- Page 1 ® ONYXWorks NION-MXL Installation & Operation Manual Document 52550 12/7/9 Rev: P/N: 52550:C3 ECN: 09-538...
-
Page 2: Fire Alarm System Limitations
Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! typically made up of smoke detec- An automatic fire alarm system— bedrooms), smoking in bed, and violent explosions (caused by escap- tors, heat detectors, manual pull stations, audible warning devices, ing gas, improper storage of flammable materials, etc.). -
Page 3: Installation Precautions
GE Plastics, a subsidiary of General Electric Company. © by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited Copyright 2009 NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9... -
Page 4: Documentation Feedback
Manual page number • Your comment Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9... -
Page 5: Table Of Contents
Table of Contents Section 1 About this NION ....................... 6 1.1: Agency Listings .............................6 1.1.1: Compliance............................6 1.1.2: Installation ............................6 1.2: Environmental Requirements ........................7 1.2.1: Mounting Location Requirements .......................7 1.3: Related Documentation ..........................7 Section 2 Descriptions and Installation.................. 9 2.1: Siemens MXL Panel Configuration Description ...................9 Figure 2.1 MXL Panel Settings for Control ...................9 2.2: NION-MXL Description ..........................10 2.3: NION-NPB Motherboard Descriptions .......................10... -
Page 6: Section 1 About This Nion
Section 1 About this NION 1.1 Agency Listings NOTE: ® UL 864, 9th Edition—ONYXWorks systems work with products that have been UL 864, 9th Edition listed as well as products that have not received UL 864, 9th Edition certification. Operation of systems that are comprised of equipment that is UL 864, 9th Edition listed together with products that are not UL 864, 9th Edition listed requires the approval of the local Authority Having Jurisdiction (AHJ). -
Page 7: Environmental Requirements
Environmental Requirements About this NION Canada • CSA C22.1—Canadian Electrical Code, Part I, Safety Standard for Electrical Installations WARNING: Installation Improper installation, maintenance, and lack of routine testing could result in system malfunction. 1.2 Environmental Requirements This product must be installed in the following environmental conditions: •... - Page 8 About this NION Related Documentation NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9...
-
Page 9: Section 2 Descriptions And Installation
Section 2 Descriptions and Installation 2.1 Siemens MXL Panel Configuration Description For monitoring, the NION-MXL requires that a Siemens NIM-1R/1W module be installed in the MOM-2/4 card of the Siemens MXL panel. The NION communicates through its RS485 port to the MXL through TB3 of the MOM-2/4 card on the MXL panel. -
Page 10: Nion-Mxl Description
Descriptions and Installation NION-MXL Description 2.2 NION-MXL Description ® This NION-MXL is a plug-in feature of a ONYXWorks Workstation software application. The plug-in allows a Workstation to display events and other data originating from MXL panels. The events and data are defined as transparent (no action required) or apparent (action required) type communications between the Workstation, the NION’s associated panel, and the panel’s monitored points. -
Page 11: 2: Nion-Npb Motherboard Layout
NION-NPB Motherboard Descriptions Descriptions and Installation • Transformer coupled network connection using SMX style plug-in network transceiver modules. • Transient protection to 2400V on all terminals. • Standard wall mount enclosure (NISCAB-1 or CHS-4L with CAB-3/4 series enclosure). 2.3.2 NION-NPB Motherboard Layout This NION uses a NION-NPB motherboard and the component relevant to procedures in the manual are shown in the following figure. - Page 12 Descriptions and Installation NION-NPB Motherboard Descriptions Figure 2.2 NION-NPB Board Layout NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9...
- Page 13 NION-NPB Motherboard Descriptions Descriptions and Installation NION-NPB Motherboard Component Descriptions Here are some relevant descriptions, the number correspond items shown in Figure 2.2. • Battery Terminal (BT1) - 3V Lithium battery (Panasonic BR2032, P/N: 31007, +3VDC) terminal (#4). • Network Communication PLCC (U24) - The flash module that specifies the network transceiver (#5) •...
-
Page 14: 3: Nion-Npb Diagnostic Leds
Descriptions and Installation NISCAB-1 NION Enclosure Installation 2.3.3 NION-NPB Diagnostic LEDs Table 2.1 NION-NPB LED Descriptions NION-NPB LEDs are used to diagnose operations. SERVICE NTWK STATUS NTWK PKT SERIAL 2 SERIAL 1 NION STATUS Description SERVICE Indicates binding status of node on Echelon network: •... - Page 15 NISCAB-1 NION Enclosure Installation Descriptions and Installation Step 3. Mount the enclosure to the wall. Refer to the enclosure mounting hole layout in the following figure. 0.25 0.87 0.50 0.50 Mounting Studs with 7.75 Standoffs attached 12.0 Figure 2.3 NISCAB-1 Mounting Hole Layout WARNING: CAB-3/4 Series Cabinets When using a chassis in conjunction with a CAB-3/4 series cabinet, DO NOT use the CHS-4 chassis.
- Page 16 Descriptions and Installation NISCAB-1 NION Enclosure Installation Mount the NION-NPB Motherboard Inside the Enclosure When installing a single NION board in this enclosure, be sure to use the in cabinet set of four mounting studs with standoff studs as shown below. NISCAB-1 NION Motherboard...
-
Page 17: Nion Hardware Connections
NION Hardware Connections Descriptions and Installation 2.5 NION Hardware Connections NOTE: It is recommended that the installer conform to local code requirements when installing ® all wiring. All power connections must be non-resettable. Refer to the current NOTIFIER catalog for specific part numbers and ordering information for each NION. This NION requires these physical connections: ®... - Page 18 Descriptions and Installation NION Hardware Connections FTXC Network Transceiver The FTXC transceiver allows up to 8,000 feet (2438.4 m) per segment in a point-to-point configuration, up to 6,000 feet (1828.8 m) per segment in a dedicated bus configuration, or up to 1,500 feet (457.2 m) per segment in a star configuration.
-
Page 19: Nion Power And Serial Data Connections
NION Power and Serial Data Connections Descriptions and Installation 2.6 NION Power and Serial Data Connections Figure 2.7 NION-MXL Wiring Diagram NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9... -
Page 20: 1: Power Connection
Descriptions and Installation NION Power and Serial Data Connections 2.6.1 Power Connection This NION requires +24VDC @250 mA nominal and supervised battery backup in accordance with local code requirements. Outside Canada, this NION can be powered by any regulated, UL 1481 listed, power limited, battery backed, +24 VDC power supply. -
Page 21: Software Replacement/Upgrade Information
Software Replacement/Upgrade Information Descriptions and Installation 2.7 Software Replacement/Upgrade Information Follow this procedure and its precautions to replace or upgrade software chip-sets on the NION- NPB motherboard. When removing chips, a PLCC extractor (chip puller) should always be used. Never use screwdrivers or any devices that is not designed for the removal of socketed chips. WARNING: Power Always remove power from any NION before making any changes to switch settings, when removing or installing;... - Page 22 Descriptions and Installation Software Replacement/Upgrade Information NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9...
-
Page 23: Section 3 Nion-Mxl Operation
Section 3 NION-MXL Operation 3.1 About MXL Point Commands When a right click is performed on a panel’s device icon a list of command choices is displayed. Those commands below the last division line are sent from the Workstation through this NION to the panel’s device (point) and they are synonymous with the panel’s commands for the same operation. -
Page 24: 3: About Plugin Configuration
NION-MXL Operation Launch PlugIn 3.2.3 About PlugIn Configuration To configure the NION-MXL Plug-In, follow these steps: Step 1. Right click on the point icon and then select Launch PlugIn from the list of choices. The PlugIn window displays. Step 2. Select MXL in the NION Type field. Step 3. -
Page 25: About Mxl Point Programming
About MXL Point Programming NION-MXL Operation 3.3 About MXL Point Programming When programming information for panel point, each point must be given a unique address that will relate it to actual point monitored on the network. The formats for those point addresses may differ slightly from the addresses programmed in the panels. - Page 26 NION-MXL Operation About MXL Point Programming NION-MXL Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9...
-
Page 27: Index
Index FOXC Network Transceivers 18 FTXC Network Transceivers 18 Hardware Requirements 10 Installation Environmental Conditions 7 Network Connection 20 NISCAB-1 Installation 14 Power Connection 20 Regulatory Listings 20 SMX Network Transceivers 17 ONYXWorks™ NION-MXL (NPB) Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9... - Page 28 Index ONYXWorks™ NION-MXL (NPB) Installation & Operation Manual - P/N: 52550:Rev: C3 12/7/9...
-
Page 29: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 30 World Headquarters 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
