QUICK START GUIDE
EXCEED CF M160
IMPORTANT!
READ THESE INSTRUCTIONS CAREFULLY BEFORE FIRST
USE AND KEEP THEM FOR FUTURE REFERENCE.
For unboxing and
assembly scan here

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXCEED CF M160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Canyon EXCEED CF M160

Summary of Contents for Canyon EXCEED CF M160

  • Page 1 QUICK START GUIDE EXCEED CF M160 IMPORTANT! READ THESE INSTRUCTIONS CAREFULLY BEFORE FIRST USE AND KEEP THEM FOR FUTURE REFERENCE. For unboxing and assembly scan here...
  • Page 2 CANYON SUPPORT CENTRE CONTACT YOUR LOCAL SUPPORT: (+49) 261 9490 3000 UK (+44) 3331501967 AU (+61) 1 300 712 003 NZ (+61) 3 9771 261607 (+33) 890 710 132 (+34) 910470740 (+39) 045515527 (+31) 40 - 808 0485 (+32) 16 98 03 99...
  • Page 3 QR code sottostante per scaricarlo, oppure tained as such. Misuse, improper assembly, or delec Handbuch beachten. Wenn Du mit Deinem Canyon, au moins jusqu’à la fin de la période visita il sito www.canyon.com per maggiori lack of maintenance can make your bike unsafe Fahrrad am öffentlichen Straßenverkehr teil-...
  • Page 4 FI  HUOM! Tämä pikaopas ei korvaa Canyon-kä- Canyon racefietsen, tijdritfietsen, triatlonfietsen canyon.com. Se usas a tua bicicleta em estradas yttöohjekirjaa tai muita pyörän käyttämiseen Obecné informace o péči a kontrole, en baanfietsen zijn performance bikes met een públicas, esta deve estar equipada de acordo...
  • Page 5 å scanne QR koden, eller besøke www. 在有效保固期內我們會供應必要的補修零件. 然而在此保固期間若當零件供應有短缺或無 캐니언 로드, 트라이애슬론 자전거는 프로 수준의 Możemy zaoferować naszym klientom canyon.com, der du vil finne all den informasjo- 法供應時, 得以相同等級或更高級的零件做替 가벼운 구조를 특징으로 하는 최고의 스포츠 자전 niezbędne części zamienne do produktów nen du trenger.

  • Page 6: Table Of Contents

    CONTENTS 01. Unpacking 02. Handlebar installation (ST0039) 02. Cockpit installation (CP0036/37) 03. Brake lever installation 04. Seat post installation 05. Saddle adjustment (SP0083) 06. Saddle adjustment (VCLS SP0084) 07. Front wheel assembly 08. Rear wheel assembly (L – 2XL) 09. Pedal installation Checklist –...
  • Page 7 SMALL BOX CONTENTS NOT INCLUDED INCLUDED QUICK START GUIDE ONLY CP0036/37 ASSEMBLY PASTE ASSEMBLY PASTE For carbon & alloy components For carbon & alloy components...
  • Page 8 WARNING!

  • Page 9: Unpacking

    01. UNPACKING...

  • Page 10: Handlebar Installation (St0039)

    02. HANDLEBAR INSTALLATION (ST0039) 4 mm 10-30°...
  • Page 11 02. HANDLEBAR INSTALLATION (ST0039) 4 mm 6 Nm A = B...

  • Page 12: Cockpit Installation (Cp0036/37)

    02. COCKPIT INSTALLATION (CP0036/37) 4 mm max. 2 Nm 4 mm 4 mm...

  • Page 13: Brake Lever Installation

    03. BRAKE LEVER INSTALLATION 10-30° 3 Nm...

  • Page 14: Seat Post Installation

    04. SEAT POST INSTALLATION 3 mm 3 mm 4 Nm...
  • Page 15 04. SEAT POST INSTALLATION 1040 1020 1000 Saddle height (mm)

  • Page 16: Saddle Adjustment (Sp0083)

    05. SADDLE ADJUSTMENT (SP0083) 5 mm 5 mm 8-10 Nm...

  • Page 17: Saddle Adjustment (Vcls Sp0084)

    06. SADDLE ADJUSTMENT VCLS (SP0084) 4 mm 4 mm 4 mm 4 mm 7 Nm 5 Nm...

  • Page 18: Front Wheel Assembly

    07. FRONT WHEEL ASSEMBLY...

  • Page 19: Rear Wheel Assembly (L - 2Xl)

    08. REAR WHEEL ASSEMBLY (L – 2XL) 15 Nm SRAM Shimano Check unboxing video Sieh dir das Unboxing-Video an Voir la vidéo de déballage...

  • Page 20: Pedal Installation

    09. PEDAL INSTALLATION PEDALS AND GREASE ARE NOT INCLUDED! PEDALE UND FETT NICHT IM LIEFERUMFANG! LES PÉDALES ET LA GRAISSE NE SONT PAS INCLUSES !

  • Page 21: Fork Setup

    10. FORK SETUP 10.1 Check suspension setup video Sieh dir das Video zur Einstellung der Federung an Voir la vidéo sur le réglage de la suspension 15-20 % SAG RECOMMENDED 15-20 % SAG EMPFOHLEN 15-20 % SAG RECOMMANDÉ FORK MANUAL...

  • Page 22: Rear Wheel Disassembly

    11. DISASSEMBLY REAR WHEEL 11.1 11.2 11.3...
  • Page 23 11. DISASSEMBLY REAR WHEEL 11.4 SRAM Shimano...

  • Page 24: Handlebar Height Adjustment (St0039)

    12. HANDLEBAR HEIGHT ADJUSTMENT (ST0039) 12.1 12.2 5 mm 4 mm 12.3 12.4 2 Nm 4 mm...
  • Page 25 12. HANDLEBAR HEIGHT ADJUSTMENT (ST0039) 12.5 5 mm 8 Nm...

  • Page 26: Cockpit Height Adjustment (Cp0036/37)

    13. COCKPIT HEIGHT ADJUSTMENT (CP0036/37) 13.1 13.2 4 mm 13.3 13.4 4 mm max. 2 Nm...
  • Page 27 13. COCKPIT HEIGHT ADJUSTMENT (CP0036/37) 13.5 4 mm...

  • Page 28: Checklist - Before First Ride

    CHECKLIST BEFORE FIRST RIDE CHECK THE BIKE CATEGORY & INTENDED PURPOSE OF YOUR BIKE IN THE CANYON USER MANUAL PRÜFE DIE BIKE-KATEGORIE UND DEN BESTIMMUNGS- GEMÄSSEN GEBRAUCH IM FAHRRAD-HANDBUCH VÉRIFIE LA CATÉGORIE DU VÉLO ET L’USAGE PRÉVU DANS LE MANUEL DU VÉLO...

  • Page 29: Checklist - Before Every Ride

    CHECKLIST BEFORE EVERY RIDE CHECK AND/OR RETIGHTEN WHEEL CHECK BIKE, TYRE & ALL COMPONENTS FOR DAMAGE, FASTENING SYSTEM, PEDALS, BOLTS & NUTS WEAR & MATERIAL FATIGUE CHECK YOUR BIKE FOR PROPER FUNCTIONALITY PRÜFE UND ZIEHE DIE ACHSEN, PEDALE PRÜFE DEIN BIKE UND ALLE KOMPONENTEN AUF SOWIE SCHRAUBVERBINDUNGEN NACH.

  • Page 30: Maintenance - What To Do

    MAINTENANCE – WHAT TO DO INSPECT SEAL/POLISH SURFACE CHECK MEASUREMENTS PRÜFEN OBERFLÄCHE VERSIEGELN AUF MASS PRÜFEN INSPECTER SCELLER LA SURFACE VERIFIER LA TAILLE WET CLEAN GREASE COMPONENT ADJUST COMPONENT WASCHEN BAUTEIL FETTEN EINSTELLEN LAVER COMPOSANT DE GRAISSE AJUSTER DRY CLEAN LUBRICATE COMPONENT CHECK BEARING CLEARANCE TROCKEN REINIGEN...
  • Page 31 WARNINGS CONSULT MANUFACTURER MANUAL HERSTELLER-HANDBUCH BEACHTEN OBSERVER LE MANUEL DU FABRICANT ALWAYS USE CORRECT TORQUE RICHTIGES DREHMOMENT BEACHTEN ASSUREZ-VOUS DU COUPLE CORRECT DON’T USE A PRESSURE WASHER HOCHDRUCKREINIGER NICHT BENUTZEN NETTOYEUR HAUTE PRESSION INTERDIT...

  • Page 32: Maintenance

    MAINTENANCE AFTER EVERY RIDE Complete Bike Drivetrain...

  • Page 33: Every 2 Weeks

    MAINTENANCE EVERY 2 WEEKS Drivetrain components Suspension Brake pads...

  • Page 34: Every Month

    MAINTENANCE EVERY MONTH Spokes & Hubs Headset Bearing Pedals, Crank & Bottom Bracket 2. 2. 2. Tyres & Rims...
  • Page 35 MAINTENANCE AFTER 6 MONTHS Chain wear Cables Surfaces...

  • Page 36: Every Year

    MAINTENANCE EVERY YEAR Cockpit Attached parts...
  • Page 37 YOUR BIKE‘S NOW PROPERLY MAINTAINED.

  • Page 38: Explosion Drawing

    EXPLOSION DRAWING SPARE PARTS:...
  • Page 39 READY TO RIDE!
  • Page 40 EDITOR / MANUFACTURER: Canyon Bicycles GmbH Karl-Tesche-Strasse 12 D-56073 Koblenz MANUFACTURER UNITED STATES: Canyon Bicycles USA, Inc. 5600 Avenida Encinas Carlsbad, CA 92008, USA VERSION: 26.08.24 | 20027149 | 057-V01...
