Bauhn AMPDQ-0525-MP User Manual

Have you got everything?
A
A. 4 in 1 Multiport Wireless Charging Station
B. Power Adaptor
C. USB-C Cable
D. User Guide
E. Warranty Certificate
A. Wireless Charging Pad
B. Wireless Charging LED Indicator
C. Ambient Light Button
D. USB-C Output
E. USB-A Output
F. USB-C Input
Operation
Connect to a power source
Connect the supplied power adaptor and USB C cable to the
4 in 1 multiport wireless charging station.
Make sure the power source is switched on and working. The
charging station will power on and works standby mode.
Note: Please always use the supplied power adaptor.
Otherwise, the charging station may not work properly if the
input power source does not have sufficient power input.
Charging your devices
1.
Wireless charging pad
Place your smart phone facing up on the wireless
charging pad. Once the phone is correctly aligned, the
charging process will auto start. The wireless charging
LED indicator solid blue light indicates the charging is
in progress. If the LED is off, your mobile phone may
not support wireless charging, or it is not aligned to
wireless charging pad or it is fully charged.
2.
Charging devices using the USB-C port
Plug one end of your USB-C cable into the USB-C
port, and the other end into your mobile device.
3.
Charging devices using the USB-A port
Plug one end of your USB-A cable into the USB-A
port, and the other end into your mobile device.
Using the ambient light
Press the ambient light control button to turn on/off
the light and switch the light mode.
Wireless charging
not working
No output from the
USB ports
No power output or
not work properly
Input
Output
Ambient Light
Dimensions
Weight
* Output is dependent on input power
** Only supported on some devices compatible with 15W wireless charging.
4 in 1 Multiport Wireless Charging Station
Note: Only one charging station
(black or white) is supplied.
• Check that your smart phone supports wireless charging.
• If you have a smart phone case, you must remove when charging.
• Ensure your smart phone is facing up and aligned to the centre of the
wireless charging pad, and remove any metal or other objects between the
smart phone and the wireless charging pad.
• Check that the USB cable is connected securely to the USB port and/or try a
different USB port.
• The total output current for the USB ports are 3A. Remove devices using the
other USB ports.
Use another USB cable.
•
• The charging station may not work properly if the input power source has
no sufficient power input.
• Please always use the supplied power adaptor.
USB-C 12V 3A
Wireless Output: 5W, 7.5W, 10W, 15W
USB-C1 / A1 / A2 Output: 5V
(Total USB Output 15W Max if more than 1 output use)
8 light mode
174 x 82 x 34mm
165g
User Guide
Model: AMPDQ-0525-MP
C
B
Product Overview
B
C D
E
1
Troubleshooting
3A
D
E
A
F
USB-C Input
2
3
Ambient Light
Control
