Installation Guide
Remote Control Wafer light
www.gelighting.com
The GE brand and logo are trademarks of the General Electric Company.
©2022 GE Lighting, a Savant company. Information provided is subject to
change without notice. All values are design or typical values when measured
under laboratory conditions.
PRODUCT COVERED
Input voltage
Model
CAN06DW100R9RTWTNRO
BEFORE YOU BEGIN
Read these instructions completely and carefully.
STOP
WARNING
• Risk of fire or electric shock. Installation requires
knowledge of luminaire electrical systems. If not
qualified, do not attempt installation. Minimum 90°C
conductors, if uncertain contact a qualified electrician.
• These products are suitable for use in wet locations.
• IC rated for direct contact with insulation.
PREPARE ELECTRICAL WIRING
Electrical Requirements
The LED fixture must be supplied with 120Vac 60Hz.
Grounding Instructions
The grounding and bonding of the overall system
shall be done in accordance with National Electric
Code (NEC) and local codes.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:(1) This device may not cause harmful
interference; (2) this device must accept any interference received, including
interference that may cause undesired operation.
Current
Wattage
(Vac, Hz)
(mA)
(W)
120, 60
130
16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GE CAN06DW100R9RTWTNRO
Summary of Contents for GE CAN06DW100R9RTWTNRO
- Page 1 The GE brand and logo are trademarks of the General Electric Company. ©2022 GE Lighting, a Savant company. Information provided is subject to change without notice. All values are design or typical values when measured...
- Page 2 Note: This equipment has been tested and found to comply TOOLS REQUIRED with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 3 INSTALLATION Place the junction box on the Hold the spring clips against the ceiling through the hole. fixture and gently guide into the Turn off power source to the For a hole size of 6-1/4 inch, Connect the light with junction ceiling until the clips snap into power supply where you are Use the hole template to trace...
- Page 4 INSTALLATION - REMOTE CONTROLLER Option B: Mounting with adhesive tape This remote controller can be mounted to the wall in two ways, by screws • Ensure the installation surface is clean and dry or adhesive tape. Once you determine which install method is best for •...
- Page 5 USING THE REMOTE CONTROLLER CHANGING THE BATTERY NOTE: Pull out the plastic card from the battery compartment before using your remote controller. ② LED Indicator ① On/off button, turn on or turn off the light Dim down button, use it to decrease the brightness Dim up button, use it to Remove the back cover of remote using the screwdriver to change...
- Page 6 Additional Information and Warnings FCC Compliance Statement Compliance Notice: IC Statement This device complies with RSS247 of Industry Canada. Cet Warning: Changes or modifications to this unit not expressly approved appareil se conforme à RSS247 de Canada d’Industrie. by the party responsible for compliance could void the user’s authority to This device complies with Industry Canada license-exempt RSS operate the equipment.
