- Page 1 Face Recognition Terminal 91 60-K5 User Manual...
-
Page 2: Table Of Contents
3.3.4.2 Communication setting......................24 3.3.4.3 Universal parameters........................26 3.3.5 Peripherals ............................27 3.3.6 About..............................28 3.3.6.1 Basic Device Information......................28 3.3.6.2 Modify activation........................28 3.3.6.3 APP Version Update........................29 3.3.6.4 Firmware Upgrade........................29 3.3.6.5 Restore factory........................30 3.3.6.6 Restore Default........................31 Troubleshooting............................32 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 3: Product Description
1 second. Technology & Function: The dorm akaba 91 60-K5 Face Recognition Term inal can be easily integrated into building structures. It has large screen ratio which supports 1:N or 1:1 face authentication . The devices em bed a web server enabling on-device enrollm ent, term inal configuration and transaction log retrieval. -
Page 4: Technical Data
• Wiegand* 1 • Realy output* 1 Input Single* 2 1.2.6 Ambient conditions • Operating tem perature: -20℃ ~ + 70℃ • Relative hum idity: 10% - 90% (non-condensing) • Waterproof level: IP66 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 5: Dimensions
User Manual 1.2.7 Dimensions • 237m m L x 133m m W x20.8m m H All dimensions in mm. Wall dimension drawing 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... - Page 6 User Manual Mounting dimensions of bracket without temperature measurement 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
- Page 7 User Manual Dimension drawing of module with temperature measurement 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
- Page 8 User Manual Mounting dimensions of bracket with temperature measurement 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
-
Page 9: Featrue Structure
Card reading area Infrared fill light RGB Camera Bottom fixing screw Infrared Camera Bottom fixing screw Indicator feedback signal wiring Infrared sensor module Backplane fixing screw 8 Inch Touch Screen Temperature measurement module 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 10: Labeling
User Manual Labeling The identification plate is located on the underside of the device. The identification plate contains: • Device name • Item number • Serial number • Connection data (power supply) 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 11: Installation
The following connections should be present at the installation location: • Ethernet cable, with RJ 45 plug • Power supply cable • Lines to electric strikes and opener key. • Lines to the Wiegand Interface 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... - Page 12 (not use) GPIO The combination of NO and COM is normally open,while that of NC and COM is normally closed.The main equipment needs to use our power supply for independent power supply. 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
-
Page 13: Start-Up And Commissioning
Start-up and communication in regular operation are done via an Ethernet network. Power Suppply: DC12V 1.8A The firewall configuration m ust therefore be adapted accordingly. Without temperature measurement Step 1 Step 2 Step 3 With temperature Step 1 Step 2 Step 3 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 14: System Activation Adn Login
2.If the 9160 is started for the first time, the system prompts you to activate it. 3.After the startup is complete, the main activation screen is displayed. Step 1: The first login screen will prompt you to set the language to be used 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... - Page 15 User Manual Step 2: Set the account and password, enter the account password you need to set 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
- Page 16 User Manual Step 3:S et up network configuration 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
- Page 17 Server mode is to use software to configure the device(for example DISCERN) Standalon mode is the local configuration device Server IP and account is the configured server connection address and account information 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
-
Page 18: Device Local Management
In the upper right corner of the 91 60 screen, hold down the screen. The login screen is displayed. Enter your account and password to enter the main screen Menu options Login interface 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 19: Personner Management
1.The action menu is displayed after successful login and select the Personnel management Click this button 1. Click the button to add the person 2. Input the information to add Click here to take photo 3. Take photo 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 20: Logbook
1.The action menu is displayed after successful login and select the Logbook Filter conditions Log type 1. Enter the employee ID or name to filter logs 2. View Select a log type 3. Event description and time 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 21: Face Control
Configure the format of the card number identified by 91 60 Configure the 485 interface and baud rate. Currently, the functions are disabled The Bluetooth function is enabled 2. Interface Parameter 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 22: Parameter Settings
Parameter Settings include Customer setting and Communicationsetting and Universal setting The action menu is displayed after successful login and select the Parameter Settings 3.3.4.1 Customer Parameters 3.3.4.2 Communication Settings 3.3.4.3 Universal Settings 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 23: Basic Settings
The text message displayed on the screen when the face is verified for success and failure Whether to enable low-power mode, 91 60 disable some functions in idle state , such as NFC/Infrared light of the device. 2. Dispaly settings 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 24: Device Parameters
Maximum number of records in the local storage 2.Display settings Device Parameters： Sound volume Settings for the device Adjust the brightness of the device Set the standby time of the device The interval between recognition 3.Device Parameters 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 25: Communication Setting
Set the IP address of the device and enable the DHCP function 1.Ethernet Settings Host Configuration: Set the address, port, account and password of the communication server (such as DISCERN or third-party interface software). 2. Host Configuration 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... - Page 26 1.The action menu is displayed after successful login and select the Parameter Settings-- Commnication setting Ethernet Settings: Set the IP address of the device and enable the DHCP function 1.Ethernet Settings 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal...
-
Page 27: Universal Parameters
1.The action menu is displayed after successful login and select the Parameter Settings-- Universal Parameters Languages and Data/time settings: Language Settings. Currently, only Chinese and English are supported Set the time synchronization server 1.Languages and Data/Time settings 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 28: Peripherals
Warning:The double light caliration procedure is only for professionals to operate. Wrong operation will cause inaccurate body temperature measurement. 2. Thermal sensor settings 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 29: About
The device is delivered with an activation code. If the device does have an activation code, you need to contact the manufacturer to obtain the activation code and enter the activation code to activate the device while keeping the device connected to the Internet 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 30: Firmware Upgrade
You can update APP versions with interfaces (e.g. DISCERN and third-party interface software) 1.Update 3.3.6.4 Firmware Upgrade Upgrade the 91 60 firmware version 1.The action menu is displayed after successful login and select the About-Firmware Upgrade 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 31: Restore Factory
Restore factory Settings will clear all data of the 91 60, and you need to initialize the device to set the account and password of the 91 60. 1. Restore the factory 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 32: Restore Default
1.The action menu is displayed after successful login and select the About-Restore default. Restore default: Restore Default Settings Clear user Settings and restore the device to factory default Settings. 1.Restore default 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... -
Page 33: Troubleshooting
Check if data 0 & data 1 cable is correctly connected (See “Wiring” above). ⚫ Reader beeps but Check the input voltage at the card reader end is correct (See “Specifications” ⚫ No card data info above). 09/2021 dorm akaba 91 60-K5 Face Recognition Term inal... - Page 34 FCC Statement Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) ...
