LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV
INSTALLATION & USE MANUAL
Pro Filtration
Bottle Filling Stations & Coolers
™
Important: The refrigerated coolers must be hung on the right side.
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
Page 1
2000002324 (Rev. A - 03/25)
Advertisement
Table of Contents
Related Manuals for Elkay Pro Filtration LZSTL8WSBPRO
Summary of Contents for Elkay Pro Filtration LZSTL8WSBPRO
- Page 1 Bottle Filling Stations & Coolers ™ Important: The refrigerated coolers must be hung on the right side. Patent zurn-elkay.com/patents WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov Page 1 2000002324 (Rev.
-
Page 2: Table Of Contents
Elkay assumes no responsibility for results obtained or damage incurred from the use of this material either in whole or in part by the buyer. -
Page 3: Serial Number Location
The following key words call the reader’s attention to potential hazards. This product is covered by a Limited Warranty and Elkay will not be held responsible for damage of any kind in Hazards are identified by the “Safety Alert Symbol”... -
Page 4: Personal Safety
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 2.3 Personal Safety Shock and Electrocution Hazards Failure to follow these instructions could WARNING result in severe burns, significant injuries, and even death. These warnings indicate a potentially hazardous situation which, if not avoided, could result in serious in Water will conduct electric current to jury or death. -
Page 5: Property Damage
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 3. Tools and Supplies Use Proper Tools 3.1 Tools Required Always use proper tools which are in good working condition during the installation of the product. Using tools other than those listed could Tool Used For adversely affect the product and could result in Tape Measure Locating mounting brackets... -
Page 6: Preparation
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 4. Preparation NOTICE Connect shut-off valve to water inlet. Do not use a piercing-type 4.1 General Information saddle valve for supply water which will reduces water flow and clogs easier. 1. This water cooler is designed for indoor use only and should not be installed outdoors or in a humid Note: This water cooler has been designed and built environment. - Page 7 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Fig. 1 Page 7 2000002324 (Rev. A - 03/25)
-
Page 8: Installation
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 5. Installation 5.1 Instructions For Removing Wrapper Fig. D(ii) Fig. D(i) 1. Remove the two security screws (size T25) from the front panel. (see Fig D(i)) NOTE: SCREW THREADS INTO BUSHING WHILE ANGLED. DO NOT ATTEMPT TO THREAD SCREW INTO BUSHING HORIZONTALLY. 2. -
Page 9: Instructions For Removing Wrapper
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV NOTE: 1. Ensure that there are no plumbing or external objects below the wrapper in the specified dimension. The specified (3.27’’) minimum distance is required for the wrapper to swing out (see Fig D(iv)). 2. Removing the wrapper from the pivoting bracket when servicing the unit is recommended. The wrapper may be left in place for quick serviceability (see Fig D(iii)). -
Page 10: Installation Of Cooler
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 5.3 INSTALLATION OF COOLER 1. Hang the cooler on the hanger bracket. Be certain hanger bracket is engaged properly in the slots on the cooler back as shown in Figure 1 (Pg. 7). 2. Refer Fig D(i) to D(iv), Pg. 6 for wrapper removing instructions. 3. - Page 11 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Mounting Holes 5. Remove the bottle filler from the partially installed fasteners, remove the fasteners from the wall and align the bottle filler to the cooler. Secure the top row of mounting holes on the bottle filler using the pre- ROW A drilled holes from step 2 and secure the remaining 2 mounting holes in that row.
- Page 12 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 10. Connect electrical power by plugging in unit’s power cord. 11. Turn on main water supply and turn the power switch on to the right side and check for leaks. Tethers Note: Ensure drain line is installed to avoid leakage into the cooler during auto-flush procedure.
- Page 13 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 16. Verify proper dispensing from the bottle filler by placing a cup under the water dispenser spout and verify the bubbler operation by pressing the push bar on the front panel. Note: The first initial dispenses might have air in the line which may cause a sputter.
-
Page 14: Reference Figures
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Reference Figures FIG. 2 FIG. 3 Secure cooler frame to wall by installing (2) screws and washers (not supplied). Fig. 4 Connect the bottle filler electrical harness. (Gasket removed from bottle filler for clarity) Fig. 5 OPERATION OF QUICK CONNECT FITTINGS OPERATION OF QUICK CONNECT FITTINGS SIMPLY PUSH IN... -
Page 15: Plumbing Diagram
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV PLUMBING DIAGRAM Bottle Filler Drain Versatile Wrapper Installation Instructions Right Hand Wrapper (Low Side) 1) Remove the (2) screws from the wrapper, rotate the wrapper down, and remove. 2) Clip cover plate, sliding until plate sits flush with the wall. - Page 16 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Mounting Bolt Holes (6) Tethers Wall Mounting Plate Tethers Fig. 11 BOTTLE FILLING UNIT 115V Refrigerated Wiring Diagram with Alpha/Numeric Display Connected-Ready - Enhanced Bottle Filler Pro Filtration Bottle Filling Station Electrical Diagram Programming Button LZSTL8WSBPRO LZSTL8WSBPROUV Module RS232...
- Page 17 Blue indicates normal operation, no immediate attention needed. Red indicates immediate attention required to maintain proper function. Scan for trouble shooting and to sign up for auto replenishment of authentic Elkay filters. Page 17 2000002324 (Rev. A - 03/25)
-
Page 18: Temperature Control
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Refrigerated Unit Service Instructions Lower and Upper Shroud To access the refrigeration system and plumbing connections, remove two (2) screws from front of cooler to remove the lower shroud. To remove the upper shroud for access to the pushbars, regulator, solenoid valve or other components located in the top of the unit, remove lower shroud, disconnect drain, remove four screws from tabs along lower edge of upper shroud, unplug two wires and water tube. -
Page 19: Programming Instruction
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Programming Instruction Depress Button for 5 seconds to activate main menu, then release Display will cycle through all menu options for 2 seconds each for 2 cycles, then return to bottle count display if no user input is detected Display will cycle through all sub-menu options for 2 seconds each for 2 cycles, then return to main menu if no user input is detected Selections are saved upon exit from each sub-menu. - Page 20 IR sensor and clean sensor lens. • Close water shutoff valve, power cycle unit, and re-open valve. If error pesists, replace solenoid. • System could not detect genuine Elkay PRO filter in lower filter position. Lower filter BF04 Communication error - filter tag •...
- Page 21 LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV Pictured is unit only without bottle filler. Note: Danger! Electrical shock hazard. Disconnect power before servicing unit. Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A See Fig. 17 11, 12 See Fig. 16 11, 12 Fig.
-
Page 22: Service Instructions
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 115V PARTS LIST / LISTA DE PIEZAS DE 115 V / LISTE DES PIÈCES 115 V ITEM NO. PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION 28401C Hanger Bracket Soporte colgante Ferrure de suspension 55001109 Basin - Stainless Steel Tarja: Acero inoxidable Cuve - Acier inoxydable 0000001337... -
Page 23: Frequently Asked Questions (Faq)
LZSTL8WSBPRO, LZSTL8WSBPRO-FSR5, LZSTL8WSBPRO-FLP4, LZSTL8WSBPRO-UV 8. Frequently Asked Questions (FAQ) For FAQ questions refer to the Elkay website elkay.com FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved could void your authority to use this equipment This device complies with Part 15 of the FCC Rules. Operation to the following two conditions: (1) This device may not cause harmful interference, and... - Page 24 IMPRESO EN LOS E.E.U.U. INFORMATIONS POUR LE SERVICE PAR NUMERO SANS FRAIS 1.800.260.6640 IMPRIMÉ AUX É.-U. ELKAY MANUFACTURING Co. • 1333 BUTTERFIELD ROAD SUITE 200 • DOWNERS GROVE, IL 60515 USA • 630.574.8484 • www.elkay.com 2000002324 (Rev. A - 03/25) Page 24...
