Multi-Channel Audio/Video Monitor/Mixers User Guide Part Number 821839, Revision C...
Page 2
In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.
Selecting the Loudness Cluster ............. 21 Video Screen ....................22 Menu / Option Touchscreen ................23 Main Menu ..................24 Loudness Menu .................. 24 Loudness Meter.................. 24 Loudness Settings ................27 Source Select ..................28 Presets ..................... 30 All Presets ..................30 Page 3 iVAM1-SUM16-G...
Page 4
System Information ................46 Passcode Settings ................47 Forgotten Passcode ................49 CHAPTER 3: Technical Info ............... 50 CHAPTER 4: iVAM1-SUM16-G Web GUI ..........55 Web Browser / Control Device................ 55 First Time IP Assignments ................55 Peer-to-Peer Connection..............55 Network Connection................
Page 5
Updating via the Web GUI using a Flash Drive ..........97 Updating an iVAM1-SUM16-G Remotely ............99 Updating Multiple Units Remotely ..............101 APPENDIX B: Dante Network Setup ............104 Introduction ....................104 What is in the iVAM1-SUM16-G for Dante? ............104 Dante Device Setup ..................106 Dante Clock Selection ..................107 Channel Names...................107 AES67 .......................108...
Page 6
APPENDIX F: Out of Band Control............136 Introduction ....................136 SFP IP Address Configuration ................136 SFP System Configuration ................137 SFP 2110 Configuration................138 SFP 2110 Preset Config ................141 Diagnostic Information.................142 APPENDIX G: 2110 SFP Personalities ..........144 Introduction ....................144 Personality Change..................144 Page 6 iVAM1-SUM16-G...
Any audio channels (or channel pairs) from any audio/video source stream may be monitored. The iVAM1-SUM16-G includes two 3G SDI inputs and it can monitor both video and audio from them. It also includes one switched 3G SDI output, and a pair of analog inputs and outputs.
LCD Display Cleaning Do not use the following to clean the display screen. They may damage the polarizer. Water • Ketone solvents (Ketone or acetone) • Aromatic solvents (toluene or xylene) • Ethyl alcohol • Page 8 iVAM1-SUM16-G...
This feature will reduce or eliminate rear bracing requirements in many mobile/portable applications. The weight of internal components is distributed fairly evenly around the unit. Electrical Interference Be careful to avoid mismatched cable types and other similar causes of undesired Page 9 iVAM1-SUM16-G...
ICES-003 This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Page 10 iVAM1-SUM16-G...
CHAPTER 2: Local Operation Operation The iVAM1-SUM16-G can be operated easily and simply from controls on its front panel, as described in this chapter. It may be accessed remotely in two ways, via the Wohler Web GUI for administrative purposes or by third party equipment via Application Programming Interface (API) commands.
Page 12
10. Status: This indicator lights green when the system is powered and ready for use. A solid or blinking yellow color indicates that the product is starting up. A red color indicates that a system update is taking place. Page 12 iVAM1-SUM16-G...
Cage Cage Power Connection: The iVAM1-SUM16-G receives power from an AC inlet, which is a standard IEC receptacle for 100 to 240 VAC ±10%, 50/60 Hz power connection. Four regional AC power cords, supplied according to shipping region, are available.
Page 14
48 kHz sample rate. An optional license key must be purchased to enable this function. The COAX output is reclocked from the MADI source. When power to the iVAM1-SUM16-G is not present, the COAX input and output are automatically connected together to allow the MADI signal to pass through.
Page 15
. The Analog Inputs are standard on the Left Right iVAM1-SUM16-G. Refer to Figure 2-4 for the pinout of this connector. Figure 2-4: Analog XLR-F Output Connections 11. Analog Outputs: These male XLR connectors provide two balanced analog outputs: .
Page 16
Option card. The source of these signals is the monitored audio channels as shown on meters 1 - 8. Tascam cables may be used, and can be purchased by contacting Wohler Sales. Refer to Figure 2-6 for the pinout of this connector.
Page 17
0 to 5 volt logic level. Do not exceed 5 VDC or less than 0 VDC if driven from a logic level to avoid possible damage to the GPI input. Page 17 iVAM1-SUM16-G...
To integrate it into your digital network, you need to set its address to the source to be monitored. You must use the MN-Set configuration software to set up this option. It is available from Wohler Technologies Technical Service. The procedure to accomplish this is described in the SFP-2022-6 / SFP-2110 Setup Guide (part number 821822), which is available at https://wohler.com/downloads/...
When a Cluster can be adjusted, the Trim Dial will highlight in purple: The rotational position of the indicator within the Trim Dial shows the adjustment. Note: To undo all Cluster trims and reset them to the default value in the Page 19 iVAM1-SUM16-G...
A blue box will then surround the cluster and it will be the only Cluster heard. At this point you may rotate the Channel knob to move the blue box to solo other Clusters. Press the Channel knob once again to remove the solo and return Page 20 iVAM1-SUM16-G...
Reading button on the display. It will turn from green to orange. Then touch the cluster you would like to begin analyzing for Loudness. The orange Loudness Cluster Indicator will move to that Cluster. After 15 seconds, Loudness Reading button will time out and turn green again. Page 21 iVAM1-SUM16-G...
A large variety of signals are detected, including HDR. Note: If the Video Source and Video Signal displays have been optioned to disappear after 5 or 10 seconds and you wish them to reappear, simply touch the video screen. Page 22 iVAM1-SUM16-G...
Screen HDMI Settings Network Settings Analog Config Screen System Reboot Screen System Options Network Settings System Update Screen System Reboot Factory Reset System Update Screen Factory Reset System Details System Details Screen Password Settings Password Settings Screen Page 23 iVAM1-SUM16-G...
Touch the Loudness Meter button on the Loudness Menu screen to reach the Loudness Meter Screen. The Loudness Meter Screen is a more detailed view of the Loudness Measurement. It is displayed along with the channel meter screen and is Page 24 iVAM1-SUM16-G...
Page 25
2. Green: Loudness is within the Alarm Tolerance. 3. Orange: Loudness is greater than the Alarm Tolerance. Below the digital Loudness meter, in the left column, the following parameters are also displayed: 1. The Loudness RAnge (LRA) is the measure of variation between the Page 25 iVAM1-SUM16-G...
Page 26
5. Stop: When Manual Mode is selected in the Loudness Settings screen, the Stop button will stop gathering loudness data. Data will be held for viewing and not be reset using this control. 6. Back: Touch the Back button to go to the Loudness Menu. Page 26 iVAM1-SUM16-G...
Web GUI Loudness Settings: These settings are included on this screen for reference only. They cannot be changed on this screen. 1. Standard: This is the loudness standard by which the loudness calculation is made. 2. Reference: This is the set point in the loudness measurement about which Page 27 iVAM1-SUM16-G...
This screen also shows sources which are unlicensed and therefore nonfunctional. These sources are shown in a gray color. To license these sources so that they may be used, contact Wohler Technologies. Figure 2-15 shows the Source Select Menu. Figure 2-15: Source Select Menu Touch Menu to exit this menu.
Page 29
Menu Back Analog Valid license is required DB25 This selection requires a license from Wohler to enable. Please call at +1-510-870-0810 or email at support@wohler.com. Thank you! Back Touch Back to return to the Source Select menu or touch Menu to return to the Main Menu.
Figure 2-18: All Presets Screen - Group Selection The Presets are normally arranged into Groups. Use this screen to select which Preset-containing Group to examine. After selecting one of the Groups, the Preset Selection screen shown in Figure 2-19 is shown. Page 30 iVAM1-SUM16-G...
Page 31
To return to the All Presets Group Selection screen instead, touch the Groups button. To return to the Menu without making a selection, touch the Menu button. Figure 2-20: All Presets Screen - No Presets To return to the Menu from this screen, touch the Menu button. Page 31 iVAM1-SUM16-G...
To exit this screen without making a selection, touch Menu. If no Favorite Presets have been designated, this screen will appear as shown in Figure 2-22. Figure 2-22: Preset Favorites Screen - No Favorites Page 32 iVAM1-SUM16-G...
Touching the Speaker Options selection on the Unit Settings Menu screen proceeds to the Speaker Options screen. The controls on this screen affect various characteristics of the monitored audio as heard on the iVAM1-SUM16-G. This screen is shown in Figure 2-24.
2. Video Info: This setting determines if or how video information is displayed when the video screen is selected by pressing the Source knob. The possible selections are as follows: Page 34 iVAM1-SUM16-G...
Page 35
3. AES termination: AES signals should have one and only one termination. This termination should physically be at the last destination of an AES coax cable. If the iVAM1-SUM16-G is the last connection in a series of AES connections, then its terminations should be turned on. A symptom of too many terminations (or no termination) is that no signal appears to be present on the AES input.
Touch the left or right arrows to select the scale. A representation of the chosen scale will be shown at the right. The possible scales that can be selected are shown in Figure 2-27. Figure 2-27: Meter Scale Selection Page 36 iVAM1-SUM16-G...
Page 37
10 ms to reach -2 dB of IEC Type II -24 dB 2.8 sec. settled reading None Bar or Floating Segment Not Displayed When you have made your choices, touch Back to exit this screen. Page 37 iVAM1-SUM16-G...
(EDID) to disclose their capabilities to the video source. The iVAM1-SUM16-G can use this information to ensure its compatibility with the HDMI Monitor. If you decide that you do not want the iVAM1-SUM16-G to receive this information, set this switch to Off. By default this switch is set to On.
Analog Config screen. Contained in this menu is an Analog Reference as illustrated in Figure 2-30. The parameters set on this screen pertain to the Analog Input and Analog Output DB25 and XLR connectors on the rear panel of the iVAM1-SUM16-G. Figure 2-30: Analog Configuration Menu Analog Config...
(fixed) or a dynamic (DHCP) network address. Figure 2-32: Network Settings Screen 1. To change the IP Address, Net Mask, Gateway, or DNS, tap the item you would like to change. A keypad will appear, as shown in Figure 2-33. Page 41 iVAM1-SUM16-G...
Page 42
(fixed) network address, touch the DHCP button again. The colors of the buttons will return to the ones depicted in Figure 2-32. Figure 2-34: Network Settings: DHCP 1. To complete the network addressing scheme change, touch the Save button. Page 42 iVAM1-SUM16-G...
Figure 2-35: System Reboot If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
Upgrading System. There is no USB mounted If you have just inserted a flash drive with a valid software upgrade package, press Refresh to see that package. Touch the Back button return to the System Options Menu. Page 44 iVAM1-SUM16-G...
Mac address 28.) If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
System Details screen as shown in Figure 2-38. This screen lets you view the product Serial Number, Software Version, and various other information. Figure 2-38: System Details Screen The information shown on this screen is read only and cannot be changed. Touch Back to return to the System Options Menu. Page 46 iVAM1-SUM16-G...
To prevent accidental or unauthorized changing of critical settings in some of the menus, it is possible to block or restrict access to various menus. The Wohler Web GUI can be used to limit access to the menus of your choice. Refer to Chapter 4, the Front Panel Configuration tab of System Preferences.
Page 48
This is shown in the left image of Figure 2-42. Touching these buttons will cause a Passcode entry screen to appear, as shown in the left image of Figure 2-40. The correct Passcode must Page 48 iVAM1-SUM16-G...
Although the Passcode should be remembered or securely noted somewhere, it can happen that it is forgotten. This can be remedied by performing a Factory Reset from the Wohler Web GUI. Unfortunately, this will also erase all of the menu settings. You may also contact Wohler Technical Service for help.
CHAPTER 3: Technical Info Table 3–1: iVAM1-SUM16-G Specifications Specification Values/Domains Power Requirements 100 VAC to 240 VAC ± 10%, 50/60Hz Power Consumption 65 Watts Dimensions 1.75” x 19” x 5.5” (44mm x 483mm x (H x W x D) 140mm), standard 19” rack mounting Shipping/Net Weight 8 lbs.
Page 51
Power Output 5 Watts RMS, 12 Watts peak (each side) Acoustic Frequency 150 Hz to 16 kHz (± 5 dB) Response Headphone Out - Stereo 40 Hz to 20 kHz (± 1 dB) Headphone Load 8Ω to 150Ω Page 51 iVAM1-SUM16-G...
Page 53
**MN-Set is configuration software that is necessary so that you can set up this module. It is available at no cost either from its manufacturer, Embrionix, or by contacting Wohler Technologies Technical Service. Table 3–3: iVAM1-SUM16-G Option Cards Option Part #...
Page 54
Figure 3–1: iVAM1-SUM16-G Block Diagram 3G-SDI Input 1 HDMI Output Video from SDI 1, 2, or SFP 3G-SDI Input 2 Touchscreen for Audio Meters and Video 3G-SDI Output Audio from SDI 1, 2, or SFP Menu HD/1080p 59.94Hz SDI-1 LKFS-M : -20.5...
Network Setup page. Refer to the Network Setup section which follows. Otherwise set the iVAM1-SUM16-G to DHCP address mode by checking the box for ‘Use DHCP?’ in Network Setup and have your IT administrator assign rights and settings for operation on the network.
Network Setup Make network IP Address changes for the local iVAM1-SUM16-G Management (MGMT) Port here. Figure 4–2: Set IP Addresses iVAM-SUM The procedure for changing the IP Address information is as follows: 1. Use DHCP? Check this box if your network has a DHCP server and you want to use dynamic addressing.
Throughout the Web GUI, pages are a click or two away using the list of selections on the left side. The Dashboard page shows all of the available Preset configurations at a glance. The iVAM1-SUM16-G allows you to assign Presets to particular groups. In Figure 4-3, two groups, Operator-1 and Operator-2 are shown.
Page 59
Figure 4-4, to the right of the associated Recall button. After clicking the Preset Edit button, the screen shown in Figure 4-5 will appear. Clicking a Group Edit button will cause the screen in Figure 4-6 to appear. Page 59 iVAM1-SUM16-G...
Page 60
1. Delete: Remove the Preset from the system. Do Not delete the currently active Preset. 2. Rename: Rename the Preset, but keep all of its other characteristics. 3. Make Favorite: Make this Preset a favorite. This can be done for frequently used Presets. Page 60 iVAM1-SUM16-G...
Page 61
Figure 4–6: Dashboard Group Edit The Edit options for a Group are as follows: 1. Delete: Delete the Group and all of the Presets it contains. 2. Rename: Rename the Group, but keep all of its other characteristics. Page 61 iVAM1-SUM16-G...
Click on Audio Meters to remotely display the audio meters of the iVAM1-SUM16- G. This display is shown in Figure 4-7. Also displayed is the name of the source that the meters are displaying. In Figure 4-7, this is SDI/BNC-1. Figure 4–7: Audio Meters Display Page 62 iVAM1-SUM16-G...
Reference. This tab is shown in Figure 4-8. This System Audio Clock Reference setting can be overridden by the optional System Clock Reference setting in the Preset Management menu when the Preset is chosen. Figure 4–8: System Audio Clock Reference Tab Page 63 iVAM1-SUM16-G...
Above or below this range will result in color changes in the graph. 7. Loudness Window: This may be set to Momentary, Short, or one of 22 values, ranging from one second to two hours. 8. Monitoring Mode: Page 64 iVAM1-SUM16-G...
Select All and Reset All buttons are also provided. Figure 4–10: Phase Indicator Configuration Tab iVAM-SUM When you have finished making the settings click Apply to save them or click Cancel to discard them. Page 65 iVAM1-SUM16-G...
Trigger Action: A pull down menu allows you to select one of seven possible actions that may be triggered by GPI voltage: No Action: The GPI trigger will have no effect. This is the default setting and may be used when that particular GPI is left disconnected. Page 66 iVAM1-SUM16-G...
Page 67
Note again that if the Alternate GPI Trigger Action is chosen for one GPI transition, then Action and Action 2 for the other transition on the same GPI must be set to No Action to avoid conflict. Page 67 iVAM1-SUM16-G...
Continue button to try again. If you have forgotten the Passcode, this can be remedied by performing a Factory Reset. Unfortunately, this will also erase all of the menu settings. You may also contact Wohler Technical Service for help. Figure 4-13: Unrecognized Passcode...
Page 69
You may set which menus are affected by restrictions. Click any menu shown to change it between affected (red icon) and unaffected (green icon). Apply: When you have completed the desired settings in this tab, click Apply to put them into effect. Page 69 iVAM1-SUM16-G...
1. Preset Configuration: You may create a new Preset, adjust an existing Preset, or create a new Preset from an existing Preset: To create a new Preset, enter the name for the new Preset in the • Page 70 iVAM1-SUM16-G...
Page 71
A Surround 5.1 Cluster consists of 6 channels that together monitor a 5.1 surround sound signal. Clicking a Cluster Info box opens a Cluster selection box. In the Cluster box, you can select the type of Cluster from a pull down selection. The available Cluster Type selections are: Page 71 iVAM1-SUM16-G...
Page 72
SUM16-G screen is the consecutive number of each channel’s appearance on the display. It may be changed on this screen within the limits of the space for it on the iVAM1-SUM16-G screen. 11. The Output Routing tab is shown in Figure 4-16. When the OPT-OUTPUT- ROUTING capability was not purchased and licensed, the signals are routed to the outputs in a fixed pattern, which is not changeable.
Six or eight channels could be directed to the AES outputs, which could feed an external surround sound system. Contact Wohler Sales to purchase the license for the OPT-OUTPUT- ROUTING feature.
AES Pair 2 Output. 5. AES/Pair-3: Selected inputs will be mixed to the left and right channels and played through the AES Pair 3 Output. 6. AES/Pair-4: Selected inputs will be mixed to the left and right channels and Page 74 iVAM1-SUM16-G...
Output Options section, the associated row within the matrix is automatically set to the speaker mix and the checkboxes are grayed out indicating that you may not change them with a Free Mix assignment. Page 75 iVAM1-SUM16-G...
What signal outputs can be controlled using the Output Routing feature? All the outputs on the iVAM1-SUM16-G can be controlled using the Output Routing feature. This includes – Internal Speakers, Analog XLR outputs, all 4 pairs of AES outputs on HD-15, and AoIP Pair 9 and Pair 10.
Analog XLRs? To downmix a pre-fade output on AES Pair-1, uncheck the Volume Control checkbox for that AES pair. For a Post-fade output on the Analog XLRs, check Volume Control checkbox. Page 77 iVAM1-SUM16-G...
Presets and want to monitor audio only using Source Select? How would I configure different outputs for Source Select choices? Use the Global Output Routing settings to determine how the outputs are Page 78 iVAM1-SUM16-G...
When the optional OPT-OUTPUT-ROUTING license is purchased, in the Global Output Routing configuration, if the Mute on Headphone Insertion checkbox is ON then the outputs get automatically muted when a headphone is inserted into the Headphone jack. Page 79 iVAM1-SUM16-G...
In the Output Routing setting, for the Analog XLR outputs, keep the Volume Control checkbox unchecked and the Solo/Mute checkbox checked. This ensures that the Volume Control is not applied to the outputs, while the Solos/Mutes are. Page 80 iVAM1-SUM16-G...
Set the Meter Label Source on this screen to “Evertz Quartz” as shown in Figure 4- Figure 4-20: Evertz Quartz Compatibility Setting If no Evertz Quartz Server Setup is entered, or if it is incorrect, the Connection Page 81 iVAM1-SUM16-G...
Page 82
Status will indicate Invalid Address. Enter the Host Address and Port of the Evertz Quartz server in the Quartz Server Setup section. For assistance, contact Wohler Technical Service. Click the Apply button to enable Evertz Quartz compatibility. When Evertz Quartz compatibility is enabled and connected, this screen changes as...
Page 83
Figure 4-23: Preset Setup Screen Apply Global Quartz Routing Tab The Global Quartz Routing Tab will display the Quartz Server Setup and allow you to decide whether Global Quartz Routing will apply to this Preset. Page 83 iVAM1-SUM16-G...
To start Preset Replication, click on the Preset Replication tab on the master unit. This will start the unit discovery process and will list all the iVAM1-SUM16-G units that you currently have on your network. The discovery process will continue for a period of 2 minutes.
Page 85
The progress of the Preset replication for each unit, as the Presets are being copied, will be displayed in the Process column. When all of the Presets have been copied to each of the selected units, you may leave this screen. Page 85 iVAM1-SUM16-G...
SUM16-G. Likewise, it can be used to import a Preset database from the computer hard drive into the iVAM1-SUM16-G. In this way, a Preset configuration may be only devised once and then duplicated into all of the iVAM1-SUM16-G units in a system, saving significant effort.
If there were any errors, repeat these steps to try again. Figure 4–27: Database Export Import Configuration Use the following steps to copy the Preset configuration into the iVAM1-SUM16-G: 1. Click the Choose File button as shown in Figure 4-27 and select the Preset Tag you would like to import.
Page 88
Figure 4–28: Database Import iVAM-SUM Download all Presets from your iVAM-SUM unit onto your computer. Upload Presets from a file to your iVAM-SUM unit. Page 88 iVAM1-SUM16-G...
These tabs are explained in the following three sections. System Information This tab displays a variety of information about the iVAM1-SUM16-G. It is shown in Figure 4-29. This information could be useful to view if you are contacting Wohler Technical Service.
This tab displays a variety of information about the module inserted into the SFP slot on the rear panel of the iVAM1-SUM16-G. It is shown in Figure 4-30. This information could be useful to view if you need to ascertain what module, if any, is installed, or if you are contacting Wohler Technical Service.
This tab displays the license number for each of the modules or features in the iVAM1-SUM16-G. It is shown in Figure 4-31. You will use this tab to enter any new license numbers that you purchase. Contact Wohler Sales to obtain new license numbers.
If you have any doubt as to whether you should perform a Factory Reset, do not click the Initiate Factory Reset button. Contact Wohler Technical Service for advice. Factory Reset will also reset your IP address to the default one. After a Note: Factory Reset, the IP Settings will need to be updated.
The Reboot System function should be used with a bit of caution. It puts the iVAM1-SUM16-G out of service for several minutes while it is rebooting, and this may unexpectedly interfere with the use of the product by the remote operator.
Introduction This chapter describes how to download a software update file to your computer, transfer it to a USB flash drive and install the updated into an iVAM1-SUM16-G. Download the Software The iVAM1-SUM16-G software update can be found at http://www.wohler.com, under Product Downloads on the Products >...
Local Update from the Front Panel Use the following steps to update the iVAM1-SUM16-G software: 1. Copy the unzipped Wohler Update Package file(s) from your computer to the root directory (not inside of a folder) of a USB flash drive. It must be FAT32 file type, and does not need to be empty.
Page 96
After the software update starts, the text on the left screen will change periodically to indicate the progression of the upgrade. The upgrade will take 5 minutes or more, after which the iVAM1-SUM16-G will restart. After the system has completed its restart cycle and is once again operational, you may then remove the flash drive.
USB flash drive. 2. Connect to the iVAM1-SUM16-G with the Wohler Web GUI. Navigate to the System | System Update menu, as shown in Figure A-5.
Page 98
6. Next, the update begins, showing the screen in Figure A-8. The circle in the center of the screen, along with status messages below it, will indicate the progress of the update. Figure A-8 – Software Upgrade in Progress Page 98 iVAM1-SUM16-G...
7. At this point, wait for the update to complete. It may take several minutes, it is critical not to disturb the iVAM1-SUM16-G or the Web GUI until the update process is complete. When it is complete, the iVAM1-SUM16- G will restart.
Page 100
3. At this point, wait for the update to complete. It may take several minutes, it is critical not to disturb the iVAM1-SUM16-G or the Web GUI until the update process is complete. When it is complete, the iVAM1-SUM16- G will restart.
Use the following steps to update one or more iVAM1-SUM16-G units remotely by transferring the software from a previously updated iVAM1-SUM16-G: 1. If any of the iVAM1-SUM16-G units that you intend to update remotely may be in use, contact the people using them and let them know what you will be doing.
Page 102
Figure A-13 – List of Found iVAM1-SUM16-G Units 4. Then click Update Selected Devices. The window shown in Figure A-14 will appear. Figure A-14 – Apply System Package 5. Click Apply System Update. The screen shown in Figure A-15 will appear.
Page 103
Figure A-15 – System Update Progress 6. At this point, wait for each update to complete. It may take several minutes, it is critical not to disturb any of the iVAM1-SUM16-G units or the until the update process is complete. When it is complete, each Web GUI iVAM1-SUM16-G will restart.
On iVAM1-SUM16-G, the AoIP source can be selected through the Source Select option. The iVAM1-SUM16-G is set up at the Wohler factory to be used as a slave rather than a master within the Dante network. Other devices or software, such as a Dante Controller, are expected to be responsible for most device configurations and all audio routing.
Page 105
Card ID will be shown in red, e.g. Wohler-xxxxxx where xxxxxx is the last 6 hex digits of the card MAC address as shown in B-1. This usually indicates that the IP address of the card is not in the same subnet as the Dante Controller host.
6 digits of the Dante port MAC address, as shown in Figure B-2. This name can be changed by the Dante Controller to appear that way on the network, but that will not change the iVAM1-SUM16-G unit name appearing on GUI pages and iVAM1- SUM16-G Remote Metering or Discovery pages.
Dante Clock Selection While the Brooklyn’s internal clock is highly accurate, the iVAM1-SUM16-G does not have provisions for external sync clocks, such as those that are GPS or media reference (video genlock or audio word clock) based. So it is generally not the best candidate to be the PTP Master Clock (commonly called the “grandfather clock”) for...
AES67 The iVAM1-SUM16-G Brooklyn II can be configured for AES67 operation. Refer to Figure B-5. AES67 operation with Dante is limited to eight or less receive and transmit channels at 48 kHz sample rates. 24 bit linear (L24) encoding and 1 msec packet time are fixed default transmit parameters.
Device Lock command at this time. Dante Firmware Upgrades Wohler iVAM1-SUM16-G monitors ship with current Brooklyn II firmware as of the option installation date. The version information is found in the Dante Controller Device View-Status page. iAM software/firmware is tested with the latest Dante code release.
8171152, European Patent 2255541, Chinese Patent ZL200780026677.0 and other patents pending or issued, see or such other www.audinate.com/patents legend as Audinate may stipulate from time to time to the Manufactured Product and any packaging and marketing materials therefor. Page 111 iVAM1-SUM16-G...
APPENDIX D: Ravenna (ZMAN) Setup Introduction Installing the iVAM1-SUM16-G into an existing and functioning Ravenna network using the Merging ZMAN Card is virtually plug and play. The iAM rear panel AoIP jack supports 1Gb/s and 100Mb/s Ethernet devices in Ravenna Audio over IP network configurations.
The iVAM1-SUM16-G can be configured using its Front Panel controls or its web interface through its Management port. Details specific to the iVAM1-SUM16-G can be found in Chapters 2 and 4 of this manual.
6. Network Interface: Note the address of the card and its type (Zeroconf, DHCP, Static). (If necessary, the address can be changed to another type such as a Static address which must include a Network Mask and Gateway.) Page 114 iVAM1-SUM16-G...
Delay Mech.: This is PTP Profile related - E2E or P2P h. Announce: This is PTP Profile related - PTP announcement interval (1 - 2 - 4 - 8 -16 seconds) i. Sync: This is PTP Profile related (0.0625 - 0.125 - 0.25 - 0.5 seconds) Page 115 iVAM1-SUM16-G...
6. Address: This the stream’s multicast address. Note that the user defined checkbox is activated automatically when entering a multicast address manually. 7. TTL: Time to Live (also called Hop Limit) - This value should not be modified. Page 116 iVAM1-SUM16-G...
1. Create session button: Create new session sinks by clicking on left ICON. 2. IO: Select the physical output (when applicable). 3. Label: This is the Sink name. 4. Source: This is a drop down menu to select a source (both sap and bonjour advertised sources are automatically listed). Page 117 iVAM1-SUM16-G...
(usually the same as the source name) 4. Clock Domain: This is the PTP clock type and domain 5. Payload: Selections are Payload / Codec / Sampling Rate / Number of Channels 6. SDP: This displays detailed SDP information on the current stream. Page 118 iVAM1-SUM16-G...
Getting Started | I/O Router This page allows remapping of incoming channels to different internal channel assignments. For example, Stream channel 1 can be remapped to Merging card Channel 0, and so on. Figure D-6: Getting Started | I/O Router Page 119 iVAM1-SUM16-G...
IAM interface for display on meters and speakers, etc. The iVAM1-SUM16-G must be set to receive AOIP from the Source Select Front Panel menu or a browser iVAM1- SUM16-G GUI.
Page 121
For example, for monitoring 2 SDI sources (four 8 channel Flows), assign two flows to 1-8 and 9-16 and the next SDI signal to 17-24 and 25- 32. Touch the iVAM1-SUM16-G AOIP selection menu to select the proper range to monitor, up to 57-64.
Figure D-8: Session Sources Tab ZMAN Updating The Zman card is pre-initialized with the correct Wohler firmware load. In case of future upgrades, use the following steps: 1. In Aneman, right click the ZMAN entry on the bottom Devices section, and select Maintenance Mode.
Page 131
"Id": 3, "Name": "SDI_Autofill" "Favorite": 0, "Id": 2, "Name": "SDI_Manual" "Id": 1, "Name": "G1" 4. GET to recall the preset Method: GET api/op/presets/<int:presetID>/activate Example Response: "params": { "PresetId": "error": null, "result": { "GroupId": 1, "PresetName": "SDI_Manual", "GroupName": "G1", Page 131 iVAM1-SUM16-G...
Page 132
"error": null, "result": { "GroupId": 6. POST to delete the preset Method: POST api/op/preset/<int:presetID>/delete Example Response: "params": "PresetId": "error": null, "result": "PresetId": 7. POST to rename group Method: POST /api/op/group/<int:groupID>/newGrpNameSdi/rename Example Response: "params": { "GroupId": 1, "GroupName": "newGrpNameSdi" Page 132 iVAM1-SUM16-G...
Page 133
"error": null, "params": { "PresetId": 1, "PresetName": "newPresetNameTest" "result": { "PresetId": 1, "PresetName": "newPresetNameTest" 9. POST to set preset as Favorite Method: POST /api/op/preset/<int:presetID>/<favoriteVal>/favorite Example Response: "error": null, "params": { "PresetId": 4, "Favorite": "result": { "PresetId": 4, "Favorite": Page 133 iVAM1-SUM16-G...
Page 134
"ChannelGroup": <Int: 1-8> Note: Allowed MADI input sources are "Madi.Coax" and "Madi.Optical" ChannelGroup 1 => Channels 1-8 and ChannelGroup 2 => Channels 9-16 and so on e.g. "SourceType": "Madi.Coax", "ChannelGroup": 3. Body content for Analog "SourceType": "Analog.XLR" Page 134 iVAM1-SUM16-G...
Page 135
Note: ChannelGroup 1 => Channels 1-8 and ChannelGroup 2 => Channels 9-16 and so on 6. Body content for TOSLINK "SourceType": "Toslink" Example Response: "unit_name": "", "model": "iVAM1-SUM", "api_version": 1, "message": "Input Source Toslink has been applied successfully", "serial_number": "123456", "status": Page 135 iVAM1-SUM16-G...
SFP IP Address Configuration You may change the IP address of a 2110 or 2022-6 SFP. This can be done using the System Setup | Sfp Information | Network tab of the Wohler Web Server, as shown in Figure F-1.
You may change the Personality of an SFP using the System Setup | SFP Information | Personality tab of the Wohler Web Server. If the Embrionix SFP is a combo SFP module, you may also switch from 2110 to 2022 using this feature. All the personalities loaded on a SFP are displayed on the tab, as shown in Figure F-2.
SFP 2110 Configuration If a 2110 firmware is loaded, the Wohler Web-GUI can be used to configure Audio/Video Flows of the SFP. The Out of Band On/Off Switch at the top of the SFP 2110 Global Setup page controls whether the out of band settings will be applied to the SFP or not.
Page 139
Appendix. The global configuration will be used for Source Select. Refer Figures F-3 and F-4 for Video parameters. Refer to Figures F-5 and F-6 for Audio parameters. Refer to Figure F-7 for PTP parameters. Figure F-5: Audio Parameters Page 139 iVAM1-SUM16-G...
Figure F-8: SFP 2110 Preset SFP Configuration Enable SFP Config After clicking the SFP Config button, the SFP 2110 Setup Screen will appear, as shown in Figure F-9. Make the settings you need for this Preset and then click Close. Page 141 iVAM1-SUM16-G...
10 seconds to fetch the latest information from the SFP. The diagnostic information is always available even when the “Out of band” control is turned off. Refer to Figures F-10, F-11, and F-12 for descriptions of the information available. Figure F-10: Diagnostic Information Page 142 iVAM1-SUM16-G...
Page 143
Figure F-11: Diagnostic Information Figure F-12: Diagnostic Information Page 143 iVAM1-SUM16-G...
Personality Change Locate the Combo SFP IP Address on the SFP Information Tab of the System page. Refer to Figure G-1, which shows the System page of a typical Wohler iAM or iVAM product. Figure G-1: Combo SFP Address Location...
Page 145
Set As Default button appears in the Action column of the Element 1 row. 2. Click on the Set As Default button which has now appeared in the Element 1 row. 2022-6 is now the Default Personality, and the screen should appear as shown in Figure G-3. Page 145 iVAM1-SUM16-G...
Page 146
Figure G-3 – New Personality Selected Element 1 Load Now Do Not Press the Selected Button Clear Buttons This completes the procedure. Page 146 iVAM1-SUM16-G...
