Summary of Contents for Hisense HRVF170
- Page 1 HRVF170...
-
Page 3: Table Of Contents
Contents Safety and warning information...2 Using your appliance......14 Installing your new appliance....8 Helpful hints and tips......15 Reversing the door......9 Cleaning and care......16 Description of the appliance....12 Troubleshooting.......17 Display controls........13 Disposal of the appliance....18 Safety and warning information For your safety and correct usage, before installing and first using the appliance,read this user manual carefully, including its hints and warnings.To avoid unnecessary mistakes and accidents,it is important to make sure that all... - Page 4 concerning use of the appliance by a person being responsible for their safety. Children should be supervised to ensure that they do not ● play with the appliance. Keep all packaging away from children as there is a risk ● of suffocation.
- Page 5 are of the type recommended by the manufacturer. WARNING — The refrigerant and insulation blowing gas ● are flammable. When disposing of the appliance,do so only at an authorized waste disposal centre.Do not expose to flame. WARNING —When positioning the appliance,ensure the ●...
- Page 6 or ignition. Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal. If the refrigerant circuit should be damaged: -Avoid opening flames and sources of ignition. -Thoroughly ventilate the room in which the appliance is situated. It is dangerous to alter the specifications or modify this product in any way.
- Page 7 socket,do not pull on the cable. Do not place hot items near the plastic components of ● this appliance. Do not place food products directly against the air outlet ● on the rear wall. Store pre-packed frozen food in accordance with the ●...
- Page 8 Caution! Care and cleaning Before maintenance,switch off the appliance and ● disconnect the mains plug from the mains socket. Do not clean the appliance with metal objects,steam ● cleaner,ethereal oils,organic solvents or abrasive cleansers. Do not use a sharp objects instead of a plastic scraper ●...
-
Page 9: Installing Your New Appliance
Installing your new appliance avoid high moisture. Before using the appliance for the first Keep the appliance out of direct time, you should review the following ● tips. sunlight, rain or frost. Stand the Ventilation of appliance appliance away from heat sources such In order to improve efficiencyof as stoves, fires or heaters. -
Page 10: Reversing The Door
Reversing the door The side at which the door opens can be tapping screws which are used for changed, from the right side (as supplied) fixing the right upper hinge part by a to the left side, if the installation site 8mm socket driver or a spanner requires. - Page 11 5. Place it on a smooth surface with the adjustable bottom feet parts to its panel upwards. Loose screw another side and fixing it . and pard , then install them to the left side and tighten securely. 8. Transfer the door to the property position, adjust the lower hinge part, make the hinge axis into the lower hole of the door.
- Page 12 10.Install the screw hole cover on the top right corner of the refrigerator. Install the upper hinge cover (which is in the plastic bag) on the left corner. Put the other upper hinge cover into the plastic bag. Warning! When changing the side at which the door opens, the appliance must not be connected to the mains.
-
Page 13: Description Of The Appliance
Description of the appliance View of the appliance Control panel Lower drawer Wind channel Right adjustable bottom foot Flap Left adjustable bottom foot Middle drawers Note! Due to unceasing modification of our products, your appliance may be slightly ● different from this instruction manual, but its functions and using methods remain the same. -
Page 14: Display Controls
Display controls The control panel that controls the food will freeze faster. This can lock temperature inside the freezer in the vitamins and nutrients of fresh compartment is located inside the food and keep food fresh longer. freezer. Use your appliance ”... -
Page 15: Using Your Appliance
Door Alarm ●To save energy, please avoid keeping ●If the door of freezer is open for over 1 the door open for a long time when minutes, the door alarm will sound and using the appliance. The door alarm the indicator begin to flash. -
Page 16: Helpful Hints And Tips
Helpful hints and tips Energy saving tips It is recommended to label and date ● each frozen package in order to keep We recommend that you follow the tips track of the storage time. below to save energy. Try to avoid keeping the door open for ●... -
Page 17: Cleaning And Care
Cleaning and care For hygienic reasons the appliance wrung-out sponge or cloth. Wipe completely dry before replacing the (including exterior and interior shelves and drawers. Thoroughly dry accessories) should be cleaned all surfaces and removable parts regularly(at least every two months). before putting them back into place. -
Page 18: Troubleshooting
Troubleshooting If you experience a problem with your appliance or are concerned that the appliance is not functioning correctly, you can carry out some easy checks before calling for service,please see below. Warning! Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service engineer or the shop where you purchased the product. -
Page 19: Disposal Of The Appliance
Check that the air outlets are not blocked by food and ensure A layer of frost occurs food is placed within the appliance to allow sufficient in the compartment ventilation Ensure that door is fully closed To remove the frost please refer to the Cleaning and care” chapter “... - Page 20 To avoid contamination of food, please respect the following instructions: - Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. - Clean regularly surfaces that can come in contact with food and accessible drainage systems.
