Hirschmann EAGLE TX/TX Description And Operating Instructions

Description and operating instructions
Industrial ETHERNET Firewall/VPN System
EAGLE
x
1 2
P FAULT
STATUS
LS/DA
1 2 V.24
R
k
1
2
g
V.24
EAGLE TX/TX
EAGLE FW TX/TX
D
RS2-4R EAGLE
x
1 1 2 2
P P FAULT FAULT
RM
STATUS
0 1
LS/DA
RM
1 2 V.24
RING
R
V.24
k
DA
1
1
LS
2
DA
2
LS
g
DA
3
LS
DA
4
LS
V.24
EAGLE TX/MM SC
EAGLE TX/SM SC
EAGLE TX/LH SC
EAGLE FW TX/MM SC
EAGLE FW TX/SM SC
EAGLE FW TX/LH SC
EAGLE
x
1 2
P FAULT
STATUS
LS/DA
1 2 V.24
R
k
1
2
g
V.24
EAGLE MM SC/TX
EAGLE FW MM SC/TX
EAGLE
x
1 2
P FAULT
STATUS
LS/DA
1 2 V.24
R
k
1
2
g
V.24
EAGLE MM SC/MM SC
EAGLE MM SC/SM SC
EAGLE MM SC/LH SC
EAGLE FW MM SC/MM SC
EAGLE FW MM SC/SM SC
EAGLE FW MM SC/LH SC
EAGLE
Bestell-Nr. / Order No.
943 011-00x
943 011-01x (FW...)
The industrial firewall/VPN system
– EAGLE TX/TX
– EAGLE TX/MM SC
– EAGLE TX/SM SC
– EAGLE TX/LH SC
– EAGLE MM SC/TX
– EAGLE MM SC/MM SC
– EAGLE MM SC/SM SC
– EAGLE MM SC/LH SC
– EAGLE FW TX/TX
– EAGLE FW TX/MM SC
– EAGLE FW TX/SM SC
– EAGLE FW TX/LH SC
– EAGLE FW MM SC/TX
– EAGLE FW MM SC/MM SC
– EAGLE FW MM SC/SM SC
– EAGLE FW MM SC/LH SC
in the following called EAGLE, authenti-
cates, validates and ensures that the com-
munication within the production networks
remains confidential, also beyond the
boundaries of the company.
– Interfaces:
depending on the type up to two 10/100
MBit/s twisted pair (TP/TX) ports (RJ45
socket) and/or up to two 100 MBit/s FX
ports (multimode, singlemode or
longhaul) with DSC connectors and addi-
tionally one V.24 interface for external
management or modem connection
– Network modes:
• Multi Client Transparent Mode
(MCT Mode), default setting
• Single Client Transparent Mode
(SCT Mode)
• Router Mode
– Firewall (FW)
– ARP Limiter
– Redundancy support
– ACA 11 support
– Management: HTTPS, SNMPv3, SSH
– Redundant 24 V power supply
– Temperature range: 0°C – 60°C, no fan
– Housing: can be mounted on DIN rail, IP20
The VPN versions (EAGLE TX.../
EAGLE MM...) in addition support
Virtual Private Network (VPN) functions.
In the „Manual EAGLE Management –
Industrial ETHERNET Firewall/VPN System"
you will find a detailed description on the
EAGLE.
