Model #
1456AFCAF Pacific
Cal-King Storage Bed
Caffè finish
Assembly Instructions
Congratulations!
This fine piece of furniture will make a gorgeous
addition to your home. For the best results, read the
Assembly Instructions before you begin your project.
CALL US FIRST!
Service Policy: We will replace any part that is
defective, missing or damaged during assembly.
Please contact Whittier Wood Products customer
service department directly by phone, fax, mail or
email for a replacement part.
Hours: Our friendly customer service staff can be
reached Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific
Time). You may leave a message 24 hours a day,
seven days a week.
800-653-3336
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.
P.O. Box 2827
Eugene, OR 97402 USA
Do not return this item to the store.
To Order: Provide the furniture model number (upper
left corner of this page), the part letter, production
code, quantity needed, reason for replacement, your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one
or two business days from the time we receive your
request. Please allow five to ten business days for delivery.
• Outside the U.S. or Canada: 541-687-0213 • Fax: 541-687-2060
Production Code:
VN
IMPORTANT NOTES:
For normal household use only. Not recommended
for commercial use.
Unload items from this unit prior to moving.
Before you load or move this item, check to make
sure all screws and supports are tight.
Do not overload the drawers in this unit.
Before you begin your project, completely read the
Assembly Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in
temperatures that range from 40° to 90° (not on a
cold and possibly damp cement floor).
Periodically inspect your furniture for any loose
glue joints, screws or any other problem that might
affect the stability of your furniture. Tighten or
repair as needed.
This assembly requires two people.
.
11/09
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whittier Wood Furniture Pacific 1456AFCAF
Summary of Contents for Whittier Wood Furniture Pacific 1456AFCAF
- Page 1 Model # 1456AFCAF Pacific Cal-King Storage Bed Caffè finish Assembly Instructions IMPORTANT NOTES: For normal household use only. Not recommended for commercial use. Unload items from this unit prior to moving. Before you load or move this item, check to make sure all screws and supports are tight.
- Page 2 1456AFCAF Pacific Cal-King Storage Bed — Parts List Please identify the parts and check that quantities received match what is on this list. If you need to replace a part, refer to the following letter and item name. 1459AFCAF (x1) B —...
- Page 3 1456AFCAF Pacific Cal-King Storage Bed Assembly Instructions This Assembly Requires Two People Tools Required Hex Wrench (provided), Phillips Screwdriver, Slotted Screwdriver 1/2" Wrench, 7/16" Wrench, Tape Measure, Padded Hammer or Rubber Mallet, Wood Glue Fig. 1a Fig. 1 Drawer Release Lever Remove the Drawers (O) from the Pedestal Kits (N).
- Page 4 Fig. 3a 4½" Fig. 3 3. Rotate the Adjustable Glides (M) so that the Foot Assemblies (C) are 4½" tall as shown in Figure 3a. Attach the six Foot Assemblies (C) as shown in Figure 3. Fig. 4 4. This step requires two people to move the bed to its upright horizontal position. Rotate the bed so the deck boards are face-up.
- Page 5 Fig. 6a Fig. 6b Top cap Fig. 6 6. Position the Footboard (B) against the end of the pedestal assembly and insert the dowels into the oval holes in the top cap of the footboard. Place four 5/16" Washers (E) over four 5/16" x 2¼" Hex Bolts (D) and thread the washer/bolts through the pre-drilled holes in the Pedestal Assembly and into the Footboard.
- Page 6 Fig. 8 Fig. 8b Fig. 8a Secure the preattached Angle Brackets (K) on the Headboard to the Pedestal Assembly with six #6 x ¾" Flat Head Screws (L). See Figures 8 and 8a. Insert one Barrel Nut (I) into the predrilled hole on the bottom of the left pedestal rail.
