USER MANUAL

Simcenter SCADAS MOBILE &

SCADAS RECORDER

Version 2.12

Need help?

Do you have a question about the Simcenter SCADAS MOBILE and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens Simcenter SCADAS MOBILE

Page 1 USER MANUAL Simcenter SCADAS MOBILE & SCADAS RECORDER Version 2.12...
Page 3 CONTENTS USER MANUAL .........................1 GENERAL CONDITIONS ......................7 Copyright ............................7 Conditions of change ........................7 Licenses and trademarks ......................8 Product compliance ........................8 ABOUT THIS MANUAL ......................11 Availability ..........................11 Target audience ......................... 11 Conventions ..........................11 Related documentation ......................12 INTRODUCTION ........................
Page 4 SCADAS Mobile & Recorder - User Manual System architecture ......................52 Functional description ......................53 Modes of operation ........................54 Front-end mode........................54 Stand-alone mode ......................... 54 COMPONENT DESCRIPTION ....................55 Component overview ......................... 57 Functions of analog input modules..................58 Functions of analog output modules ..................
Page 5 SCADAS Mobile & Recorder User Manual Troubleshooting ........................108 Specifications........................109 OPERATION......................... 113 Prerequisites and considerations .................... 114 Preparation ..........................114 Instrument grounding ......................115 Cooling requirements ......................116 Single-frame or multi-frame operation ................116 Prepare for front-end operation ..................117 Prepare for stand-alone operation ..................
Page 7 Siemens. CONDITIONS OF CHANGE Siemens reserves the right to change parts at any moment without prior notice or direct notification. This manual may also be subject to change without prior notice. Changes and/or modifications to the product (to be conducted by the owner) may only be conducted after explicit prior written instruction, permission and/or approval by Siemens.
Page 8 SCADAS Mobile & Recorder - User Manual LICENSES AND TRADEMARKS Any software, described in this manual and/or delivered with the Simcenter SCADAS Mobile & Recorder, is provided under license and may only be used in accordance with the conditions, stated in the licenses concerned.
Page 9 Chapter 1 General conditions Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempt de licence. L'exploitation est autorisée aux deux conditions suivantes : 1. L'appareil ne doit pas produire de brouillage ; 2. L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le functionnement.
Page 10 SCADAS Mobile & Recorder - User Manual Brazil: Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. Export compliance: For all products (including V-RB) except SCM "V" Vibration control frames: Classification and Export Control EAR99.
Page 11 Siemens can supply additional copies upon request. Copies of the manual are normally supplied in electronic format. Keep this manual available for the users of the Simcenter SCADAS Mobile & Recorder. In case of re- commissioning or transfer of ownership the User Manual of the Simcenter SCADAS Mobile &...
Page 12 User Manual RELATED DOCUMENTATION This User Manual describes the hardware that makes up the Simcenter SCADAS Mobile & Recorder. These systems can only be used in combination with other Simcenter named products that have their own dedicated manuals. Where applicable the relation between the Simcenter SCADAS Mobile &...
Page 13 This chapter gives generic information about the Simcenter SCADAS Mobile & Recorder systems. The purpose of this chapter is to inform the user about what the Simcenter SCADAS Mobile & Recorder systems are meant for, and what the products comprise of.
Page 14 Misuse may result in injury to personnel or serious damage to equipment. In all cases any warranty in force will be invalidated, while Siemens will not accept any liability for misuse. WHAT DID YOU GET The Simcenter SCADAS Mobile or Recorder is delivered for one or more test configurations;...
Page 15 The information in this part is given as a guideline; we recommend that you act accordingly. In case you need to return parts to Siemens for repair, you are requested to contact your local Siemens representative first. You will be informed about the applicable procedures and follow-up.
Page 17 Simcenter SCADAS Mobile & Recorder. It is the responsibility of the user to read this information before working with the Simcenter SCADAS Mobile & Recorder, to make sure that it is used correctly and safely.
Page 18 Safety precautions. SAFETY PROVISIONS By design, the Simcenter SCADAS Mobile & Recorder has a number of safety provisions to establish the required level of personal safety. Furthermore, the owner of the Simcenter SCADAS Mobile or Recorder has the responsibility to provide a safe environment to work in.
Page 19 Some components of the Simcenter SCADAS Mobile & Recorder are designed to operate on  internal battery power; they can also be powered and/or charged with appropriate adapters. Power levels of the outputs of the Simcenter SCADAS Mobile & Recorder are within safe  limits.
Page 20 The presence of safety provisions alone is no guarantee against injury. This section gives instructions and guidelines to help the user to work safely. The users of the Simcenter SCADAS Mobile & Recorder are always responsible for their actions, their own safety and that of others.
Page 21 It is recommended to use the SCM-MODXTR SCADAS Mobile extraction tool for module  replacement. (In case of IP54 certified SCR207, the removal can only be done by authorized Siemens personnel.) EMC CONSIDERATIONS In order for the Simcenter SCADAS system to be completely immune to external and intrusive electromagnetic fields the Simcenter SCADAS system needs to be shielded at every location of the frame.
Page 23 Chapter 3 SYSTEM DESCRIPTION This chapter gives information about the features and functions of the Simcenter SCADAS Mobile & Recorder. The purpose of this chapter is to make the user familiar with what these system-level features and functions mean. IN THIS CHAPTER: System identification ...
Page 24 SCADAS Mobile & Recorder - User Manual Type Number elements and their meaning Additional information and related topics Simcenter SCADAS Mobile (SCM) and Simcenter SCADAS Recorder (SCR) are Hardware family hardware products within the Simcenter SCADAS family. System type Whether a system is an SCM or an SCR is determined by the type of System Controller module.
Page 25 Frames with enhanced ingress protection  MAIN FRAMES Main frames are available for both Simcenter SCADAS Mobile and Simcenter SCADAS Recorder systems. They have distinctive Type Numbers: a Mobile main frame has an SCM Type Number; a Recorder main frame has an SCR Type Number.
Page 26 Further details are described elsewhere: refer to Ingress Protection (IP) levels. FRAME SIZES The frame size of a Simcenter SCADAS Mobile & Recorder is determined by the number of free slots (the element nn within the Type Number). The higher the number of free slots the higher the maximum number of I/O modules that the frame can contain.
Page 27 Chapter 3 System description Simcenter SCADAS Mobile and Simcenter SCADAS Recorder – frame sizes Version 2.12...
Page 28 SCADAS Mobile & Recorder - User Manual SINGLE-FRAME AND MULTI-FRAME CONFIGURATIONS The Simcenter SCADAS Mobile & Recorder support different test configurations, provided that the main frame in a particular test configuration has the required combination of system modules and I/O modules.
Page 29 The figure below shows one typical main frame arrangement for the purpose of module recognition. Information about the individual modules is described in the paragraphs that follow. Simcenter SCADAS Mobile and Simcenter SCADAS Recorder – typical main frame configuration Note: In a standard main frame configuration the SYSCON module is located in the top-slot close to the PSU.
Page 30 SCADAS Mobile & Recorder - User Manual SYSCON MODULES The primary tasks of a SYSCON module are to act as main controller of a system and to transmit data as fast as possible. Beside these tasks the SYSCON module can accommodate other functions that are relevant for specific test configurations that need to be supported.
Page 31 Chapter 3 System description SYSCON MODULE USED IN SCM2xx SCM2Exx SCM2xxV SCM2ExxV SCM2xxV-RB SCM2ExxV-RB SCR2xx SCR2Exx SCR IP54 Version 2.12...
Page 32 SCADAS Mobile & Recorder - User Manual Details about the individual front connections and their functions are described in the paragraphs that are listed below; details of LEMO connectors are given where applicable. Ethernet connectivity  Tacho and IRIG-B in/OUTputs ...
Page 33 Chapter 3 System description ETHERNET CONNECTIVITY Each main frame is equipped with a USB to Ethernet adapter to enable data transmission to and communication with the host PC. Physical connection is established with an Ethernet cable (standard accessory). The type of Ethernet connection on the SYSCON module and the applicable communication speed depend on the Type Number.
Page 34 SCADAS Mobile & Recorder - User Manual TACHO AND IRIG-B IN/OUTPUTS A Tacho input is used to capture RPM signals and can be used in two modes: analog or digital. Physical connection is established with LEMO to BNC adapter-cables (standard accessory). An IRIG-B timecode input is used for sampling clock and time-of-day synchronization.
Page 35 Chapter 3 System description GENERATOR OUTPUTS A SYSCON module supports two generator outputs, either via: two separate BNC connectors;  physical connection is established with standard BNC to BNC cable, one LEMO connector;  physical connection is established with a LEMO to BNC adapter-cable (standard accessory). OUT connections are described below.
Page 36 SCADAS Mobile & Recorder - User Manual CAN-BUS INPUT A SYSCON module can be equipped with a CAN-bus input that supports the high speed CAN protocol. Physical connection is established with a LEMO to 9-pin SUB-D adapter-cable (standard accessory). The CAN-bus interface is designed to operate in “listen only” mode by default. This means that it will read any messages that are transmitted on an existing CAN bus.
Page 37 Chapter 3 System description STOP INPUT A SYSCON module that supports Vibration Control (VIBCO) is equipped with a STOP input. A typical use for this input for instance is an Emergency Stop source (DSCU). Physical connection is established with a LEMO to BNC adapter cable (standard accessory). STOP connections are described below.
Page 38 SCADAS Mobile & Recorder - User Manual RECORDING FEATURES A SYSCON module that supports recording of measurement data is equipped with either Bluetooth or WLAN (SYSCON 4 only) connectivity, a Compact Flash card interface and a REC button. Bluetooth or WLAN connection is established with an antenna (standard accessory). Please note that the WLAN connection is of the dual band type, requiring the dual band antenna that has been delivered with your product and has been marked as such: 2.4GHz-5GHz...
Page 39 Chapter 3 System description SYSCON FEATURE DETAILS REMARKS Bluetooth connectivity. Connector type: SYSCON WLAN connectivity. Connector type: SYSCON 4 Compact Flash. Supported types (these also support DMA mode):  Transcend 128GB 1000x TS128GCF1000  Transcend 64GB 1000x SCR IP54 TS64GCF1000 ...
Page 40 SCADAS Mobile & Recorder - User Manual POWER SUPPLY UNIT AND BATTERIES The primary task of the Power Supply Unit (PSU) and batteries is to provide the required electrical power for the equipment in the frame and if necessary to connected sensors as well. The PSU has a DC IN connection to receive power from an external DC source.
Page 41 Chapter 3 System description PSU FEATURE DESCRIPTION PSU front (PS12-2 and PS12-3) PSU front (SPM50) PSU front (SPM80) DC IN connection to receive power from an external source. For more information see: Power requirements and details. On / OFF button. LEFT: Power indicator.
Page 42 SCADAS Mobile & Recorder - User Manual POWER REQUIREMENTS AND DETAILS The Simcenter SCADAS Mobile & Recorder have a DC power input that is 11~42V tolerant. For AC mains operation, the instrument comes with an AC/DC adapter (standard accessory) that is 90~240VAC and 50~60Hz tolerant.
Page 43 Chapter 3 System description Please check your system for indication of SPM50 or SPM80 on the front plate or check the power supply type using SCADAS Diagnostics)"Using the ON / OFF button on the PSU prevails over the function Remote ON / OFF switching. In case the PSU was controlled by Remote ON / OFF switching, and the ON / OFF button is used to: switch on the PSU, the function Remote ON / OFF switching is disabled,...
Page 44 SCADAS Mobile & Recorder - User Manual BATTERY LIFE The Simcenter SCADAS Mobile & Recorder is equipped with one or two Li-Ion battery packs to enable autonomous operation for a certain period of time. The autonomy period depends on different operational aspects, such as: The number of battery packs ...
Page 45 Chapter 3 System description STATUS INDICATIONS The top part of the PSU front provides two types of indications (see figure below): Top LEFT: Power indicator. Top RIGHT: Battery status indicators. Power indicator Off: instrument switched OFF; no external power. Yellow flashing: instrument switched OFF; external power supplied; battery is charging.
Page 46 Require min. 30% battery capacity for safe DAC shutdown. • In typical setups, Simcenter SCADAS Mobile frames are permanently connected to mains power, resulting in a gradual decrease of battery capacity: After a long period without cycling the battery, the battery capacity can drop below 30%;...
Page 47 Chapter 3 System description  1x 1m power cable to interconnect UPS to SCM-V Power input The SCM-UPS consists of a unit that monitors mains AC power and a unit with an internal power buffer. When mains AC power is interrupted, the SCM-UPS interrupts the normally closed (NC) circuit to the DAC Shutdown Control Unit (DSCU) and shuts down the DAC.
Page 48 SCADAS Mobile & Recorder - User Manual SCM-UPS specifications Input voltage rating 120/230 VAC, 50/60 Hz AC mains supply voltage fluctuations Up to ±10 % of the nominal voltage Fuse 5A (slow) Overvoltage category Input current at rated input voltage 120 V 2.34 A Input current at rated input voltage 230 V 1.36 A...
Page 49 Chapter 3 System description SCX-DSCU-II: DAC SHUTDOWN CONTROL UNIT FOR VIBRATION CONTROL APPLICATIONS NC/NO connector NC loopback plug The SCX-DSCU-II unit, when used in combination with a SCADAS front-end supporting vibration control functionality, allows the user to initiate a controlled shutdown of the excitation source during a vibration control campaign.
Page 50 SCADAS Mobile & Recorder - User Manual MULTI-FRAME INTERFACE MODULE The primary task of a Multi-Frame interface module is to enable communication between a main frame and one or more secondary frames. This type of communication is required to achieve multi- frame configurations.
Page 51 Chapter 3 System description FEATURE DESCRIPTION Switch to set the frame in Main or Secondary mode. In a single-frame configuration – and a Multi-Frame interface module is installed – this switch must be set to M. In a multi-frame configuration only one main frame can operate in main mode.
Page 52 The most complete architecture is shown here. SYSTEM ARCHITECTURE The concept of the Simcenter SCADAS Mobile & Recorder is built around an internal bus that provides all internal communication. It is designed for versatility and high speed data transfer in order to deliver guaranteed performance irrespective of the large variety of combination of modules.
Page 53 Chapter 3 System description FUNCTIONAL DESCRIPTION A Simcenter SCADAS Mobile & Recorder frame operates on external DC power – either with or without an AC/DC adapter – or on internal battery power. The required software settings for system, test and I/O behavior are determined by the application on the host PC. These settings are communicated and processed via the SYSCON main processor.
Page 54 Stand-alone mode FRONT-END MODE In front-end mode the Simcenter SCADAS Mobile or Simcenter SCADAS Recorder is connected to a host PC that has Simcenter Testlab or Simcenter Testxpress installed. Connection is established over LAN via Ethernet. Simcenter Testlab or Simcenter Testxpress will be in full control during data acquisition.
Page 55 Chapter 4 COMPONENT DESCRIPTION Version 2.12...
Page 56 The Simcenter SCADAS Mobile & Recorder can be equipped with a large variety of I/O modules. The choices for I/O modules that are used in a system depend on the specific needs of the user and the software application that a particular module must support.
Page 57 Chapter 4 Component description COMPONENT OVERVIEW The list below contains titles of sections and sub-sections to help the user find the required module- related information quickly. IN THIS CHAPTER: Component overview (this section)  Functions of analog input modules (overview) ...
Page 58 SCADAS Mobile & Recorder - User Manual FUNCTIONS OF ANALOG INPUT MODULES This part gives information about analog input modules. Most analog input modules support various channel functions that are software configurable; some modules offer specific and dedicated channel functions. Configuration is done in the Application software of Simcenter Testlab or Simcenter Testxpress.
Page 59 Chapter 4 Component description FUNCTIONS OF ANALOG OUTPUT MODULES This part gives information about analog output modules. All of these modules offer specific and dedicated channel functions. The table below gives an abstract of the channel function of each I/O module. Click on a function type number...
Page 60 SCADAS Mobile & Recorder - User Manual ANALOG INPUT – VOLTAGE The group of analog input modules is the largest group within the range of I/O modules and is divided in a number of sub-groups. Most of these modules can support several functions, while some are designed to support more specific functions.
Page 61 Chapter 4 Component description SINGLE-ENDED V/ICP INPUT Functional description The diagram below shows the basic functionality for one connection that is configured as single- ended voltage input. From left to right the elements shown represent: external I/O,  analog signal conditioner, ...
Page 62 SCADAS Mobile & Recorder - User Manual The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 4 x BNC connector. 8 x CAMAC connector. 8 x CAMAC connector. 8 x BNC connector. 8 x CAMAC connector.
Page 63 Chapter 4 Component description DIFFERENTIAL V/ICP INPUT Functional description The diagram below shows the basic functionality for one connection that is configured as differential voltage input. From left to right the elements shown represent: external I/O,  analog signal conditioner, ...
Page 64 SCADAS Mobile & Recorder - User Manual The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 8 x isolated CAMAC connector. 8 x BNC connector. 1 x Sub-D connector, 37-pin. Other modules that basically support this function are: VD8MO-E ...
Page 65 Chapter 4 Component description SEMI-DIFFERENTIAL VOLTAGE INPUT Functional description The diagram below shows the basic functionality for one connection that is configured as semi- differential voltage input. From left to right the elements shown represent: external I/O,  analog signal conditioner, ...
Page 66 SCADAS Mobile & Recorder - User Manual The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 8 x 9-pin LEMO connector. Connection details are described below. 1 x multi-pole connector, 68-pin. Optional accessories are available. 8 x 9-pin LEMO connector.
Page 67 Chapter 4 Component description ANALOG INPUT – CHARGE The group of analog input modules is the largest group within the range of I/O modules and is divided in a number of sub-groups. Most of these modules can support several functions, while some are designed to support more specific functions.
Page 68 SCADAS Mobile & Recorder - User Manual A connection of this module can be configured to support either a Single-ended Charge input or a Single-ended V/ICP input. This can be done by means of a set of software-selectable switches (Sw and Sw’).
Page 69 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS VC8-E 8 x industry standard 10-32 Microdot connector. The connectors of this module are fitted with neoprene rings. Make sure these rings do not come off and replace them if necessary.
Page 70 SCADAS Mobile & Recorder - User Manual DIFFERENTIAL CHARGE INPUT Functional description The diagram below shows the basic functionality for one connection that is configured as differential charge input. From left to right the elements shown represent: external I/O,  analog signal conditioner, ...
Page 71 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 4 x 2-pin LEMO connector. Connection details are described below. Other modules that basically support this function are: None. ...
Page 72 SCADAS Mobile & Recorder - User Manual ANALOG INPUT – MICROPHONE The group of analog input modules is the largest group within the range of I/O modules and is divided in a number of sub-groups. Most of these modules can support several functions, while some are designed to support more specific functions.
Page 73 Chapter 4 Component description For certain types of microphones (e.g. conventional microphones) it is required to use the dedicated microphone pre-amplifier supply and an accurate polarization voltage. Next signal conversion takes place; this basically consists of an anti-alias filter and an analog-to-digital converter.
Page 74 SCADAS Mobile & Recorder - User Manual ANALOG INPUT – THERMOCOUPLE The group of analog input modules is the largest group within the range of I/O modules and is divided in a number of sub-groups. Most of these modules can support several functions, while some are designed to support more specific functions.
Page 75 Chapter 4 Component description Key features and physical appearance The primary modules that support this function are: T8, T8-RT  The T8 module provides thermocouple conditioning with galvanic isolation. It supports analog inputs for thermocouple types B, E, J, K, N, R, S and T. Thermocouple types are software-selectable per channel.
Page 76 SCADAS Mobile & Recorder - User Manual ANALOG INPUT – BRIDGE FUNCTIONS The group of analog input modules is the largest group within the range of I/O modules and is divided in a number of sub-groups. Most of these modules can support several functions, while some are designed to support more specific functions.
Page 77 Chapter 4 Component description BRIDGE INPUT – VOLTAGE SUPPLY Functional description The diagram below shows the basic functionality for a set of connections that are configured as bridge input for voltage sources. From left to right the elements shown represent: external I/O ...
Page 78 SCADAS Mobile & Recorder - User Manual VB8-II, VB8II-RT, VB8III-RT, DB8-II, DB8III, DB8A, DB8B, DB8C, DB8IIIC.  Version 2.12...
Page 79 Chapter 4 Component description The table below shows which key features are supported by these modules and points out the main differences between them. More detailed information is described in the relevant Product Information Sheet. FEATURE VB8-II/III DB8-II/III DB8A DB8B DB8C/ IIIC Analog to digital conversion:...
Page 80 SCADAS Mobile & Recorder - User Manual The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS VB8-II: 8 x 7-pin LEMO connector. Connection details are described below. VB8III-RT: 8 x 7-pin LEMO connector. Connection details are described below.
Page 81 Chapter 4 Component description BRIDGE INPUT – DYNAMIC STRAIN Functional description The diagrams below show the basic functionality for two possible set-ups. The first shows a set of connections that are configured as Bridge input with voltage supply; the second shows a set-up with a single strain sensor (gage) for Dynamic strain with current supply.
Page 82 SCADAS Mobile & Recorder - User Manual In this set-up the module functions in AC Dynamic-strain mode. The external I/O can be any type of two-wire strain sensor (gage) that connects directly to the module. Signal conditioning basically consists of a balanced current supply, an AC filter per incoming line and input-range selection by a programmable amplifier.
Page 83 Chapter 4 Component description CONNECTION DETAILS REMARKS BDS4-E 6-pin LEMO: Connector type: Mating connector: channels 1 to 4 LEMO-ERA.1S.306 LEMO-FFA.1S.306.CLACxx Pin details: 1) +V supply 2) -V sense 3) +V IN 4) -V IN 5) -V shunt Chassis = Analog Ground 6) -V supply VBDS4-RT 8-pin LEMO: Connector type:...
Page 84 SCADAS Mobile & Recorder - User Manual ANALOG OUTPUTS The group of analog output modules consists of modules with a particular purpose; most of these modules are designed to support specific functions. A complete overview of the groups and sub- groups of modules is given at the beginning of this chapter;...
Page 85 Chapter 4 Component description Key features and physical appearance The primary modules that support this function are: DAC4  The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 4x BNC connector. Other modules that basically support this function are: SYSCON DAC ...
Page 86 SCADAS Mobile & Recorder - User Manual MAPPED MONITORING OUTPUTS Functional description The diagram below shows the basic functionality for one mapped output connection of an Analog output module. From left to right the elements shown represent: external I/O,  analog signal conditioner / buffer, ...
Page 87 Chapter 4 Component description Key features and physical appearance The primary modules that support this function are: AO16.  The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 1x Sub-D connector, 37-pin. Delivered with a breakout box.
Page 88 SCADAS Mobile & Recorder - User Manual MONITORING OUTPUT Functional description The diagram below shows the basic functionality for one connection that is configured as differential voltage input with monitoring output. From left to right the elements shown represent: external I/O, ...
Page 89 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 8x isolated CAMAC connector (IN). 8x CAMAC connector (OUT). Other modules that basically support this function are: None.  Version 2.12...
Page 90 SCADAS Mobile & Recorder - User Manual DIGITAL I/O MODULES The group of digital input/output modules consists of modules with a particular purpose; these modules are designed to support specific functions. A complete overview of the groups and sub- groups of modules is given at the beginning of this chapter; see Component overview. IN THIS SECTION: SPDIF –...
Page 91 Chapter 4 Component description The external I/O is an SPDIF source. Signal conditioning consists of voltage conversion to obtain the correct level for the SPDIF receiver. The SPDIF receiver converts the incoming bit stream into digital samples. Next the sample-rate converter synchronizes the digital samples to the ADC sample rate. The synchronized signal is offered to the DSP for digital processing.
Page 92 SCADAS Mobile & Recorder - User Manual CAN BUS INTERFACE Functional description The diagram below shows the basic functionality for one digital input connection of a CAN interface module. From left to right the elements shown represent: external I/O,  digital signal conditioner, ...
Page 93 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 2x Sub-D connector, 9-pin. Connection details are described below. 2x Sub-D connector, 9-pin. Connection details are described below. Other modules that basically support this function are: SYSCON CAN interface ...
Page 94 SCADAS Mobile & Recorder - User Manual FLEXRAY INTERFACE Functional description The diagram below shows the basic functionality for one digital input connection of a FlexRay interface module. From left to right the elements shown represent: external I/O,  digital signal conditioner, ...
Page 95 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 2x Sub-D connector, 9-pin. Connection details are described below. Other modules that basically support this function are: None.  CONNECTION DETAILS REMARKS...
Page 96 SCADAS Mobile & Recorder - User Manual WHEEL-FORCE SENSOR INTERFACE Functional description The diagram below shows the basic functionality for one digital input connection of a Wheel-Force sensor interface module. From left to right the elements shown represent: external I/O, ...
Page 97 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 2 x LEMO connector, 8-pin. Connection details are described below. 2 x CAMAC connector. One for a lock (CLK) input. One for a Trigger (TRG) input.
Page 98 SCADAS Mobile & Recorder - User Manual ROTATIONAL VIBRATION MODULE Functional description The RV4 input module is a signal conditioner for low speed and high speed tacho channels from analog sources, digital sources. It also supports incremental encoders. The following 3 combinations of inputs are supported for concurrent use: Up to four tacho inputs ...
Page 99 Chapter 4 Component description In Incremental Encoder mode the input comes from an incremental rotary encoder quadrature output. The output of the dedicated signal conditioner is a dual pulse quadrature signal and a one pulse per period reference signal. The dual pulse and reference signal are offered to the Incremental Encoder (IE) edge detector for signal conversion.
Page 100 SCADAS Mobile & Recorder - User Manual CAMERA INTERFACE MODULE Functional description The diagram below shows the basic functionality for one digital input connection of a Camera Interface module. From left to right the elements shown represent: external I/O,  Ethernet PHY, ...
Page 101 Chapter 4 Component description The table below shows the physical appearance of the primary modules in this group. MODULE FRONT DETAILS 2 x LEMO connector, 8-pin. Connection details are described below. Other modules that basically support this function are: None. ...
Page 102 ETHERCAT INTERFACE MODULE Functional description The EtherCAT interface module ESO64 enables the Simcenter SCADAS Mobile front-end to communicate and send out measurement data on an EtherCAT bus. The ESO64 will present itself as an EtherCAT slave device, meaning that it will require an external EtherCAT master device in order to function and communicate properly.
Page 103 The Simcenter SCADAS Satellite System consists of a one (1) slot wide Simcenter SCADAS Satellite Interface Module (SCM-SAT1-IP) installed in the Simcenter SCADAS Mobile frontend and one (1) IP67 certified Simcenter SCADAS Satellite Device (SCS-B12 or SCS-V12) for remote sensor connectivity.
Page 104 SCADAS Mobile & Recorder - User Manual CONNECTIVITY Input Identification There are two ways to identify if a Simcenter SCADAS Satellite Device is having Bridge or a Voltage/ICP inputs. Each satellite has two coloured dots at the top of the housing. The Bridge satellite has two green dots;...
Page 105 Chapter 4 Component description For quarter bridge operation we strongly recommend not to use the supply sense lines and short them in the mating LEMO connector To short the sense lines at the connector connect pin 5 to pin 6 and pin 7 to pin 8. SATELLITE CONNECTION CABLE Cables to connect the Simcenter SCADAS Satellite Interface Module to the Simcenter SCADAS Satellite Device are available in 5m, 10m and 50m lengths.
Page 106 SCADAS Mobile & Recorder - User Manual ERROR DETECTION AND INDICATION The two colours LED on the SCM-SAT1 module provides information on the connection and synchronization status, as well as any sensor supply overload/under loads status. The Satellite Devices themselves detect and report signal overloads and sensor supply overloads or under loads.
Page 107 Chapter 4 Component description Error Description Signal out of The input level is near or above the input limits. range Bridge supply The bridge supply has been turned off because the connected bridge was drawing too overload much current. Sensor supply The sensor supply has been turned off because the connected sensor was drawing too overload much current.
Page 108 SCADAS Mobile & Recorder - User Manual TROUBLESHOOTING Status / Error Impact of error What to do in What to do in What to do in condition condition hardware software software Simcenter Simcenter Durability Testlab Control Acquisition No link – this Not possible to Plug in the satellite Push Arm as soon...
Page 109 Chapter 4 Component description SPECIFICATIONS Version 2.12...
Page 110 SCADAS Mobile & Recorder - User Manual SCS-B12 SCS-V12 SPECIFICATION SIMCENTER SCADAS SATELLITE 12 SIMCENTER SCADAS SATELLITE 12 CHANNEL CHANNEL BRIDGE DEVICE V/ICP DEVICE Number of Inputs Sensor 10-pin LEMO 2K vacuum tight Connector Type HGG.2K.310.CLNP (FYG 2K 310.CLA30ZN used for sensor connectivity) Sensor support Strain gages: Voltage/Potentiometer/ICP/TEDS...
Page 111 Chapter 4 Component description SCS-B12 SCS-V12 SPECIFICATION SIMCENTER SCADAS SATELLITE 12 SIMCENTER SCADAS SATELLITE 12 CHANNEL CHANNEL BRIDGE DEVICE V/ICP DEVICE Sensor Power 12x full/half 350Ω bridges at 5V supply 2.7mA max current/sensor from a 19 V supply Budget 12x full/half 120Ω bridges at 2.5V supply 2.5W max./satellite or any combination 2.5W max./satellite...
Page 113 Chapter 5 OPERATION Version 2.12...
Page 114 User Manual This chapter gives information about the operation of the Simcenter SCADAS Mobile & Recorder. The purpose of this chapter is to guide the user to use the Simcenter SCADAS Mobile & Recorder correctly, safely and effectively. IN THIS CHAPTER: Prerequisites and considerations ...
Page 115  INSTRUMENT GROUNDING The Simcenter SCADAS Mobile & Recorder are Class A instruments. This means that it is safe to operate the instrument under all conditions, provided the end-user takes care of proper grounding to the instrument, independent of either an AC or DC power source. Proper grounding is essential, not only from a safety point of view but also to control and prevent ground loops.
Page 116 User Manual COOLING REQUIREMENTS The heat management of the Simcenter SCADAS Mobile & Recorder is designed to enable operation without the help of a cooling fan. Most of the internally dissipated energy is thermally conducted to the case and the cooling ribs at the back of the instrument.
Page 117 Operation PREPARE FOR FRONT-END OPERATION In front-end mode the Simcenter SCADAS Mobile or Simcenter SCADAS Recorder is connected to a host PC that has Simcenter Testlab or Simcenter Testxpress installed. Connection is established over LAN via Ethernet. Simcenter Testlab or Simcenter Testxpress will be in full control during data acquisition.
Page 118 SCADAS Mobile & Recorder User Manual Note: The application program Simcenter Testxpress supports the so-called ‘Compact Flash parallel mode’ when an Simcenter SCADAS Recorder is connected. In this special front-end mode a back-up of the measurement can be recorded onto the Compact Flash card of the Recorder. Version 2.12...
Page 119 It is essential to use cables with the correct wire gage. It is strongly recommended that you only use accessories delivered by Siemens. In this part Simcenter Testlab and Simcenter Testxpress are addressed as ‘the application program’.
Page 120 SCADAS Mobile & Recorder User Manual PREPARE THE RECORDER To prepare an Simcenter SCADAS Recorder for stand-alone operation do these steps: 1) Make sure that: power is provided,  on the host PC the application program is not yet running, ...
Page 121 Chapter 5 Operation PREPARE THE TEMPLATE To make a recording in stand-alone mode the Simcenter SCADAS Recorder must have a Compact Flash (CF) card inserted with a valid template on it. Important: In case multiple templates are on the CF card, the Simcenter SCADAS Recorder will use the file that is considered ‘first’.
Page 122 SCADAS Mobile & Recorder User Manual GUIDELINES FOR STAND-ALONE OPERATION This part provides basic guidelines to enable correct stand-alone operation of an Simcenter SCADAS Recorder. These guidelines apply: Make sure that the required preparations have been done; see the previous paragraphs. ...
Page 123 Chapter 5 Operation About GNSS (including GPS) and IRIG-B operation:  the Recorder operates in GNSS mode by default,  in case GPS tracking is required and configured, IRIG-B operation is not possible,  in case IRIG-B operation is required and configured, GPS tracking is not possible, ...
Page 124 1. Connect cable from UPS DC out to Simcenter SCADAS Mobile power input connector 2. Connect the splitter cable from UPS Power Fail (NC) out to the DSCU 3. Connect the other end of the splitter cable to the Simcenter SCADAS Mobile STOP connection on the SYSCON module...
Page 125 Chapter 5 Operation Next, disable the battery check in Simcenter Testlab Environmental Control. In your local configuration folder, edit the TestLabEnvironmental.ini file: [Mobile] CheckBattery=OFF Note: this feature is supported in Simcenter Testlab 17A and later releases; it will not work in versions prior to Simcenter Testlab 17A.
Page 126 SCADAS Mobile & Recorder User Manual Version 2.12...
Page 127 CONNECTING TRANSDUCERS This section gives information about specific (types of) transducers and best practices how to connect them. These best practices are proven in use and recommended by Siemens. Notes: It is assumed that you have taken the appropriate preparations as described in this chapter;...
Page 128 SCADAS Mobile & Recorder User Manual ICP TRANSDUCERS This part provides advised methods and relevant details for connection of ICP transducers. General information ICP (Integrated Circuit Piezoelectric) transducers, also called Piezotron™, Isotron™ or Deltatron™, are IEPE piezoelectric sensors with an integrated amplifier. This amplifier, powered by a constant current supply, converts the high impedance charge signal from a piezoelectric crystal or microphone membrane to a low impedance voltage signal.
Page 129 Chapter 5 Operation CHARGE TRANSDUCERS This part provides details with respect to I/O modules of type: VC8-E (single-ended charge input). The Microdot connectors of this module are fitted with neoprene rings; see figure on the left. Make sure these rings do not come off and replace them if necessary.
Page 130 Kistler RoaDyn® System 2000 with Interface card 5621A6Q1 (Ethernet interface).  Version VC33 is supported. Simcenter SCADAS Mobile or Simcenter SCADAS Recorder with WFI2 interface card.  Cables for clock, trigger and Ethernet connection (cables are delivered with the WFI2 module).
Page 131 Make sure that the RoaDyn® Remote Control displays the online values of a wheel,  but does not show the remote control in setup mode. Boot the Simcenter SCADAS Mobile or Simcenter SCADAS Recorder.  Start the Simcenter software application.
Page 132 SCADAS Mobile & Recorder User Manual Minimal software requirements Software – a recent version of Simcenter Testlab or Simcenter Testxpress.  Firmware – see steps below.  User controllable settings – see steps below.  All steps below relate to the Kistler RoaDyn® System 2000. 1) Do a visual check on the Printed Circuit Board (PCB): Module details: SDSP Baseboard.
Page 133 Chapter 5 Operation 2. In the Diagnostics screen (see below) make this selection:  Interface. 3. In the presented list (see below) do a check of these entries:  Version;  DSP Type;  IP-Adr. 4. If necessary, do the steps below to reset the IP-address: 1.
Page 134 SCADAS Mobile & Recorder User Manual CONNECT STRAIN GAGES TO BRIDGE INPUTS (V-SUPPLY) This part provides advised methods and relevant details for connection of strain gages to modules that support bridge inputs (voltage supply), being: VB8-II, VB8-III, DB8-II, DB8-III, DB8A, DB8B, DB8C, DB8-IIIC.
Page 135 Chapter 5 Operation FULL BRIDGE CONNECTION: 6 WIRE OR 4 WIRE From a pure measurement point of view, the full bridge is always the preferred configuration, even if you don’t have an active full bridge and the number of active gages is less than four. On the other hand, the full bridge is also the least practical of strain gage configurations, in terms of installation time.
Page 136 SCADAS Mobile & Recorder User Manual HALF BRIDGE CONNECTION: 5 WIRE OR 3 WIRE The half bridge configuration works best with two active gages, but is often used with one active gage and one “passive” gage for compensation purposes. The half bridge configuration offers two important advantages: Full compensation of voltage loss over power lines through the use of sense lines.
Page 137 Chapter 5 Operation QUARTER BRIDGE CONNECTIONS The single gage quarter bridge mode is the most common bridge mode. The positive supply sense line (pin 2) is optional and will generally not be used in practical scenarios. The modules offer two values for the internal completion resistor: 120Ω...
Page 138 SCADAS Mobile & Recorder User Manual Quarter bridge: 4 wire (DB8IIIC and VB8III-RT only) To compensate the measurement error for a quarter bridge configuration caused by sensitivity loss due to temperature dependent cable resistance a four wire quarter bridge can be used. 2: +Vsense 1: +Vsupply Cable...
Page 139 Chapter 5 Operation CONNECT OTHER SENSORS TO BRIDGE INPUTS (V-SUPPLY) This part provides advised methods and relevant details for connection of other types of sensors (than strain gages) to modules that support bridge inputs (voltage supply), being: VB8-II, VB8III-RT, DB8-II, DB8III, DB8A, DB8B, DB8C, DB8IIIC. Next to bridge type sensors such as strain gages, these modules allow connection of potentiometers, active sensors, ICP sensors and voltage sources.
Page 140 SCADAS Mobile & Recorder User Manual ACTIVE SENSOR CONNECTIONS Differential Single ended 4–20mA 1: +14V3 cable 3: +In 4: -In Shield (GND) 4-20mA sensors can be connected to the input provided that the SCx-CAS10 cable is used. This cable contains a high precision 82 Ω shunt resistor that converts the sensor current into a voltage. Version 2.12...
Page 141 Chapter 5 Operation Note: Be aware that in active sensor mode (both differential and single-ended) the positive power supply is a fixed +14.3 VDC. Version 2.12...
Page 142 SCADAS Mobile & Recorder User Manual DIFFERENTIAL VOLTAGE MODE CONNECTIONS SINGLE ENDED VOLTAGE / ICP / TEDS MODE CONNECTIONS Note: Be aware that for single-ended V/ICP/TEDS mode a different input signal pin is used (pin 7). LVDT – AC EXCITATION Note: Connection 1: +Vsupply and -V supply are powered by an AC source.
Page 143 Chapter 5 Operation DC ACCELEROMETERS There are three different underlying technologies for DC accelerometers: Capacitive DC accelerometers (mechanical)  Capacitive DC accelerometers (MEMS)  Piezoresistive DC accelerometers (MEMS)  The term “MEMS” stands for Micro Electro Mechanical System. CAPACITIVE DC ACCELEROMETERS (MECHANICAL) The principle of the mechanical capacitive DC accelerometer is depicted below: This is a mechanical structure, basically consisting of two fixed electrodes and two flexible electrodes.
Page 144 SCADAS Mobile & Recorder User Manual The two variable capacitors are placed in a classical Wheatstone bridge, and an AC bridge excitation is applied. The AC output (imbalance) of the bridge is filtered, resulting in a DC output of the sensor, representing the amount of acceleration.
Page 145 Chapter 5 Operation The module provides an active sensor supply of +14.3VDC and it can provide a maximum sensor supply current of 20mA (which are both OK for the 3701). Make sure to look at these two parameters, as they are crucial in deciding whether a sensor can be connected to the module in active sensor mode or not: required supply voltage and required supply current.
Page 146 SCADAS Mobile & Recorder User Manual Endevco 7290 series Another popular capacitive DC accelerometer is the Endevco 7290. The main difference between the 3701 and the 7290 is that the 7290 has a differential output, instead of a single-ended one. VB8-II, DB8-II and DB8C offer a dedicated input mode for this type of sensor: This is the so-called active sensor differential mode that is able (like the single-ended active sensor mode) to provide a +14.3VDC sensor supply at 20mA max.
Page 147 Chapter 5 Operation In this mode, the sensor supply ground is connected to the negative bridge supply voltage and the signal is picked up differentially. Kistler 8310 series The Kistler 8310 is again a typical example of a single-ended active sensor, and it can be connected to Simcenter SCADAS hardware in a similar way as the PCB 3701.
Page 148 SCADAS Mobile & Recorder User Manual CAPACITIVE DC ACCELEROMETERS (MEMS) A MEMS capacitive DC accelerometer principally works according to the same mechanism as a mechanical capacitive DC accelerometer, only now the mechanical structure is built on an electronic chip (silicon): The advantage of such an architecture is obvious, as both the conditioning electronics and the sensor itself can be located on the same chip.
Page 149 Chapter 5 Operation PCB 3711 series The 3711 can again be connected in both single-ended active sensor mode and “sensor with excitation single ended” mode, but depending on the type of 3711 there can be different output offsets at zero g. The one shown above is the 3711A, which has approx. 2.5V offset, but the 3711D will have no structural offset around its power/signal ground potential.
Page 150 SCADAS Mobile & Recorder User Manual PIEZORESISTIVE DC ACCELEROMETERS (MEMS) Silicon, being a crystal type of material, possesses certain properties that make it useful as a piezoresistive sensor material. When a force is applied to this sensor, as a result of acceleration, the resistive properties of the material change.
Page 151 Chapter 5 Operation Measurement Specialties 4600 (single axis) and 4630 (triax) series As the diagram shows, the internal architecture is clearly a full bridge, but the 4600 and 4630 have some output electronics. The most logical way to connect these sensors is in “sensor with excitation differential” mode, but the active sensor differential mode is also a possibility.
Page 152 SCADAS Mobile & Recorder User Manual Endevco 2262 series As the 2262 behaves as a passive full bridge, the preferred connection method for this sensor is “sensor with excitation differential”. Version 2.12...
Page 153 SUPPORT Thank you for consulting this User Manual. The content of this manual has been designed and written with the aim to support you, the user, in the day-to-day use of the Simcenter SCADAS Mobile & Recorder. In case you need specific information that is not described in this manual, please do not hesitate to contact your local Siemens representative for support.
Page 155 APPENDIX A – SPECIFICATIONS This part provides the technical specifications of the Simcenter SCADAS Mobile & Recorder. Here you can find the distinct features that the Simcenter SCADAS Mobile & Recorder offer, but also operational boundaries that apply. IN THIS APPENDIX: Ingress Protection (IP) levels ...
Page 156 SCADAS Mobile & Recorder - User Manual INGRESS PROTECTION (IP) LEVELS Electrical equipment is potentially hazardous for persons and sensitive to ingress of dust and moisture. Design and construction of equipment needs to be such that it offers sufficient protection: Against intrusion and accidental contact, ...
Page 157 Appendix B – Front panel indications APPENDIX B – FRONT PANEL INDICATIONS This part provides generic information about LED indications on the front panel of a Simcenter SCADAS Mobile & Recorder frame. Any type of module can have LED indicators depending on the type number.
Page 158 SCADAS Mobile & Recorder - User Manual LED INDICATIONS (ALL EXCEPT CAN AND TACHO) The table below gives relevant details about LED indications for all conditioning modules functionality except CAN and Tacho: MODULE(S) INPUT MODE STATUS COLOR All except V24(-II) V/ICP single ended Green V24(-II)
Page 159 Appendix B – Front panel indications LED INDICATIONS (FOR CAN) The table below gives relevant details about LED indications for CAN functionality: COLOR STATUS Green The CAN-bus is enabled; (active listener or passive / normal operation). An error-warning condition has occurred. Alternating When a bus error occurs, the LED will be set red for a duration of 200ms.
Page 161 APPENDIX C – HARDWARE CHECKS (Simcenter Testlab and Simcenter Testlab Control App) Version 2.12...
Page 162 SCADAS Mobile & Recorder - User Manual This appendix provides information on the different hardware checks and how they are visualized in the Simcenter Testlab and Simcenter Testlab Control App software. Description Simcenter Simcenter DB8II / Testlab Time Testlab Control DB8III / Data Acquisition VB8II /...
Page 163 Appendix D – Front-end configuration tool FeConfig is an internal tool for frontend configuration. The tool supports the following functionality:  Discovery of available front-end(s) in a network or direct connection to the computer.  Each discovered front-end will be assigned a unique TCP IP address and a name. ...
Page 164 SCADAS Mobile & Recorder - User Manual Command line arguments argument description format Perform a discovery. FeConfig -h or /? Help. FeConfig –h List configured network FeConfig –l segments. Add a network segment. FeConfig -a {first_addr} {last_addr} {net_mask} Set the network segment. FeConfig -s {first_addr} {last_addr} {net_mask} Export current list of FeConfig -e {text_file_name_to}...
Page 165 COPYRIGHT • 7 Remaining risks • 16 Safety precautions • 18 Safety provisions • 16 FEEDBACK • 155 SIEMENS INDUSTRY SOFTWARE - BREDA Mailto address • 155 Address • 7 SPECIAL FUNCTIONS PSU Remote On / OFF switching • 40 I/O MODULE FUNCTIONS TCK8 –...
Page 166 11-2020...

This manual is also suitable for:

Simcenter scadas recorder
