Clean & Clear
Cartridge Filter System Owner's Manual
IMPORTANT SAFETY INSTRUCTIONS
SECTION II.
SECTION III.
SECTION IV.
SECTION V.
SECTION VI.
SECTION VII
SECTION VIII.
SECTION IX.
SECTION X.
SECTION XI.
1620 Hawkins Ave., Sanford, NC 27330 • Tel 919-566-8000 • Fax 919-566-8920
10951 West Los Angeles Ave., Moorpark, CA 93021 • Tel 805-553-5000 • Fax 805-553-5515
Before installing this product, read and follow all warning notices and instructions accompanying this
filter. Failure to follow safety warnings and instructions can result in severe injury, death, or property
damage. Call 1-888-263-7763 for free copies.
Rev. B 6/5/12
PUMP SAFETY INSTRUCTIONS.............................................2
HOW YOUR FILTER WORKS.................................................3
INSTALLATION..................................................................4
CLEANING THE FILTER........................................................6
WINTERIZING THE FILTER....................................................8
TROUBLESHOOTING............................................................9
PUMP INSTRUCTIONS.........................................................10
TECHNICAL DATA..............................................................12
Pentair Pool Products, Inc.
Important Notice
Attention Installer. This manual contains important information about the installation,
operation and safe use of this product. This information should be given to the owner/
operator of this equipment.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
WARNING
1
P/N 56269900

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Clean & Clear and is the answer not in the manual?

Questions and answers

Summary of Contents for Pentair Pool Products Clean & Clear

  • Page 1: Table Of Contents

    SECTION X. PUMP INSTRUCTIONS………………………………………………...10 SECTION XI. TECHNICAL DATA……………………………………………………..12 Pentair Pool Products, Inc. 1620 Hawkins Ave., Sanford, NC 27330 • Tel 919-566-8000 • Fax 919-566-8920 10951 West Los Angeles Ave., Moorpark, CA 93021 • Tel 805-553-5000 • Fax 805-553-5515 Important Notice Attention Installer.
  • Page 2: Read And Follow All Instructions

    SECTION I. PUMP SAFETY INSTRUCTIONS When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: 1. READ AND FOLLOW ALL INSTRUCTIONS. 2. WARNING - To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
  • Page 3: How Your Filter Works

    SECTION II. HOW YOUR FILTER WORKS WARNING To reduce the risk of electrical shock, only connect to a GFCI protected receptacle. Failure to do so could result in an electrical shock to pool users, installers, or others, which can result in serious personal injury or death. Your cartridge filter is designed to produce clear, sparkling water and operate for years with a minimum of maintenance when installed, operated and maintained in accordance with these instructions.
  • Page 4: Installation

    SECTION III. INSTALLATION To install this filter system, you will need the following simple tools – a screwdriver, pliers, and ½” wrench. 1. Carefully remove the equipment from the carton and check for any evidence of damage due to rough handling or shipping. If any of the equipment is damaged, immediately notify the organization where the equipment was purchased.
  • Page 5 Detail A Detail B Detail B Detail A Connector Hose Assy 170046 Connector Hose Assy 175015 Diagram 2 Diagram 3 (Installation of Dynamo Pump shown) (Installation of OptiFlo Pump Shown) READ AND FOLLOW ALL SAFETY INSTRUCTIONS...
  • Page 6: Initial Start-Up And Restart Instructions

    SECTION IV. INITIAL START UP AND RESTART INSTRUCTIONS. 1. Be sure all connections have been made and are secure. 2. Make sure the hair and lint pot of the pump is filled with water. (FAILURE TO FILL THE HAIR AND LINT POT WITH WATER WILL RESULT IN DAMAGE TO THE PUMP AND PUMP SEAL).
  • Page 7 5. Remove the hair and lint strainer pot lid and clean the basket. Replace the basket and secure the lid. 6. Remove the filter lock ring by depressing the two (2) spring loaded locking blocks and rotating the ring counter clockwise until the ring is free from the filter body. 7.
  • Page 8: Check Valve Installation Instructions

    SECTION VI. CHECK VALVE INSTALLATION INSTRUCTIONS INSTALLATION 1. Turn the pump off, shut off any automatic controls to assure that the system is not inadvertently started during servicing. 2. Open the High Flow manual relief valve. 3. Plug the suction line by inserting a rag into the skimmer port, or if equipped with a valve close it at this time to prevent water from siphoning from the pool during servicing.
  • Page 9: Cleaning The High Flow Manual Air Relief Valve

    8. See SECTION IV. INITIAL START-UP AND SYSTEM RESTART, when pool is ready to be opened for the season. SECTION VIII. CLEANING THE HIGH FLOW MANUAL AIR RELIEF VALVE 1. Turn the pump off and shut off any automatic controls to ensure that the system is not inadvertently started during servicing.
  • Page 10: Pump Instructions

    SECTION X. PUMP INSTRUCTIONS WARNING To reduce the risk of electrical shock, only connect to a GFCI protected receptacle. Failure to do so could result in an electrical shock to pool users, installers, or others, which can result in serious personal injury or death. 1.
  • Page 11 b. The motors used on these pumps are 48 frame through bolt motors. The through bolts are used to secure the volute to the motor. When replacing the motor, mark the end bells and the motor shell to indicate alignment. Remove the four nuts from the through bolts at the shaft end.
  • Page 12: Technical Data

    SECTION XI. TECHNICAL DATA FILTER AND BASE – REPLACEMENT PARTS Clean & Clear / Predator Filter Replacement Parts Item Part Number Description Quantity 98209800 High Flow Manual Relief Valve 190058 Pressure Gauge 178553 Lid, 50/100 Sq Ft Almond 178561 Lid, 75/150/175/200 Sq Ft Almond 59052900 Locking Ring Assy 87300400...
  • Page 13 Dynamo PUMP REPLACEMENT PARTS Item Part Number Description Quantity 356597 Motor, 1HP SPL, 1 Phase, 60 Hz, 115V 356595 Motor, 1 1/2HP SPL, 1 Phase, 60Hz, 115V 356469 Motor, 2HP SPL, 1 Phase, 60Hz, 115V 354632 Bracket, Diffuser, 3/4HP 354633 Bracket, Diffuser, 1HP, 1 1/2HP 354542 Square Nut No.
  • Page 14 OptiFlo PUMP REPLACEMENT PARTS Item Part Number Description Quantity 154699 Drain Plug 354545 Mechanical Seal 354552 Impeller 3/4HP, 1HP SPL 350017 Impeller 1 1/2HP SPL 192115 O-Ring, Drain Plug 357213 Volute 357255 O-Ring @-357 357227 357228 357239 Clamp, Cam & Ramp 357254 Square Nut, ¼-20 Stainless Steel 355667...
  • Page 15 CSA ENCLOSURE REPLACEMENT PARTS Item Part Number Description Quantity 354621 Body, Motor Enclosure 354881 Cap, Motor Enclosure 154716 Screw, No 10 Self Tapping 155371 Cord Assy, 25’ Long With Standard Plug and Plastic Bushing (P/N41412700) 155187 Switch, On/Off Toggle (CSA) 155193 Wire, 6”...
  • Page 16 1620 Hawkins Ave., Sanford, NC 27330 • (919) 566-8000 10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 553-5000 This document is subject to change without notice. Pentair Pool Products , Because reliability matters most , and Clean & Clear are trademarks and/or registered trademarks of Pentair ®...
  • Page 17: Mounting Base

    MOUNTING BASE FOR ABOVEGROUND PUMP & FILTER SYSTEMS BOABOVE INSTALLATION INSTRUCTIONS Kit Contents • AG systems mounting base (“the system base”) • Lag screws, #20 x 1-1/4” long • Lag screws, #20 x 2-1/2” long Tools needed Flathead regular screwdriver ½”...
  • Page 18 Introduction The Pentair Aquatic Systems Mounting Base for the Aboveground Systems for Pool and Filter Systems installation kit contains everything you need to configure and position the mounting base. Position the aboveground pool pump/filter system on a level area intended for use as the equipment pad for the pool.
  • Page 19 2. Slide the pump foot between the claw fasteners and the release latch. See Figure 2. Seat the pump by pushing down on it until the release latch clicks into place on the pump foot (see Figure 3). Release latch Claw fasteners Release latch Claw fasteners...
  • Page 20 Secure the filter tank foot The system base provides screw holes to align with the screw holes* in the foot of the filter tank. The system base supports the following filter models: PLM, PLD, PXC, PRC, PRD, Clean & Clear®, Warrior®, EasyClean™...
  • Page 21 Secure the filter tank foot (continued) 2. Refer to Figure 6 on the previous page, and to the table below to determine the correct screw for the hole pattern. Note: Each filter model will use either the #20 x 1-1/4” long or 2-1/2 long Lag screws, never both.
  • Page 22 Secure the pump 1. Complete the pump/filter connection by connecting the plumbing between the pump volute and the filter inlet. 2. Secure the pump foot to the system base by inserting two (2) #20 x 1-1/4 long Lag screws through the slots in the pump foot into the corresponding holes in the system base next to the release latch (See Figure 9).
  • Page 23 Removal WARNING! Risk of electrical shock or electrocution. 1. Make sure all electrical breakers and switches to the pump are turned off, and disconnect the communication cable from the pump before removing from the system base. Remove the pump 1. Disconnect the pump/filter connection. 2.
  • Page 24 1620 HAWKINS AVE., SANFORD, NC 27330 • [919] 566-8000 10951 WEST LOS ANGELES AVE., MOORPARK, CA 93021 • [805] 553-5000 WWW.PENTAIRPOOL.COM All Pentair trademarks and logos are owned by Pentair, Inc. Pentair Aquatic Systems™, PLM™, PLD™, PXC™, PRC™, PRD™, Clean & Clear®, Warrior®, and EasyClean™ are trademarks or registered trademarks of Pentair Water Pool and Spa, Inc. and/or its affiliated companies in the United States and/or other countries.
