- Page 2 USER’S MANUAL Children's Desk and Chair HY10013 THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Please give us a chance to make it right and do better！ FLOOR AREA 2MX1.5M Contact our friendly customer service department for help first.
-
Page 3: Before You Start
Contact Us! Do NOT return this item. Contact our friendly customer service department for help first. E-mail US: cs.us@costway.com UK: cs.uk@costway.com Before You Start Read each step carefully before starting. It is very important to ensure each step followed in correct order, otherwise assembly difficulties may occur. - Page 5 Removable...
- Page 7 STEP 1: Assemble the table according to the following figure. Use hardware #1, #2, #3 to connect the A1(x4) legs with the A3 frame. Check the illustration for more details.
- Page 8 STEP 2: Use hardware #4 to connect the A2 panel to the frame (completed in step 1).
- Page 9 STEP 3: Assemble the hutch according to the following figure. Use hardware #6 and Dowel #5 to connect the C6 panel to the C7 panel.
- Page 10 STEP 4: Use Dowel #5 to connect the C2 panel to the frame (completed in step 3).
- Page 11 STEP 5: Use hardware #6 and Dowel #5 to connect the C4 panel to the frame (completed in step 4).
- Page 12 STEP 6: Use hardware #6 and Dowel #5 to connect the C1 and C5 panels to the frame (completed in step 5).
- Page 13 STEP 7: Assemble Hutch and the table according to the picture below. Use hardware #14,#15 and Dowel #5 to connect the Frame (com- pleted in step 2) with the frame (completed in step 6).
- Page 14 STEP 8: Use hardware #7, #8 to connect Frame (completed in step 7)
- Page 15 STEP 9: Assemble the chair as shown below. Use hardware #9, #10, #11 to connect B3, B4 frame and B1 frame.
- Page 16 STEP 10: Use hardware #9, #10, #11 to connect B2 Frame to Frame (com- pleted in step 9).
- Page 17 STEP 11: Put the chair (completed in step 10) and drawer C8 in position. Put the removable panel C3 in position.
-
Page 18: Care And Maintenance
Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. Never use water to clean your furniture as it may cause damage to the finish. - Page 19 Welcome to visit our website and purchase our quality products! With your inspiring rating, COSTWAY will be more consistent to offer you EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE! US office: Fontana, California UK office: Ipswich Reward Points Exclusive Customer Service...
