Liberty Pumps SX Series Installation Instructions And Operation Manual

A Family and Employee Owned Company
Parts Included
?
Call factory with servicing questions:
1-800-543-2550
Copyright © Liberty Pumps, Inc. 2023
Three-Phase Simplex
SX-Series Control Panel
SX34=3-131, SX34=3-141,
SX34=3-171, SX34=3-191,
SX34=3-511 and SX54=3-121
Manufactured by SJE-Rhombus
Installation Instructions
and Operation Manual/Troubleshooting
Float label sheet
Three each of the following:
• Floats
• Worm Clamps
• Pipe Mount Clamps
This control panel must be installed and serviced by a licensed electrician in
accordance with the National Electric Code NFPA-70, state and local electrical codes.
UL Type 4X enclosures are for indoor or outdoor use.
Warranty void if panel is modifi ed.
Liberty Pumps, Inc. off ers a three-year limited warranty.
For complete terms and conditions, please visit www.libertypumps.com.
Products returned must be cleaned, sanitized, or decontaminated as necessary
prior to shipment to ensure that employees will not be exposed to health hazards
in handling said material. All applicable laws and regulations shall apply.
Specifi cations subject to change without notice.
®
1038907B 02/23
7628000A P1
