Magnum Heating H64 Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
H64INSTRUCTIONS
1
2
3
4
5
6
7
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H64 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Magnum Heating H64

Summary of Contents for Magnum Heating H64

  • Page 1 H64INSTRUCTIONS...

  • Page 2: Table Of Contents

    Technical Parameters......01 Product installation and testing....06 Quick test..........14 Wiring diagram........15 Product parameter........16 Default programming......17 Link APP..........18...

  • Page 3: Technical Parameters

    Technical Parameters Wiring control centre H64-CC Power source: 100-240VAC 50 / 60Hz (maximum current 10A) Storage environment temperature and humidity: -10 ~ 60°C, 0 ~ 90% RH (non-condensing) Working environment temperature and humidity: 0 ~ 50 °C, 0 ~ 80% RH (non-condensing)
  • Page 4 Wiring control centre interface introduction Thermostat heating status: light keep bright with output without output didn’t light 1 corresponds to the W1 region, and so on Pump output status: light keep bright with output without output didn’t bright heating/cooling changeover status Cooling mode activate keep bright Heating mode no bright Power status: light keep bright...
  • Page 5 Master(H64-MT WiFi) / Slave(H64-ST) * Power supply and signal input: DC12 ~ 18V carrier non-polarity input (power supply wiring control centre, maximum current 100mA) * Storage environment temperature and humidity: -10 ~ 60°C, 0 ~ 90% RH (non-condensing) * Working environment temperature and humidity: 0 ~ 50°C, 0 ~ 80% RH (non-condensing) * Temperature display range: 0 ~ 50°C...
  • Page 6 WIFImode Programmingmode (H64-MT Only) Room temperature/ Cooling setting temperature Heating Child lock Down button Up button Power button Adjust temperature In switch off status, short press to switch on thermostat. In switch on status, long press over 5 seconds to switch off; And display OFF.
  • Page 7 Manually switch programming mode:Short press“ ” button while switching on,switch programming and non-programming operation mode. Programming icon light on when in programming mode. Without display mean in non-programming operation mode. Cooling icon:Blue light mean cooling output; White light on mean enter cooling mode. Press“...

  • Page 8: Product Installation And Testing

    Please pay attention to distinguish the master and slave thermostat during the installation. The master thermostat is packaged with the wiring control centre and named H64-MT WiFi 1. There is a slit above the wiring control centre. Use a small flat-blade screwdriver to insert it and pry it out and remove the back plate.
  • Page 9 2. Use the back plate to mark the hole position, and then use an impact drill (6mm drill bit) to make the screw holes (if there is a mounting rail, you can ignore it) 6mm drill bit...
  • Page 10 3. Press the buckle to remove the anti-electrical board, and then connect the wires referring to wiring port and the marked wiring on the anti-electrical board. Buckle Anti-electrical board...
  • Page 11 4. After wires connection, fix the back plate with screws (if there is a mounting rail,please snap to it directly) and cover the anti-electricity board and face shell. Finish...
  • Page 12 Please pay attention to distinguish the main and slave thermostats, the main thermostat and wiring control centre are in a package, named H64-MT WiFi 1. Pull back plate to open the thermostat (magnet adsorption)
  • Page 13 2. Wiring (It is recommended to use 0.75-1.5mm wire) Press the snap-gauge Connect NTC10K Power:12V wire from wiring center snap-gauge Insert the wires into slots...
  • Page 14 3. Fix the back plate with screws...
  • Page 15 4.Cover the face shell...

  • Page 16: Quick Test

    Quick test After wiring control centre energized, please check if the main thermostat was installed correctly in living room, and then check the slave thermostats in other rooms one by one. 1. The screen is off, indicating no power. Please check if the wiring is correct between the thermostat and the wiring control centre.

  • Page 17: Wiring Diagram

    Wiring diagram Wiring control centre H64-CC Precautions ①W1-W8: Connected to the thermostat, low voltage, regardless of null line and fire line, W1 must be connected to the master thermostat, W1 corresponds to an area. ② R1-R8: Connected electric heating actuator, R1 corresponds to W1, R2 corresponds to W2, and so on, R1-R4 can be connected to two electric heating actuators respectively, the total current does not exceed 5A.

  • Page 18: Product Parameter

    Configuration menu setting Turn thermostat to OFF mode, hold “+”“-” button over 3 seconds enter the first parameter setting and display 01, press “+”“-” select to different parameter. Short press “o” enter specific item setting. Short press “o” again to exit. Long press “o”...

  • Page 19: Default Programming

    NTC function selection S-r：Room temperature A floor sensor is not present, the unit will be controlled via internal sensor and display as room temperature. r-F: Dual temperature control The thermostat will control based on actual room temperature detected by internal sensor and compare the floor temperature limitation set by parameter 8.If floor temperature higher than limitation, it wil stop working and alarm E4.If floor sensor is not connected under r-F mode, it will alarm E2.

  • Page 20: Link App

    LINK APP Download and register...
  • Page 21 Login When you finish the register,log in your mailbox and click on the link to activate your account, then can login TuyaSmart APP...
  • Page 22 Add thermostat Tips: Please turn on the location of your phone at first. Enter the “HOME” interface of the app, Click the list bar “ Small home APP ”, select Click the “+” in the upper right corner . “Thermostat(Wi-Fi)”in the right device list.
  • Page 23 Make sure the red light is blinking fast. Enter your wifi account and password Click “ Confirm ” Click “ Next ” xxxxxx Click “Done”, it means the wait a few seconds until the search gateway added successfully. progress is 100%...
  • Page 24 Click“ Add subdevice” Click “LED already blink”...
  • Page 25 Click “ DONE ” Click “DONE”...
  • Page 26 APP display Click for setting implicit parameters In cooling mode: yellow Click for programming Cooling output: blue Slide to adjust temperature In heating mode: yellow Heating output: red Press“ ”“ ”adjust temperature Slide to power on /power off...
  • Page 27 Click to exit setting Temporary leaving mode: If you need to stay out temporarily, click the button to activate energy-saving mode and icon“ ” turn to green. If heating mode temperature remain at 16℃,cooling mode temperature remain at 28℃. After you arrive home,click the button again to recover the previous temperature setting.

  • Page 28: Program-Setting

    Program-setting Slide the button “ ” to close programming. cool Click“cool” to heat set program for cooling； click“heat” to set program for heating Click“ 7 days ” for choosing Select the date, Click“ ” for programming the date to program Click“...
  • Page 29 Click to enter parameter setting Click to remove device...
  • Page 30 Voice command： After waking up the speaker, you can say: Amazon Alexa Google Assistant * Alexa, open <device name>. * Ok, google, turn on <device name>. * Alexa, close <device name>. * Ok, google, turn off <device name>. * Alexa, set the <device name> to 16 degrees. * Ok, google, set the <device name>...

This manual is also suitable for:

H64-ccH64-mtH64-st
