Scinomix Sci-Print VX2 Manual

TS-1104
Purpose
This guide provides the steps required to manually adjust the tension of the labels on the
Sci-Print VX2/VXL/SOLO with a Cab A2+ printer installed.
Required Material and Equipment
CAB SQUIX printer on a Sci-Print VX2/VXL and SOLO
Intended Audience
End Users
Prerequisites
N/A
Procedure
1. Verify the labels are installed properly. See
2. On the back, right, top of the printer is a label tensioner. This is responsible for keeping
the label backing tight when feeding and backfeeding. During normal operation, the
tensioner shifts to the left when feeding, and shifts back to the right when backfeeding.
During backfeeding, to avoid tension drop, it should not get to the far right side.
File Location: Google Drive
Label Tension
Guide (A2+)
Figure 1. Normal left side movement.
Revision: A Approved Date: MAR-27-2023 Approved by: Service Team
Document Owner:
Service Department
UG0011 VX2/VXL User
Effective Date: Page 1 of 4
MAR-27-2023
Guide.
