INSTALLATION
& OPERATION
MANUAL
275/275AH/275ASH/
275AMH BEACON
PERMANENT, MAGNETIC MOUNT
IMPORTANT :
275 Beacon
12v MODELS
BEACONS
Contents:
Introduction ........................................................ 2
Unpacking & Pre-Installation .............................. 2
Installation & Mounting ....................................... 2
Magnetic Mounting ........................................... 3
Permanent Mounting ........................................ 3
Wiring Instructions ............................................ 5
Maintenance ....................................................... 6
Drill Template............................................................ 7
Warranty ............................................................. 8
Read all instructions and warnings before installing and using.
INSTALLER:
This manual must be delivered to the end user of this equipment.
Advertisement
Table of Contents
Related Manuals for Code 3 275
Summary of Contents for Code 3 275
-
Page 1: Table Of Contents
INSTALLATION & OPERATION MANUAL 275/275AH/275ASH/ 275AMH BEACON 275 Beacon 12v MODELS PERMANENT, MAGNETIC MOUNT BEACONS Contents: Introduction ............2 Unpacking & Pre-Installation ......2 Installation & Mounting ........2 Magnetic Mounting ........... 3 Permanent Mounting ........3 Wiring Instructions ..........5 Maintenance ............ -
Page 2: Introduction
Installation & Mounting The 275 Beacon may be mounted magnetically or permanently on the roof of the vehicle, or other mounting surface. Overall Size : 5.938 Dia. X 5.775 Tall. Magnetic Mount Models. -
Page 3: Magnetic Mounting
The 275 Magnetic Based Beacon provides a secure, temporary installation in most circumstances. The beacon should be placed in the center of the roof where the least amount of curvature occurs. The beacon should not be used on a vinyl covered roof. - Page 4 DRAIN SLOT TOWARD REAR OF VEHICLE SUPPLIED MOUNTING GASKET LIGHT BASE BOLT M6 VEHICLE PANEL TIGHTENING TORQUE: 5 lb-in SPRING WASHER NUT M6 .187in FEMALE CONNECTOR (-) 18-16 GA WIRE .250in FEMALE (WIRE NOT SUPPLIED) CONNECTOR (+) FIGURE 2...
-
Page 5: Wiring Instructions
275 Magnetic Mount Beacon - The 275 Beacon can be equipped with a cord that plugs into a 12 Volt D.C. cigarette lighter; rotate and push with reasonable moderate force which insures the best possible connection. -
Page 6: Maintenance
Do not oil or grease this unit. It is constructed with permanently lubricated bearings which do not need lubrication. Keep the unit clean by disassembling it and clearing any debris or dirt. Clean lens and base with mild soap and water, or CODE 3 lens polish using a soft cloth. The lens may be removed, and the ®... -
Page 7: Drill Template
Drill Template 5.125 120.0° 120.0° .250 .400 FIGURE 5 NOT TO SCALE... -
Page 8: Warranty
*Code 3, Inc. reserves the right to repair or replace at its discretion. Code 3, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products return to sender after the service has been rendered.
