- Page 1 ® Model No. WLTL45310 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guaran- tee complete satisfaction through direct assistance from our factory.
-
Page 2: Table Of Contents
120 volts AC and 15 amps. To purchase a surge suppressor, see 6. Keep children under the age of 12 and pets your local WESLO dealer or call 1-800-999- away from the treadmill at all times. 3756 and order part number 146148. - Page 3 14. Never start the treadmill while you are stand- treadmill until it is properly assembled. (See ing on the walking belt. Always hold the ASSEMBLY on pages 5 and 6, and HOW TO handrails while using the treadmill. FOLD AND MOVE THE TREADMILL on page 10.) You must be able to safely lift 45 pounds 15.
-
Page 4: Before You Begin
The model you’re not exercising, the CADENCE 4.6 DS can be number of the treadmill is WLTL45310. The serial folded up, requiring less than half the floor space of number can be found on a decal attached to the tread- other treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench and your own phillips screwdriver , two adjustable wrenches , wire cutters and needlenose pliers... - Page 6 3. Attach the Weight Rack (90) to the Uprights (11) with two Rack Bolts (89) and two Washers (39). Do not tighten the Rack Bolts yet. Note: If necessary, spread the Uprights apart slightly to align the holes in the Weight Rack with the holes in the Uprights.
-
Page 7: Operation And Adjustment
To purchase a surge suppressor, see your local The temporary adapter should be used only until a WESLO dealer or call toll-free 1-800-999-3756 and properly grounded outlet (drawing 1) can be installed order part number 146148. Use only a single-outlet by a qualified electrician. - Page 8 DIAGRAM OF THE CONSOLE Displays Incline Control Speed Control Pulse Sensor Clip CAUTION: Before operating the • Adjust the speed in small increments. console, read the following precautions. • The training zones marked beside the speed control are general guidelines only. See page •...
- Page 9 CALORIES/FAT Insert the key fully into the power switch. CALORIES/PULSE display—This display Note: Inserting the key shows the approxi- will not turn on the dis- mate numbers of plays. The displays will Arrow calories and fat calo- turn on when the ries you have burned.
-
Page 10: How To Fold And Move The Treadmill
HOW TO USE THE HAND WEIGHTS To exercise your upper body as you walk on the treadmill, hold the 1-pound weights at your sides or press the weights Weight Rack above your head. To increase the intensity of your exercise, use the 2-pound or 3-pound weights. - Page 11 HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described above. Make sure that the stor- age latch is closed fully over the catch. 1. Hold the upper ends of the handrails. Place one foot on the base as shown.
-
Page 12: Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES the first few minutes does your body begin to use stored fat calories for energy. If your goal is to burn fat, WARNING: Before beginning adjust the speed and incline of the treadmill until your this or any exercise program, consult your heart rate is near one of the lower two numbers in your physician. - Page 15 EXERCISE FREQUENCY tween workouts. After a few months of regular exer- cise, you may complete up to five workouts each week To maintain or improve your condition, complete three if desired. The key to success is to make exercise a workouts each week, with at least one day of rest be- regular and enjoyable part of your everyday life.
- Page 16 REMOVE THIS EXPLODED DRAWING AND PART LIST FROM THE MANUAL Save this EXPLODED DRAWING and PART LIST for future reference. Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of the User’s Manual.
- Page 17 PART LIST—Model No. WLTL45310 R0801A Key No. Qty. Description Key No. Qty. Description Left Handrail Extension Leg Screw Key/Clip Power Cord Incline Leg Pivot Bolt Power Cord Grommet Battery Cover Circuit Breaker Left Foot Rail Frame Pivot Washer Lift Motor...
- Page 18 EXPLODED DRAWING—Model No. WLTL45310 R0801A...
-
Page 19: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAWING in the center of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
