- Page 1 ENERGIZER SOLAR PEAK 3000 ENGLISH PSUS4000H User Manual...
- Page 2 4. Response to Emergency Situations ....................2 5. Product Information ......................... 3 5.1 PSUS4000H-S Specifications ....................3 5.2 PSUS4000H-M Specifications ....................3 5.3 Battery System Specifications for PSUS4000H ..............4 6. Product Features ..........................5 6.1 Battery System Features ....................... 5 7. Installation ............................6 7.1 Items in the package ......................6...
- Page 3 1. Introduction The document describes the installation, commissioning, maintenance and troubleshooting of the following high voltage battery listed below. Note: PSM = PSUS-M+PSUS-S The battery chemistry of these products is Lithium Iron Phosphate. This manual is designed for qualified personnel only. The tasks described in this document should be performed by authorized and qualified technicians only.
- Page 4 · Do not connect different battery types together. · Please ensure that all the batteries are grounded properly. · Do not open the battery to repair or disassemble. Only Energizer Solar is allowed to carry out any such repairs. · In case of fire, use only dry powder fire extinguisher. Liquid extinguishers should not be used.
- Page 5 2. PSUS4000H-M contains the controller of the entire system, so each system must have one PSUS4000H-M; 3. Our system consists of at least 1 PSUS4000H-S + 1 PSUS4000H-M and up to 6 PSUS4000H-S + 1 PSUS4000H-M. 5.1 PSUS4000H-S Specifications Specifications for PSUS4000H-S Model NO.
- Page 6 5.3 Battery System Specifications for PSUS4000H Specifications for PSUS4000H PSUS4000H- PSUS4000H- PSUS4000H- PSUS4000H- PSUS4000H- PSUS4000H- Model No. Technical Properties 1*PSUS4000 1*PSUS4000 1*PSUS4000 1*PSUS4000 1*PSUS4000 1*PSUS4000 The number of H-M+1*PSU H-M+2*PSU H-M+3*PSU H-M+4*PSU H-M+5*PSU H-M+6*PSU batteries S4000H-S S4000H-S S4000H-S S4000H-S S4000H-S...
- Page 7 Ground Fault, Over Temp, In rush current · Battery Protection: Internal Short Circuit, Over voltage, over current, over temp, Under voltage The battery system contains the following Interface to allow it to connect and operate efficiently. PSUS4000H-S Features: - interface: PSUS4000H-M Features:...
- Page 8 7. Installation 7.1 Items in the package Please check if following items are including with the package: For PSUS4000H-S Items Quick Installation Mounting screw pack Guide Installation guide For PSUS4000H-M Quick Installation Guide...
- Page 9 If the battery pack is entirely or partially covered or shielded, it may cause the battery pack to stop operating. 7.3 Tools The following tools will be required to install PSUS4000H-M and PSUS4000H-S. Screw Driver Crimping Modular Safety Shoes...
- Page 10 7.4 Installation Steps Step 1: Install a PSUS4000H-S with four footstand (Item E) and place it on the ground and adjust it to the level. After installing the footstand, use a track level bar to confirm the level. Insert the waterproof cover(Item K) into the bottom of the battery and lock it in place with the clip.
- Page 11 Step 3: Stack the batteries one by one. Step 4: Place the two fixing brackets (Item D) close to the wall and install them on both sides of the battery. Step 5: Mark the wall through the bracket hole.
- Page 12 Step 6: Punch after removing the PSUS4000H-M. Drill holes with electric drill, make sure the holes are at least 50mm deep, and then tighten the expansion tubes (Item J). Step 7: After stacking PSUS4000H-M again, fix the battery on the wall.
- Page 13 Note: Please make sure each system including 1 PSUS4000H-M and 1 PSUS4000H-S. PSUS4000H-S less than 6(1~6) pieces: Please refer to the video for the installation of the junction box and the cable gland. 7.5 Wiring Steps A: Connect the inverter to make sure the wiring position is correct, as shown in the figure below.
- Page 14 Step 2: Crimp the cable with a Rj45 plug which is inside of the cable connector. If the usage is indoor, please use item F Step 3: Insert the cable connector into BMS port at the bottom of inverter and screw it tightly.
- Page 15 BMS Status LED will light up for 0.5s,Operating Status LED will light up for 1s at the same time,it means that the system works normally. 8. Commissioning The operating status light on the left side of the battery pack shows its working status. For PSUS4000H-S Green LED Red LED Batteries Status On for 0.5s, Off for 0.5s...
- Page 16 For PSUS4000H-M Status Green LED Red LED LED4-1 =100% ■ ● ● ● ● 100% > SOC >= 75% ■ ● ● ● ● 75% > SOC >= 50% Standby ■ ● ● ● 50% > SOC >= 25% ■...
- Page 17 Fault Green LED Red LED LED4-1 Under voltage fault ■ ● Over voltage fault ■ ● Over temperature fault ■ ● ● Under temperature fault ■ ● Discharge over current ■ ● ● Charge over current ■ ● ● Discharge over power ■...
- Page 18 The warranty shall not cover the defects caused by normal wear and tear, inadequate maintenance, handling, storage faulty repair, modifications to the battery or pack by a third party other than Energizer Solar or Energizer Solar agent, failure to observe the product specification provided herein or improper use or installation, including but not limited to the following.
- Page 19 When the red / green LED on the panel is flashing or normally on, it does not mean that the PSUS4000H-S is abnormal, it may be just an alarm or protection. Please check the ‘LED status indicators’ in chapter 7 for the detailed faulty definition before any trouble-shooting steps. In general, the alarm indication is normal without manual intervention.
