- Page 1 User’s Manual DIGITAL CABLE NETWORK TERMINAL WITH COMMON INTERFACE CSR 3402 QAM MENU...
-
Page 2: Table Of Contents
CONTENTS 1. Features ----------------------------------------------------------------------------- 2 Front & Rear View ---------------------------------------------------------------- 3 3. Remote Control Unit (RCU) ---------------------------------------------------- 4 4. Getting Started --------------------------------------------------------------------- 5 5. Operation and Menu Program ------------------------------------------------- 7 6. Specifications ---------------------------------------------------------------------- 16 AC power switch is on the rear panel of the receiver. AC power switch is on the rear panel of the receiver. -
Page 3: Features
1. Features 1. MPEG 2 Video(MP@ML) 2. MPEG 1 Audio Layer 1, Layer 2 3. MPEG-2 Digital & Fully DVB Compliant 4. Capable of Interfacing the CAMs of DVB Common Interface Standard 5. Automatic Channel Set-up for CATV network 6. Capable of Auto scanning the frequency for QPSK to QAM Conversion system 7. -
Page 4: Front & Rear View
2. Front & Rear View FRONT PANEL MENU 2 CAM Slots REAR PANEL AC Power Cord Cable Input VIDEO ANT IN AUDIO TV/VCR AC power switch Loop Through Note) All cables used for connecting the receiver should be well-shielded type cable. -
Page 5: Remote Control Unit (Rcu)
3. Remote Control Unit (RCU) Switches the Receiver ON/OFF Switches the sound ON/OFF. Shows a thumb nail representation of the current channel in the “Edit TV Channel”, “Parental Lock” and “TV Guide”. Select the audio language or the sound track you want among data to be transmitted from the satellite. -
Page 6: Getting Started
4. Getting Started Please do NOT PLUG the receiver into Mains until you finish making all connections to the unit. Connect the coaxial cable from the Cable socket into ANT IN socket of the receiver. (Connector should be adapted finger-tight.) Receiver to TV with SCART “TV”... - Page 7 Smart Card and CI CA Module This side into the slot of the receiver Smart Card CI CA Module (Common Interface Conditional Access Module) To watch payable program channels, a CI CA Module and a smart card of specific service provider are necessary. You may ask for these to the shop which you had purchased the receiver.
-
Page 8: Operation And Menu Program
5. Operation and Menu Program Main Menu Main Menu 1. TV Channels Press on the remote control unit (RCU ). 2. Radio Channels (or press /I on the front panel of the receiver) 3. Parental Control Press to display Main Menu on the screen. 4. - Page 9 Channel Setup Manual Search Frequency Symbol Rate 0.000 By selecting this search type, you can search the Modulation channels by inputting the parameter for Frequency, Search Type Manual Search Symbol Rate and Modulation type. Start Search(Press OK) After inputting the parameters, press OK button on the Search for Single Cable Network “Start Search”...
- Page 10 Language Setting Language Setting Menu Language You can select the desired language for the OSG (On- English Screen Graphics) display using the keys when Main Audio Language English the “Menu Language” option is selected. Similarly English 2nd Audio Language you can selected a different audio channel when the Subtitle Language English “Audio Language”...
- Page 11 A/V Output Setting A/V Output Setting Please select your TV format. Aspect 4:3 for normal screen TV Banner [ 3sec ] 16:9 for wide screen TV Sub.backg. You can select OSG viewing time of the information about the current channel & program among 2/3/4/5/6/8/10secs by using volume up/down keys.
- Page 12 8. REE TV Channel Lock TV Channel Lock SMATV TV Channels 33. PARIS PREMIERE Press to lock / unlock the selected channel. 34. VOYAGE Locked channels will be skipped when scrolling 35. CONTACT TV through channels. 36. LC I 37. Canal J Note) The color of the highlighted bar turns to 38.
- Page 13 Edit Edit 1. Edit TV Channel You cannot enter this menu if the Installation & Edit Lock is [ON]. The initial code is set as [0000] and you can change it (see “Change 2. Edit Radio Channel PIN code” in page 10). 3.
- Page 14 SMATV Edit CH name & PID ASTRA Edit CH name & PID Frequency 114.0 To edit a channel name(add, change) and PID SR//Modulation 0.000/64 (Packet Identifier), you should use this menu. Channel Name ???????? Video PID On the channel name bar, you can add or change the Audio PID channel name by pressing the OK key.
- Page 15 ALT Audio L Audio R L Audio R If more than one audio channel is provided by the broadcaster on a specific channel, you can activate the audio mode display by pressing the key. TV Guide While watching or listening to any channel and you want to know more information regarding the program shown, press the GUIDE key on the remote control to display the “TV Guide”...
- Page 16 Reset (Factory Default) Reset (Factory Default) * If you want Factory Reset, press OK. If you want to reset all the data edited, press OK twice. *CAUTION : All the information of satellite and transponder to be edited by the user will be initialized by this process.
-
Page 17: Specifications
6. Specifications 1. Tuner & Channel Input Connector 1 x IEC female Loop through Connector 1 x IEC male Frequency Range 47MHz To 862MHz Waveform QAM : 16, 32, 64, 128, 256 Symbol rate 1 ~ 7MS/s Input signal level 47dB uV ~ 75dB uV for each channel Input imperdance 75 ohms nominal... - Page 18 5. PCMCIA Number of Slot Type I, II DVB Common Interface Standard 6. Power Supply AC Power Switch Push lock type(toggle) Input Voltage AC90 – 240V, 50/60Hz Type Linear PWM Power Consumption 40W Max.(Below 7W Max. For Standby Mode) Protection Separate Internal Fuse and Chassis Grounding The Input shall have lighting or Electric Shock...
