Summary of Contents for HP df300 Series
- Page 1 HP df300 Series HP df300 / df301 series Digital Picture Frame 數位相框 デジタル・ピクチャ・フレーム User Manual 使用說明書 ユーザー ・ マニュアル Revision 1.0a...
-
Page 2: Fcc Compliance Statement
FCC Compliance Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 3: Table Of Contents
Table of Contents FCC Compliance Statement What’s in the Box? Getting Started Initial Setup Setup Menu Key Features Picture Options Specifications Frequently Asked Questions Cleaning and Care Tips Getting Help... -
Page 4: What's In The Box
What’s in the Box? Item Image 3.5” Digital Picture Frame Universal Power Adapter (5V, 0.5A, 100/40 switching) USB .0 Cable User Manual Warranty Document IMPORTANT: Please keep this document for technical support contact information. -
Page 5: Getting Started
Getting Started 1. The digital picture frame has basic control buttons on the top of the frame as illustrated below. Power Right/Next Options Left/Previous . Unfold the attached stand to its extended position. Attach the USB cable to the AC adapter. Connect the mini connector of the cable to the digital picture frame, and plug the adapter into a wall power outlet as illustrated below. - Page 6 3. If the frame did not automatically power on, press and hold the button on the top of the frame for 3 to 5 seconds. The df300 Digital Picture Frame is preloaded with pictures that illustrate the basic features of this product and a slideshow will begin in a few seconds.
-
Page 7: Initial Setup
Initial Setup 1. Power on the picture frame and allow the picture slideshow to begin. Press button to view the Memory Source Screen as illustrated below. . Press and hold the button until the SETUP MENU is displayed as illustrated below. 3. - Page 8 4. Continue to use the buttons to highlight the desired option. Press the button to select the desired option. 5. Press the button to return to the SETUP MENU. Press the button again to exit the SETUP MENU and return to the Memory Source Screen.
-
Page 9: Setup Menu
Setup Menu Option Description Select “ORIGINAL” to display pictures with their original properties. Display picture in full height in normal aspect ratios. Some picture may not fill the screen, and leave space on both sides. Select Display Image Size “OPTIMAL” to allow the frame to display pictures with optimized properties. - Page 10 In this mode, you will be able to access the SD/SDHC/MMC card. This feature will automatically turn off the LCD on the HP digital picture frame to save valuable energy. You can choose from 4 settings. Options are: 5 minutes, 10 Power Saving minutes, 30 minutes, or No Power Saving.
-
Page 11: Key Features
Key Features Feature Picture slideshow • Automatic picture transition with different variations. Multiple picture viewing options • View individual pictures in Browse mode (see later section) • Copy pictures from an SD to internal memory without a PC connection •... -
Page 12: Picture Options
Picture Options Slideshow modes Slideshow mode will begin automatically a few seconds after the frame is powered on or when an external memory card is inserted. Browse mode To exit slideshow mode, press the button once. A pause symbol will be briefly displayed in the upper right of the screen. - Page 13 Picture Rotation While in slideshow or browse mode, press and hold the button until the PICTURE OPTIONS menu is displayed as illustrated below. Press the button to rotate the displayed picture. Each press of this button will rotate the picture by 90 degrees in a clockwise motion. Press the button to remove the PICTURE OPTIONS menu.
- Page 14 Copying pictures onto internal memory Pictures can only be copied onto the df300 frame’s internal memory from a Secure Digital (SD or SDHC) or MMC memory card. 1. Insert an SD/SDHC/MMC memory card with the desired pictures into the frame’s memory card slot. .
- Page 15 Deleting pictures from internal memory Pictures can only be deleted from the df300 frame’s internal memory. 1. Power down the picture frame. . If applicable, remove the memory card from the slot. This is done by pushing the card further into the slot until the card latch mechanism is released.
- Page 16 Adjust LCD Color While in browse mode, press and hold the button until the PICTURE OPTIONS menu is displayed. 1. Use the arrow button to highlight the Adjust LCD Color option. . Press the button to display the Adjustment options. 3.
-
Page 17: Specifications
Specifications Panel Specification Screen Size 3.5” Frame Dimension 95 x 77 x 13 (mm) Aspect ratio Resolution 30x40 pixels Power External AC Power Adapter +5V, 0.5A Connectivity 1- Mini USB .0 for recharging the internal USB Ports battery via AC adapter or PC/Laptop USB connection. -
Page 18: Frequently Asked Questions
Remove the external memory card or How can I switch to the internal memory? reference the Initial Setup section of this manual. How can I find the latest information/ Visit www.hp.com/support for more details FAQs about my HP Digital Picture Frame? and the latest information. -
Page 19: Cleaning And Care Tips
Cleaning and Care Tips √ Please power off the HP Digital Picture Frame before cleaning. √ DO NOT push on the screen too firmly. √ DO NOT spray or pour liquid cleaning agents directly on the screen or frame. √ DO NOT use ammonia, alcohol, or abrasive detergent cleaning agents. -
Page 20: Getting Help
Getting Help Should you have a technical service center. The service agent will provide support question or your HP you with an address and you will also be Digital Picture frame requires responsible for any shipping charges to service within the warranty the warranty service center. - Page 21 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
