Model No. WLTL42080
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
¨
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo WLTL42080
Summary of Contents for Weslo WLTL42080
- Page 1 Model No. WLTL42080 Serial No. Serial Number ¨ Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satis- faction through direct assistance from our factory.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN . - Page 3 14. Never start the treadmill while you are stand- THE TREADMILL on page 11.) You must be ing on the walking belt. Always hold the able to safely lift 45 pounds (20 kg) in order to handrails while using the treadmill. raise, lower, or move the treadmill.
-
Page 4: Before You Begin
The model youÕre not exercising, the unique LS30 can be folded number of the treadmill is WLTL42080. The serial up, requiring less than half the floor space of other number can be found on a decal attached to the tread- treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver , adjustable wrench , and scissors. - Page 6 4. Cut the indicated plastic tie from the Right Handrail (62). Next, feed the large wire tie and the Console Wire Harness (90) into the Right Handrail and out through the indicated bracket. Pull as much of the Console Wire Harness through the Right Handrail as possible.
-
Page 7: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT electric shock. This product is equipped with a cord having an equipment-grounding conductor and a Your treadmill features a walking belt coated with grounding plug. Plug the power cord into a surge PERFORMANT LUBE , a high-performance lubricant. -
Page 8: Console Diagram
CONSOLE DIAGRAM LED Track Displays Incline Display Program Indicators Manual Indicator Note: If there is a thin sheet of clear plastic on the face of the console, remove it. Pulse Sensor Clip Next, make sure that the key is removed from the con- CAUTION: sole and plug in the power cord (see HOW TO PLUG Before operating the... - Page 9 Note: There are two twenty-minute programs and Note: If the program is too difficult or too easy, the two thirty-minute programs. The graphs on the left difficulty level of the program can be adjusted. Press side of the console show how the speed of the the SPEED button.
- Page 10 ¥ DISTANCE/LAPS Measure your pulse, if desired. displayÑThis display shows the total dis- Stand on the foot rails and place your thumb on tance that you have the pulse sensor walked and the num- as shown. The ber of laps you have pulse sensor is Pulse Sensor completed (one lap equals 1/4 mile).
-
Page 11: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be permanently damaged. Unplug the power cord. CAU- TION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. -
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a UL-listed surge protector, rated at 15 amps, with a 14-gauge cord of five feet or less in length. b. If the walking belt is overtightened, treadmill perfor- 3ÓÐ4Ó...
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES WARNING: Fat Burning Before beginning this or any exercise program, consult your physi- To burn fat effectively, you must exercise at a relatively cian. This is especially important for individu- low intensity level for a sustained period of time. During als over the age of 35 or individuals with pre- the first few minutes of exercise, your body uses easily existing health problems. -
Page 15: Suggested Stretches
A Cool-downÑFinish each workout with 5 to 10 min- Exercise Frequency utes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post-ex- To maintain or improve your condition, complete three ercise problems. workouts each week, with at least one day of rest be- tween workouts. - Page 16 PART LISTÑModel No. WLTL42080 R0998A Key No. Qty. Description Key No. Qty. Description Frame Console Assembly Reading Rack Screw Front Wheel Latch Catch Motor/Pulley/Flywheel/Fan Rear Roller Motor Pivot Bolt Roller Guard Motor Tension Nut Platform Screw Motor Star Washer Foot Rail...
-
Page 18: Ordering Replacement Parts
If possible, place the treadmill near your telephone for easy reference when calling. WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
