www.healthrider.com

USERʼS MANUAL

Model No. HRTL61510.1

Serial No.

Write the serial number in the space

above for reference.

Serial Number

Decal

QUESTIONS?

If you have questions, or if parts are

damaged or missing, DO NOT CON-

TACT THE STORE; please contact

Customer Care.

IMPORTANT: Please register this

product (see the limited warranty

on the back cover of this manual)

before contacting Customer Care.

1-888-922-4222

CALL TOLL-FREE:

Mon.–Fri. 6 a.m.–6 p.m. MT

Sat. 8 a.m.–4 p.m. MT

ON THE WEB:

www.healthriderservice.com

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

Need help?

Do you have a question about the HRTL61510.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Healthrider HRTL61510.1

Page 1 USERʼS MANUAL Model No. HRTL61510.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CON- TACT THE STORE; please contact Customer Care.
Page 2 Apply the decal in the location shown. Note: The decals may not be shown at actual size. HealthRider is a registered trademark of ICON IP, Inc.
Page 3 13. To purchase a surge suppressor, see informed of all warnings and precautions. your local HealthRider dealer or call the tele- phone number on the front cover of this man- 3. Use the treadmill only as described.
Page 4 20. Never leave the treadmill unattended while it 24. Inspect and properly tighten all parts of the is running. Always remove the key, unplug treadmill regularly. DANGER: the power cord, and press the power switch into the off position when the treadmill is not Always unplug the power in use.
Page 5 BEFORE YOU BEGIN Thank you for selecting the revolutionary HealthRider ing this manual, please see the front cover of this man- ® H55T treadmill. The H55T treadmill offers an impres- ual. To help us assist you, please note the product sive selection of features designed to make your work- model number and serial number before contacting us.
Page 6 ASSEMBLY To hire an authorized service technician to assemble the treadmill, call 1-800-445-2480. Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant.
Page 7 1. Make sure that the power cord is unplugged. Remove the ties securing the Upright Wire (70) to the Base (80). Pull the Upright Wire and the Base Ground Wire (92) through the indicated hole in the Base (80). Hole Attach the Base Ground Wire (92) to the Base (80) with a #8 x 1/2"...
Page 8 3. Hold the Left Upright (75) against the Base (80). Be careful not to pinch the wires. Insert a 3/8" x 4" Patch Bolt (4) with a 3/8" Star Washer (5) into the top hole in the Left Upright. Insert the 3/8" x 4" Patch Bolt (4) partially through the Left Upright (75).
Page 9 5. Attach the Console Frame (87) to the Left Upright (75) and the Right Upright (76) with two 5/16" x 3 1/4" Patch Bolts (7) and two 5/16" Star Washers (8); do not fully tighten the Patch Bolts yet. 6. Insert the upper end of the Left Handrail (71) into the tube on the Console Frame (87).
Page 10 7. Locate the tie in the console assembly. Use the Console tie to pull the ground wires out of the hole in the Assembly console assembly. With the help of a second person, hold the con- sole assembly near the Left Upright (75). Ground Connect the Upright Wire (70) to the console Wires...
Page 11 9. Attach the Pulse Bar Bottom (90) to the console assembly with six #8 x 3/4" Screws (6); start all six Screws, and then tighten each of them. Console Assembly Do not overtighten the Screws. 10. Attach the Left Handrail Cover (73) to the lower end of the Left Handrail (71) with two #8 x 3/4"...
Page 12 11. Raise the Frame (49) to the position shown. Have a second person hold the Frame until step 12 is completed. Orient the Storage Latch (51) so that the large barrel and the latch knob are oriented as shown. Attach the lower end of the Storage Latch (51) to the Base (80) with a 3/8"...
Page 13 OPERATION AND ADJUSTMENT THE PRE-LUBRICATED WALKING BELT dance with all local codes and ordinances. IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets and may not be compatible Your treadmill features a walking belt coated with high- performance lubricant. IMPORTANT: Never apply sil- with AFCI-equipped outlets.
Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE other features. To purchase an iFit Live module at any time, go to www.iFit.com or call the telephone number on the front cover of this manual. The treadmill console offers an impressive array of features designed to make your workouts more effec- tive and enjoyable.
Page 15 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
Page 16 4. Change the incline of the treadmill as desired. Trail tab will show a track that represents 1/4 mile (400 meters). As you exercise, the flashing rectan- To change the incline of the treadmill, press the gle will show your progress. The My Trail tab will Incline increase or decrease button or one of the also show the number of laps you are completing.
Page 17 6. Measure your heart rate if desired. 7. When you are finished exercising, remove the key from the console. Before using the handgrip pulse Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest sensor, remove setting.
Page 18 HOW TO USE AN ONBOARD WORKOUT ent speed and/or incline setting is programmed for the next segment, the treadmill will automatically 1. Insert the key into the console. adjust to the new speed and/or incline setting. See HOW TO TURN ON THE POWER on page 15. The workout will continue in this way until the last segment of the profile flashes in the display and the 2.
Page 19 HOW TO USE AN IFIT LIVE WORKOUT or the Event Training button to download the next workout of that type in your schedule. Press the Note: To use an iFit Live workout, you must have an Compete button to compete in a race that you have optional iFit Live module.
Page 20 6. Follow your progress with the displays. HOW TO USE THE STEREO SOUND SYSTEM See step 5 on page 16. To play music or audio books through the consoleʼs stereo speakers, you must connect your MP3 player, The My Trail tab will show a map of the trail you CD player, or other personal audio player to the con- are walking or running or it will show a track and sole through the MP3 jack.
Page 21 THE INFORMATION MODE Press the decrease button next to the Enter button. The display will show the contrast level of the display. The console features an information mode that keeps Press the Incline increase and decrease buttons to ad- track of treadmill information and allows you to person- just the contrast.
Page 22 HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to the lowest position before you fold the treadmill. left.
Page 23 TROUBLESHOOTING Most treadmill problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
Page 24 Lower the treadmill (see HOW TO LOWER THE TREADMILL FOR USE on page 22). Remove the three #8 x 3/4" Screws (6). Carefully slide the Motor Hood (57) off. Locate the Reed Switch (95) and the Magnet (44) Front on the left side of the Pulley (43). Turn the Pulley View until the Magnet is aligned with the Reed Switch.
Page 25 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left idler roller bolt clockwise 1/2 of a turn;...
Page 26 EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 27 PART LIST Model No. HRTL61510.1 R0911A To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Storage Latch 3/8" x 2 1/2" Patch Bolt Right Rear Foot 3/8"...
Page 28 EXPLODED DRAWING A Model No. HRTL61510.1 R0911A...
Page 29 EXPLODED DRAWING B Model No. HRTL61510.1 R0911A...
Page 30 EXPLODED DRAWING C Model No. HRTL61510.1 R0911A...
Page 31 EXPLODED DRAWING D Model No. HRTL61510.1 R0911A...
Page 32 ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
