  • Page 1 IMAGECHECKER P400MD Hardware Manual...
  • Page 2 This manual and everything described in it are copyrighted. You may not copy this manual, in whole or part, without written consent of Panasonic Electric Works Europe AG (PEWEU). PEWEU pursues a policy of continuous improvement of the design and performance of its products.
  • Page 3 Disconnect the power supply before connecting or disconnecting any • connectors to or from the P400MD. Never apply force to any P400MD connectors or cables. Do not bend the • cables. The connections should never be unplugged by pulling on the cable.
  • Page 4 Use the components only within the humidity and temperature ranges • specified. Take care to keep dust accumulation to a minimum since dust may impair • the functioning of the components. Do NOT clean the components with solvents or aggressive cleansers. •...

  • Page 5: Important Symbols

    Important Symbols One or more of the following symbols may be used in this documentation: Warning! The warning triangle indicates especially important safety instructions. If they are not adhered to, the results could be fatal or critical injury. CAUTION Indicates that you should proceed with caution. Failure to do so may result in injury or significant damage to instruments or their contents, e.g.
  • Page 6 KEYPOINTS Summarizes key points in a concise manner. SHORTCUTS Provides helpful keyboard shortcuts. EXPLANATION Provides brief explanation of a function, e.g. why or when you should use it. next page Indicates that the text will be continued on the next page. The manual uses the following conventions to indicate elements from the user interface or the keyboard: "Data field"...

  • Page 8: Table Of Contents

    Serial Interface ..................15 1.2.3.1 Pin Assignment and Pin Connection..........16 1.2.4 Operating System..................17 1.2.4.1 Write Protection................18 1.2.4.2 Changing the Write Protection with Panasonic Security Console...19 1.2.5 Time Response of the System ..............21 1.2.6 Description of the Casing .................22 1.2.7 Dimensions....................25 1.2.7.1 Floor Mounting ................26...
  • Page 9 Specifications ...................51 2.4.4 Spectral Response ...................52 Partial Scan Mode ................... 53 Installation................55 Important Information ................56 Unpacking the P400MD................58 Connecting the Imagechecker..............59 Software Installation ................60 3.4.1 New Installation of Vision P400 Edition "4.2 Full Version" .......60 viii...
  • Page 10 P400MD Hardware Manual Table of Contents 3.4.2 Applying for a New License..............62 Driver for the Frame Grabber and the Digital I/O Board ......64 System Backup and Recovery..............67 3.6.1 Using the Flash Drive ................67 3.6.2 Using the Network ..................69 3.6.3...

  • Page 12: System Description

    Chapter 1 System Description...

  • Page 13: Introduction

    System Description P400MD Hardware Manual 1.1 Introduction This page provides you with an overview of all the major P400MD components and optional accessories. These components will be described in more detail in the sections to follow. Equipment/Accessories Order number Controller set: ANPMD4311V1 •...

  • Page 14: Industrial Pc

    P400MD Hardware Manual 1.2 Industrial PC 1.2 Industrial PC The Industrial PC P400MD (called Imagechecker hereafter) was developed especially for use in demanding industrial environments. The Imagechecker provides ultimate convenience as a result of: • 24V DC power supply (ATX functionality of the internal power supply) •...

  • Page 15: Specifications

    Consult the dealer or an experienced radio/T.V. technician for help. • Panasonic Electric Works Europe AG is not responsible for any radio television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Panasonic Electric Works Europe AG.
  • Page 16 P400MD Hardware Manual 1.2 Industrial PC Industrial PC Intel Celeron M440, 1,86GHz with active cooling 1GB DDR2 SDRAM (max. 4GB) Chip set Intel 82945GM Graphics Intel GMA 950 up to 224MB shared memory BIOS (Phoenix-AWARD-BIOS), P400MA-1-01/08 Ethernet Intel 82562ET 10/100 Base TX Ethernet...

  • Page 17: Digital I/O Board

    The digital outputs are equipped with short-circuit protected PhotoMos relays to protect against overload. It is possible to connect further peripheral devices (see page 9). The Imagechecker P400MD offers one PCI slot for a digital I/O board. 1.2.2.1 ANPC 850V3D The figures below show the pin assignment of the digital I/O board ANPC 850V3D when you look at the Imagechecker.
  • Page 18 P400MD Hardware Manual 1.2 Industrial PC Inputs of the digital I/O board ANPC 850V3D Inputs (16 Signals) Pin No. Pin for COM Functionality 29 (Default. Alternatively, Start: starts the application pin 10 can be defined as an Please refer to the information on wiring the optional ground...
  • Page 19 System Description P400MD Hardware Manual Outputs of the digital I/O board ANPC 850V3D Outputs (16 Signals) Pin No. Pin for COM Functionality PCReady: next application start possible REnd: Read image end Strobe: indicates output data available Application change completed Error due to byte overflow / lost start...

  • Page 20: Connect Peripheral Devices To Anpc 850V3D

    P400MD Hardware Manual 1.2 Industrial PC 1.2.2.2 Connect Peripheral Devices to ANPC 850V3D Please note the following specifications for the input and output circuit: Input circuit Voltage range Ue State 0V up to 4V 12V up to 24V ON (rated input voltage) Min.

  • Page 21: Output Circuit

    System Description P400MD Hardware Manual Danger of damage to the equipment! Applying more than 26.4V to the inputs may destroy them! Output circuit Important: The description of the PhotoMos output circuit is valid for all output signals. For reasons of speed, the flash signal will be output via a special PhotoMOS output with a rise time of 2μs.
  • Page 22 P400MD Hardware Manual 1.2 Industrial PC Output digital I/O board Power supply PLC Input (NPN) COM (+) COM (±) Output Connecting a PLC with NPN inputs Danger of damage to the equipment! Do not connect circuits with more than 26.4V (AC or DC)!

  • Page 23: Details On Pin 11 (Start Signal)

    System Description P400MD Hardware Manual 1.2.2.3 Details on Pin 11 (Start Signal) By default, the output signal at pin 11 (start) uses pin 29 as a common ground with input signals at pins 12 to 14 and pins 30 to 30, see figure. By using a jumper you can separate the ground for pin 11 from the common ground at pin 29 and move it to a separate contact at pin 10.
  • Page 24 P400MD Hardware Manual 1.2 Industrial PC Flash: Emitter (-) Flash: Collector (+) 4 pin Phoenix Contact connector Start input (con- nected with pin 11) COM Start (con- nected with pin 10) ( B ) ( A ) Jumper COM Start...
  • Page 25 System Description P400MD Hardware Manual Flash: Emitter (-) Flash: Collector (+) 4 pin Phoenix Contact connector Start input (con- nected with pin 11) COM Start (con- nected with pin 10) Jumper set to position A Jumper A COM Start Pin 10...

  • Page 26: Serial Interface

    P400MD Hardware Manual 1.2 Industrial PC Flash: Emitter (-) Flash: Collector (+) 4 pin Phoenix Contact connector Start input (con- nected with pin 11) COM Start (con- nected with pin 10) Jumper set to position B Jumper B COM Start...

  • Page 27: Pin Assignment And Pin Connection

    System Description P400MD Hardware Manual 1.2.3.1 Pin Assignment and Pin Connection The following sections explain how to connect the Imagechecker correctly to an external device depending on the settings of the "Handshake" parameter. The Imagechecker has a 9-pin male connector.

  • Page 28: Operating System

    P400MD Hardware Manual 1.2 Industrial PC Parameter "Flow Control" = Hardware Another way to improve the data transfer is to set the devices to perform a hardware handshake. This does not only mean a connection of data lines (depending on the configuration the lines are crossed or not), but also to connect the pins RTS and CTS.

  • Page 29: Write Protection

    System Description P400MD Hardware Manual • Swedish Menus and dialog windows will be displayed in the language you have selected. 1.2.4.1 Write Protection The operating system Windows XP Embedded uses a sophisticated write protection to prevent users from inadvertently changing the system settings.

  • Page 30: Changing The Write Protection With Panasonic Security Console

    P400MD Hardware Manual 1.2 Industrial PC 1.2.4.2 Changing the Write Protection with Panasonic Security Console Use the tool Security Console if you want to save settings in the registry file permanently or if you wish to switch the write protection on or off.
  • Page 31 System Description P400MD Hardware Manual Button Available functionality Enable FBWF Switches on the "File-Based Write Filter" (FBWF) (see page 18). This activates the write protection of the operating system. You need to restart the system to apply the change. Please note: By default the write protection is OFF.

  • Page 32: Time Response Of The System

    P400MD Hardware Manual 1.2 Industrial PC Button Available functionality Registry Key Not only can you exclude files and folders from the write protection, but also complete paths in Protection the registry file. This is necessary if you want to be able to save system changes permanently.

  • Page 33: Description Of The Casing

    This is why the option "Power Scheme" is set to "Presentation". The options "Switch off monitor", "Switch off hard disk", "Standby" and "Hibernation" are deactivated. 1.2.6 Description of the Casing 14 15 Connections in the front panel of the P400MD...
  • Page 34 P400MD Hardware Manual 1.2 Industrial PC Button to: • Switch on (press lightly once), • Shut down (press lightly once) and • Switch off (press and hold until the device switches off) Frame grabber ANPCL 8021D with two camera connectors (camera 1 and 2)
  • Page 35 Imagechecker P400MD. The use of any other products will negate the warranty for the entire system since third-party components can damage the P400MD. In this case, Panasonic will not assume liability for the proper functioning of the P400MD.

  • Page 36: Dimensions

    P400MD Hardware Manual 1.2 Industrial PC Take care to keep dust accumulation to a minimum since dust may impair • the functioning of the components. Do NOT clean the components with solvents or aggressive cleansers. These • substances can destroy equipment parts and damage the paint.

  • Page 37: Floor Mounting

    System Description P400MD Hardware Manual 1.2.7.1 Floor Mounting 4x M3 Floor mounting of the P400MD...

  • Page 38: Wall Mounting

    P400MD Hardware Manual 1.2 Industrial PC 1.2.7.2 Wall Mounting A ( 2 : 1 ) 3,25 3,25 Wall mounting of the P400MD...

  • Page 39: Frame Grabber

    System Description P400MD Hardware Manual 1.3 Frame Grabber The frame grabber ANPCL 8021D is available for parallel image grabbing with two cameras. The Imagechecker offers one PCIe slot for one frame grabber. You can work with one camera or connect two cameras for parallel image grabbing. Use the table below to find out about possible combinations of frame grabber and cameras.
  • Page 40 P400MD Hardware Manual 1.3 Frame Grabber Below there are two examples: Using different camera types Camera 1: ANPVC 1021 with a shutter speed of 1/1000s Camera 2: ANPVC 1210 with a shutter speed of 1/1000s 18ms 20ms Camera 1 Read...

  • Page 41: Displaying The Camera Image In Parallel Operation

    You can connect up to 2 cameras to the frame grabber ANPCL 8021D. You can connect the cameras in any order, either only at connector 1 or connector 2 or at both connectors. In addition, you can mix cameras of different types with the P400MD. NOTE The camera connector type is Mini Camera Link SDR.

  • Page 42: Specifications

    P400MD Hardware Manual 1.3 Frame Grabber Camera connection to the ANPC 8021D Connection to ANPC 850V3 output flash signal Connection for camera 1 Connection for camera 2 1.3.1.3 Specifications ANPCL 8021D (2 cameras parallel) Bus interface PCIe x 1, DMA image transmission...

  • Page 43: Working With A Flash

    (optional). There are different possibilities of connecting and controlling a flash, depending on whether you have installed a digital I/O board or not. This table provides an overview of the machine vision systems P400, P400MA, and P400MD, as well as P400S: Device...
  • Page 44 P400MD Hardware Manual 1.4 Working with a Flash Pin 3 Pin 4 Circuit diagram Plug specifications Maximum current 50mA Variable current 5,0V up to 24,0V Maximum reverse voltage 7,0V NOTE When there is a digital I/O board installed, please note the pin assignment for •...

  • Page 45: Software For Industrial Image Processing

    System Description P400MD Hardware Manual 1.5 Software for Industrial Image Processing The Vision P400 software version 4.2 is multi-lingual. It supports English, German, and French. The following camera types are supported: • ANPVC 1040 • ANPVC 1210 • ANPVC 1021 The installation procedure is described in detail elsewhere (see page 60).

  • Page 46: Software Protection

    Vision P400, which can be run and installed on any PC. A backup copy of the license file will be stored with Panasonic as well as your local PEW branches. In addition, a time-limited license is also available for the current month at Panasonic and the local PEW branches in case you need to compensate the loss of a license file temporarily.

  • Page 48: Camera Specifications

    Chapter 2 Camera Specifications...

  • Page 49: Introduction

    (PoCL) (see page 37). Please read the notes below prior to operating any of the cameras (see page 28). NOTE Only use the cameras and camera cables recommended by Panasonic. • For lens selection tables, please turn to our homepage: •...
  • Page 50 P400MD Hardware Manual 2.1 Introduction Do not touch the CCD element or the lens surface of the camera. Attach the • lens cap to keep off dust when not in use. When removing the cable from the connector, be sure to hold it by its plug to •...

  • Page 51: 2-Mega-Pixel Digital Camera (Anpvc 1210)

    Lens Use the proper lens for each camera. Make sure to use only lenses with a resolution suitable for the camera. For more information please contact your local Panasonic branch. The following lenses are available: • ANPVL162, lens f=16 for 2-mega-pixel digital camera •...
  • Page 52 P400MD Hardware Manual 2.2 2-Mega-Pixel Digital Camera (ANPVC 1210) When you are using partial scan mode, only a reduced number of image lines will be transferred and this reduces the transfer time. This helps you to increase the image or inspection rate considerably.

  • Page 53: Dimensions

    Camera Specifications P400MD Hardware Manual 2.2.2 Dimensions 2.2.3 Specifications Feature Specification Image sensor Interline transfer method. 1/1.8" CCD, pixel size: 4.4 μ m x 4.4 μ m (tetragonal pixel) No. of effective pixels 1628 x 1236 pixels (horizontal x vertical)

  • Page 54: Spectral Response

    P400MD Hardware Manual 2.2 2-Mega-Pixel Digital Camera (ANPVC 1210) Feature Specification Weight About 65 g (without lens) 2.2.4 Spectral Response 1000 Wave length (nm)

  • Page 55: Quad-Speed Digital Camera Anpvc 1040

    Camera Specifications P400MD Hardware Manual 2.3 Quad-Speed Digital Camera ANPVC 1040 Description Additional information Lens Use the proper lens for each camera. Lens fixture C-Mount lens Mounting plate Insulation type plate. The plate can be attached to four sides of the camera.
  • Page 56 P400MD Hardware Manual 2.3 Quad-Speed Digital Camera ANPVC 1040 When you are using partial scan mode, only a reduced number of image lines will be transferred and this reduces the transfer time. This helps you to increase the image or inspection rate considerably.

  • Page 57: Dimensions

    Camera Specifications P400MD Hardware Manual 2.3.2 Dimensions 2.3.3 Specifications Feature Specification Interline transfer method. 1/3" CCD, pixel size: 7.4 μ m x 7.4 μ m Image sensor (tetragonal pixel) No. of effective pixels 659 x 494 pixels (horizontal x vertical)

  • Page 58: Spectral Response

    P400MD Hardware Manual 2.3 Quad-Speed Digital Camera ANPVC 1040 2.3.4 Spectral Response 1000 Wave length (nm)

  • Page 59: Ultra Compact Double Speed Digital Camera Anpvc 1021

    Camera Specifications P400MD Hardware Manual 2.4 Ultra Compact Double Speed Digital Camera ANPVC 1021 Camera head Description Additional information Lens Lens fixture Special mount. Lens securing ring Use the ring to fix the lens. Mounting plate Camera cable Mounted directly to the camera. Cannot be removed.

  • Page 60: Time Diagram For Image Grabbing

    P400MD Hardware Manual 2.4 Ultra Compact Double Speed Digital Camera ANPVC 1021 2.4.1 Time Diagram for Image Grabbing The camera ANPVC 1021 is a black-and-white progressive scan CCD camera. The camera is suitable for grabbing images of moving objects. The image grabbing is triggered by a signal from the frame grabber.

  • Page 61: Dimensions

    Camera Specifications P400MD Hardware Manual All camera settings like shutter speed, offset, gain, gamma, flash signal output etc. are made on the property page "Camera Settings" under Camera → Properties in the software. For example, it is possible to set a delay between the camera trigger and the flash signal output so that you can set the optimum exposure time and duration for the image grabbing.

  • Page 62: Specifications

    P400MD Hardware Manual 2.4 Ultra Compact Double Speed Digital Camera ANPVC 1021 Dimension of the camera control unit 2.4.3 Specifications Feature Specification Image sensor Interline transfer method. 1/3" CCD, pixel size: 7.4 μ m x 7.4 μ m (tetragonal pixel) No.

  • Page 63: Spectral Response

    Camera Specifications P400MD Hardware Manual 2.4.4 Spectral Response 1000 Wave length (nm)

  • Page 64: Partial Scan Mode

    P400MD Hardware Manual 2.5 Partial Scan Mode 2.5 Partial Scan Mode Here you can specify which part of the image sensor should be used for image grabbing. If you reduce the sensor area used, the image grabbing time will be shorter. The image size for a full image is 640 x 480 pixels for the quad-speed and the ultra-compact camera, and 1600 x 1200 pixels for the 2-mega camera.

  • Page 66: Installation

    Chapter 3 Installation...

  • Page 67: Important Information

    Installation P400MD Hardware Manual 3.1 Important Information Please read the following information before you begin with the installation or operation! NOTE Use only products (cameras and camera cables) offered by PEWEU for • specific use with the Imagechecker. The use of any other products will negate the warranty for the entire system since third-party components can damage the Imagechecker.
  • Page 68 P400MD Hardware Manual 3.1 Important Information Avoid discharges of static energy. • Use the components only within the humidity and temperature ranges • specified. Take care to keep dust accumulation to a minimum since dust may impair • the functioning of the components.

  • Page 69: Unpacking The P400Md

    Installation P400MD Hardware Manual 3.2 Unpacking the P400MD As you unpack your P400MD, please check the package contents to make sure nothing is missing. NOTE Be careful! The P400MD weighs approx. 3kg. • Mount the device on the floor or at the wall according to the description.

  • Page 70: Connecting The Imagechecker

    P400MD Hardware Manual 3.3 Connecting the Imagechecker 3.3 Connecting the Imagechecker Procedure 1. Check the power input of the power supply (24V DC/3A) For operating the Imagechecker you need a current consumption of 24V DC/3A. To avoid noise, use a separate power supply for the Imagechecker.

  • Page 71: Software Installation

    Installation P400MD Hardware Manual 3.4 Software Installation Vision P400 is available in different editions. The following editions are available in English, French, or German: • Vision P400 version 4.2 • Vision P400 Demo Version 4.2 (free of charge) 3.4.1 New Installation of Vision P400 Edition "4.2 Full Version"...
  • Page 72 P400MD Hardware Manual 3.4 Software Installation The auto start menu of the flash drive is displayed. Select "Start my P400MA Recovery System". 2. Select "Install Vision P400" from the following menu This triggers the installation routine of the Vision P400 software. Follow the instructions on the screen and restart the system when you are finished.

  • Page 73: Applying For A New License

    Installation P400MD Hardware Manual 3.4.2 Applying for a New License Procedure 1. Insert the flash drive in a free USB port The auto start menu of the flash drive is displayed. 2. Select "Start my P400MA Recovery System" 3. Select "Get License ID" from the following menu...
  • Page 74 6. Write down the serial number of your Imagechecker The serial number can be found on the product label on the casing. 7. Inform your local Panasonic Electric Works branch that you need a new license file Tell them the license ID you have written down and the serial number.

  • Page 75: Driver For The Frame Grabber And The Digital I/O Board

    3.5 Driver for the Frame Grabber and the Digital I/O Board The Imagechecker P400MD uses a frame grabber of type ANPCL 8021D for image grabbing and the digital I/O board ANPC 850V3 for digital data output. All devices need the appropriate drivers for correct operation.
  • Page 76 P400MD Hardware Manual 3.5 Driver for the Frame Grabber and the Digital I/O Board Device type ANPC 850V3D ANPCL 8021D (frame (Imaging devices) (I/O P400MD/P400) grabber) Displayed as Panasonic Digital IO Silicon Software GmbH ANPC850V3D microEnable IV-BASE x1 .INF file PIOPEW.inf...
  • Page 77 Next, in the installation folder open the file with the extension .SYS. The drivers for all other PC devices like graphic boards, Ethernet, etc. are installed with the setup from the recovery CD. If the necessity for an update of the driver arises, please contact your local Panasonic branch.

  • Page 78: System Backup And Recovery

    P400MD Hardware Manual 3.6 System Backup and Recovery 3.6 System Backup and Recovery You have several possibilities to use the recovery software on the flash drive: • Start recovery from flash drive (see page 72) • Create and save a backup copy of the current system:...
  • Page 79 Installation P400MD Hardware Manual 2. Start the system and wait until the system has booted from the flash drive 3. Type "2" <Enter> 4. Type "S" <Enter> The backup process should take 10 to 20 minutes to complete. When the backup process has finished, you will find the backup copy "BackupVisionP400image.wim"...

  • Page 80: Using The Network

    P400MD Hardware Manual 3.6 System Backup and Recovery 2. Start the system and wait until the system has booted from the flash drive 3. Type "3" <Enter> 4. Type "R" <Enter> The restore process should take 10 to 20 minutes to complete. After you have completed the restore process, the Imagechecker is in the same state as it was when you created the backup.
  • Page 81 Installation P400MD Hardware Manual Back up the system Procedure 1. Insert the flash drive in a free USB port 2. Start the system and wait until the system has booted from the flash drive 3. Type "4" <Enter> 4. Type "S" <Enter>...
  • Page 82 P400MD Hardware Manual 3.6 System Backup and Recovery Restore the system Procedure 1. Insert the flash drive in a free USB port 2. Start the system and wait until the system has booted from the flash drive 3. Type "5" <Enter>...

  • Page 83: Recover The Original State Of The System

    Installation P400MD Hardware Manual 3.6.3 Recover the Original State of the System Before you reset your system to the original state, please carry out the following steps to back up important information from you current system: Procedure 1. Create a backup copy of the file "license.dat"...
  • Page 84 At first boot, you are prompted for your Microsoft Product ID. 8. Enter the user name, company name, and Vision P400 serial number You find the serial number on the Panasonic product label on the hardware casing. 9. Configure the network adapter, if necessary 10.

  • Page 85: Assign A Password For Windows

    Installation P400MD Hardware Manual 3.7 Assign a Password for Windows If you wish to start the Imagechecker and/or Vision P400 automatically, you need to assign a Windows password in order to be able to activate the corresponding settings for Vision P400.

  • Page 86: Maintaining The Imagechecker

    P400MD Hardware Manual 3.8 Maintaining the Imagechecker 3.8 Maintaining the Imagechecker Aside from cleaning the device and replacing or cleaning the dust filter, the Imagechecker is maintenance-free. Consequently, you should never open the Imagechecker. Ensure that the PC has ample space for ventilation in both front and back. Heat build-up can destroy the electronic components.

  • Page 87: Resolving Problems

    Installation P400MD Hardware Manual 3.9 Resolving Problems If your Imagechecker should ever cease to function, please check all plug connections first, then check the software configuration. If you cannot find the reason for the problem there, do NOT open the device and do not attempt to repair anything inside the Imagechecker.

  • Page 88: Environmental Protection

    P400MD Hardware Manual 3.10 Environmental Protection 3.10 Environmental Protection NOTE Please disconnect the Imagechecker from the electrical outlet when it is not • in use for an extended period of time (e.g. vacation, etc.). Turn off the Imagechecker when not in use (e.g. upon completion of the work •...

  • Page 90: Appendix

    Chapter 4 Appendix...

  • Page 91: Hardware Settings

    Appendix P400MD Hardware Manual 4.1 Hardware Settings This chapter deals with the following hardware-related topics: • BIOS configuration data • Environment variables 4.1.1 BIOS Configuration Data If you wish to restore the correct BIOS settings for the Imagechecker, please proceed as...

  • Page 92: Environment Variables

    P400MD Hardware Manual 4.1 Hardware Settings seconds. 3. Save the settings with <F10> 4.1.2 Environment Variables The following settings are made when you install Vision P400. The settings are absolutely necessary for working with Vision P400. If the path settings are not correct or missing altogether, Vision P400 will not be able to operate.

  • Page 93: Repair Service Instructions

    Appendix P400MD Hardware Manual 4.2 Repair Service Instructions Danger for people and equipment! These instructions are intended for the exclusive use of authorized personnel. You should never even open the Imagechecker casing unless you have expert knowledge of applied computer engineering and are qualified to work on computer hardware.
  • Page 94 P400MD Hardware Manual 4.2 Repair Service Instructions 5. Fasten and connect the fan, respectively insert the new battery Make sure to keep the cables securely away from the fan. 6. Close the Imagechecker casing and fasten it with the four recessed-head...

  • Page 95: Installing A Hard Disk

    Appendix P400MD Hardware Manual 4.2.2 Installing a Hard Disk The hard disk drive ANPMA 861 has a limited service life. If necessary, you can replace the hard disk: Procedure 1. Pull the mains cable and disconnect the power supply 2. Unscrew the four screws of the top cover and pull the cover up to open the casing 3.

  • Page 96: Installing A Slot Card

    It is only necessary to replace the frame grabber (ANPC 802D) or the digital I/O board (ANPC 853V3D) in the rare event that a hardware failure occurs. These boards are pre-installed in the Imagechecker P400MD. It is possible to replace the pre-installed digital I/O board with your own board.
  • Page 97 Appendix P400MD Hardware Manual 3. Open the slot card holder of the board 4. Inside the Imagechecker, unscrew the fastening screws of the board with a suitable screwdriver Insert the torx screwdriver supplied with the Imagechecker through one of the slotted side holes in the casing to unscrew the board's fastening screws.

  • Page 98: Error Handling And System Diagnosis

    P400MD Hardware Manual 4.3 Error Handling and System Diagnosis 4.3 Error Handling and System Diagnosis This chapters contains information about how you can diagnose and fix errors when operation Vision P400. You find information on the following topics: • List of possible types of error •...

  • Page 99: User Feedback

    Appendix P400MD Hardware Manual Menu Description File → Save.../Save As... Saves all the available information in a file with the extension *.dvi. This file can be viewed with the DiagVision software. File → Exit Exits DiagVision. Tools → Generate a report Displays a report dialog box for the entire analysis.

  • Page 100: Error Description

    P400MD Hardware Manual 4.3 Error Handling and System Diagnosis Software Error Report Change Request/Suggestion for Improvement From Name: Date: Address: Panasonic Electric Works Europe AG IPD Sensors Phone: Facsimile: Facsimile: +49-8024-648-222 Error description Vision P400 version number Vision P400 software serial number:...

  • Page 101: Recommended Literature

    Appendix P400MD Hardware Manual 4.4 Recommended Literature Title Author Published by Fundamentals Of Digital Image Processing Anil K. Jain Prentice Hall Englewood Cliffs 1989 Digitale Bildverarbeitung Bernd Jähne Springer Verlag Berlin Sechste überarbeitete und erweiterte Auflage 2005 Bildverarbeitung in der Praxis R.

  • Page 102: Index

    Index FBWF ............18 File-Based Write Filter (FBWF)....18 Flash ............32 Flash drive ........67, 72 Ambient temperature ........4 Frame grabber ANPC 850V3D ........6, 9, 12 Camera connector plugs....28 ANPCL 8021D ........31 Combine with cameras ......28 ANPVC 1021...........48 Frame grabber ANPCL 8021D ..31 Dimensions ........50 Parallel grabbing........28 Specifications........51...
  • Page 103 Index P400MD Hardware Manual ..........67, 69 Reset to original state ......72 P400MD ............2 Reset button..........22 BIOS ..........80 Reset to original state ......72 Changing the Assembly..82, 84, 85 Cleaning..........75 Conformity..........3 Connect camera.........38 Safety notes ..........ii Description of the casing ....22 Save changes to the system permanently Dimensions .........
  • Page 104 Index P400MD Hardware Manual Warm start..........59 Write protection of the operating system 18...

  • Page 105: Record Of Changes

    Record of Changes Manual No. Date Description of changes ACGM0104EN V1.0 June 2009 First edition (based on ACGM0101V71DE)

  • Page 106: Global Network

    Piazza della Repubblica 24, 20154 Milano (MI), Tel. +39022900-5391, Fax +39022900-3466, www.panasonic-building-materials.com Nordic Countries Panasonic Electric Works Nordic AB Sjöängsvägen 10, 19272 Sollentuna, Sweden, Tel. +4659476680, Fax +46859476690, www.panasonic-electric-works.se  PEW Fire & Security Technology Europe AB Jungmansgatan 12, SE-211 19 Malmö, Tel. +46406977000, Fax +46406977099, www.panasonic-fire-security.com Poland Panasonic Electric Works Polska sp.
