Anchor LIBERTY LIB-6000 Setup Manual

LIBERTY LIB-6000
1
Setting Up the Speaker Stand
Loosen the bottom tripod
adjustment knob (counter
clockwise).
Turn the stand right
side up and while
holding above
ground, push the
collar down until the
legs are extended and
leg braces are parallel
to the ground.
2
Setting Up the Liberty Unit
Turn the stand
upside down and
separate the legs.
Adjust the inner tube to the desired height
(best performance with speaker above crowd level).
Tighten the tripod height adjustment knob
(clockwise).
Tighten the bottom tripod adjustment
knob (clockwise).
Line up the speaker stand
port with the bottom of the
Liberty's base
Place the Liberty on the
speaker stand.
SETUP GUIDE
3
Managing the Optional Built-in CD Unit
CD player is autimatically active when you turn on the power
When CD is inserted, indicator light illuminates.
Volume control can be
adjusted using the CD
VOLUME knob on the
back panel.
4
Battery Maintenance
• Recharge battery after every use
• Liberty may be plugged into AC power when not in use
• Liberty battery life is approx 2-4 years, depending on use
• Battery may be purchased directly from Anchor Audio, Inc.
100-0137-000 Rev. A
Push PLAY to
begin playback
Insert disk into CD player
Track skip features can be utilized by pressing either
the UP or DOWN buttons. Press and hold either UP
or DOWN buttons to fast forward or rewind.
