- Page 1 ATN BlazeTrek Series THERMAL MONOCULARS M A N U A L AMERICAN TECHNOLOGIES NETWORK CORP .
-
Page 2: Table Of Contents
TA B LE O F C O N T E N T S Features ........4 Application . - Page 3 The instructions in this manual are for informational use only and subject to change without notice . This manual is not to be construed as a commitment by ATN Corp . ATN Corp . assumes no responsibility or liability for any errors or inaccuracies that may appear in this book .
-
Page 4: Features
• AUTOMATIC SUSPEND AND SHUTDOWN A PPL I CAT I O N The ATN BlazeTrek captures sharp thermal imaging at a fast frame rate for smooth, impeccable vision on running targets and from moving vehicles . Designed to increase situational awareness at any time of day, the monocular... -
Page 5: Specifications
6 .2” x 2 .2” x 2” / 157 x 57 х 50 мм Weight 0 .7 lb / 310 g Warranty 3 years * ATN reserves the right to change the above specifications at any time without notice . -
Page 6: Preparing The Device
. 4 . Ensure that all optical surfaces are clean and ready for use . NOTE If any accessories are missing or broken contact ATN’s Customer Service at 1.800.910.2862. ON/OFF To Turn On the device press and hold the Power button... -
Page 7: Using Your Keypad
USING YOUR KEYPAD The keypad is programmed to be used in two different ways: • Short and Quick Taps — used for basic functions . • Press and Hold — used for additional functions . 1 - Power button, 2 - Top button, 3 - Center button, 4 - Bottom button . FOCUSING ADJUSTING DIOPTER For the first-time use, adjust the diopter... -
Page 8: Interface
During the adjustment, do not touch the lens to avoid smudging it; otherwise it may affect the image quality . I N T E R FAC E HOMESCREEN The first screen you’ll see after turning on the device is the Homescreen . It contains Battery Status icons and different Information icons in the lower right corner . -
Page 9: Configuring The Monocular
CONFIGURING THE MONOCULAR MENU DESCRIPTION When the Monocular is on, press and hold to enter the main menu . Function of all buttons are as follows . Press to move upward the cursor . Press to move downward the cursor . Press to confirm . - Page 10 • White Hot: The objects with high temperature are white . The higher the temperature, the brighter the color . • Alarm: The objects with high temperature are red . The objects can stand out . • Iron Red: The objects with high temperature are red . The higher the temperature, the brighter the color .
- Page 11 • Black Hot: The objects with high temperature are black . The higher the temperature, the darker the color . • Sepia: The objects with high temperature are brown . The higher the temperature, the darker the color . • Green Hot: The objects with high temperature are green . The higher the temperature, the darker the color .
- Page 12 SETTING DIGITAL ZOOM Digital zoom helps to zoom in the image . On the viewing screen, press to do digital zoom, and the image changes . SETTING EXTERNAL DISPLAY The monocular connects to PAL screen to zoom in and expand the output images for you to check the details .
-
Page 13: Adjusting Brightness
ADJUSTING BRIGHTNESS You can adjust the screen brightness, including 5 levels: level 1, level 2, level 3, level 4 and level 5 . On the main menu, press to select Press to select the brightness level . SETTING CONTRAST You can set the contrast . The higher the level is, the more the contrast will be between bright and dark areas . - Page 14 to go to the WiFi configuration screen . Press • Wi-Fi name: Model number + serial number . • Wi-Fi password: 12345678 . You can find the serial number on the Monocular and the label of the packing box . Log in to the app .
-
Page 15: Setting Language
Press to go to the Ranging Mode configuration screen . Press to move the green lines to the top and bottom of the target to get the distance between the target and the Monocular . Use the following fig as an example: •... -
Page 16: Function Settings
Press to select X-axis and Y-axis . Press and hold to calibrate the defective pixels . Press and hold to save the configuration . The center of the cursor is the position of the defective pixel . • Restore: The DPC configuration is restored to the primary state . FUNCTION SETTINGS On the main menu, press to select... -
Page 17: System Settings
Function Description Press to enable DPC (Defective Pixels Correction), and you can correct the de- DPC ( fective pixels in the image. For details, see "3.2.8 Setting DPC". Press to enable screen mode. Connect the Monocular to a computer to view live Screen Mode ( images through the Client. -
Page 18: Video And Snapshot
Parameter Description Press to select the USB mode. • Storage: The Monocular can be used as a USB Mode ( storage device. • Off: Charge the Monocular. Press to select the unit from Yd and Unit Set ( Metre. View the device information such as serial Version ( number and version number. -
Page 19: Charging
Connect the Monocular to the computer through a USB Type-C data cable . The driver will automatically be installed for first-time connection . • Connect the cables before starting the Monocular . Do not hot swap the Type-C port of the Monocular . •... -
Page 20: System Update
SYS T E M U PDAT E UPGRADING MANUALLY On the main menu, press to select Press to go to the System Settings configuration screen . Press to select USB Mode, and then press Select Storage . Connect the Monocular and your computer, and then copy the upgrading file to the Monocular . -
Page 21: Year Product Warranty
ATN, at its option, will either repair or replace the product, and such action on the part of ATN shall be the full extent of ATN’s liability, and the Customer’s sole and exclusive remedy . This warranty does not cover a product (a) used in other than its normal and customary manner;... -
Page 22: Limitation Of Liability
Agreement extend solely to the Customer . ATN’s liability hereunder for damages, regardless of the form or action, shall not exceed the fees or other charges paid to ATN by the customer or customer’s dealer . ATN shall not, in any event, be liable for special, indirect, incidental, or... - Page 23 When returning please take or send the product, postage paid, with a copy of your sales receipt to our service center, ATN Corporation at the address noted above . All merchandise must be fully insured with the correct postage; ATN will not be responsible for improper postage or, missing or damaged merchandise during shipment .
- Page 24 FOR CUSTOMER SERVICE AND TECHNICAL SUPPORT, PLEASE CONTACT AMERICAN TECHNOLOGIES NETWORK CORP. 2400 NW 95 AVE, DORAL, FL 33172 PHONE: 800-910-2862, 650-989-5100 E-MAIL: SERVICE@ATNCORP .COM WWW.ATNCORP.COM ©2025 ATN CORPORATION...
