iVAM1-SUM8
iVAM1-SUM16
Multi-Channel Audio/Video Monitor/Mixers

User Guide

Part Number 821839, Revision B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iVAM1-SUM8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wohler iVAM1-SUM8

Summary of Contents for Wohler iVAM1-SUM8

  • Page 1: User Guide

    Multi-Channel Audio/Video Monitor/Mixers User Guide Part Number 821839, Revision B...
  • Page 2 In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Table of Contents User Guide ..................1 TABLE OF CONTENTS ................3 Table of Contents ................... 3 CHAPTER 1: Installation ............... 7 Introduction ....................7 Overview .................... 7 Safety ......................8 Instructions ..................8 Safety Symbols ..................8 Mounting.....................
  • Page 4 Speaker Options................. 33 Unit Configuration ................34 Meter Scales..................36 Phase Configuration................38 HDMI Settings ................... 39 Analog Configuration ................40 System Options Menu ................. 41 Network Settings................41 System Reboot .................. 43 System Update .................. 44 Factory Reset ..................45 System Information ................
  • Page 5 Headphone jack is inserted?..............78 What are AoIP-Pair 9 and AoIP Pair 10? ..........79 How do I ensure that my outputs are pre-faded but follow the solo-mutes on the web interface? This will allow us to monitor only the unmuted/solo Audio Meter channels on amplified stereo speakers connected to the Analog XLR’s.
  • Page 6 Getting Started | Ins/Outs ..............118 Getting Started | I/O Router ...............118 Operation: ....................119 Connecting Remote Source to Local Sink ..........119 ZMAN Session Sinks ................119 ZMAN Session Sources ...............121 ZMAN Updating .................121 APPENDIX E: API Documentation ............122 Introduction ....................122 API: Presets ....................122 APPENDIX F: Out of Band Control............135 Introduction ....................135 SFP IP Address Configuration ................135...

  • Page 7: Chapter 1: Installation

    Analog inputs and outputs. Upgrade/license other signal formats and processing options, as and when needed, either initially or after purchase. Refer to the Specifications section of this manual or contact Wohler Sales for more information. The iVAM1-SUM is compact and simple to operate, with straightforward controls. It has a very wide format touch screen LCD display providing up to 8 or 16 high resolution level meters, depending upon the model.

  • Page 8: Safety

    Safety Instructions 1. Read, keep, and follow all of these instructions; heed all warnings. 2. Do not use this equipment near water. 3. Use only a dry cloth to clean the equipment. 4. Do not block any ventilation openings. 5. Do not install near any heat source such as a radiator, heat register, amplifier, or stove.

  • Page 9: Heat Dissipation

    the following clearances: Table 1-1: Clearance Recommendations Clearance Surface 24” Front 3” Rear 2” Sides 1.75” Top and Bottom (if either radiates heat) 0” Top and Bottom (if no heat) Heat Dissipation The ambient temperature inside the mounting enclosure should not exceed 40° Celsius (104°...

  • Page 10: Compliance

    When the mains plug or appliance coupler is used as the disconnect device, the disconnect device should remain operable. Compliance This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 11: Chapter 2: Local Operation

    The iVAM1-SUM can be operated easily and simply from controls on its front panel, as described in this chapter. It may be accessed remotely in two ways, via the Wohler Web GUI for administrative purposes or by third party equipment via Application Programming Interface (API) commands. The Wohler Web GUI is described in Chapter 4 of this manual.
  • Page 12 4. Headphone Jack: A 1/4" jack for an optional headphone is provided on the front panel. Speaker audio can be optioned to either mute or not mute when headphones are plugged in. This is set in the Speaker Options menu. If the speaker audio is set to mute with headphone insertion, and a headphone is plugged into the Headphone Jack, the following icon will appear at the center top of the display:...

  • Page 13: Rear Panel

    4. Network Port: This Ethernet port can connect to either a LAN or to a PC to let you perform administrative tasks remotely. The Wohler Web GUI is described in Chapter 4 of this manual. Third party equipment, connecting to the iVAM1-SUM via a LAN plugged into this port and using an API commands, can view and change product options, as well.
  • Page 14 Appendix E of this manual. 5. MADI BNC: (optional) The COAX input accepts an AES10 64-channel signal at 48 kHz sample rate. An optional license key must be purchased to enable this function. The COAX output is reclocked from the MADI source. When power to the iVAM1-SUM is not present, the COAX input and output are automatically connected together to allow the MADI signal to pass through.
  • Page 15 Ethernet. You must use the MN-Set configuration software to set up this option. It is available from Wohler Technologies Technical Service. d. SMTPE 2110 Receiver: This uses Multi-Mode 850 NM, LC fiber connectors. It allows the iVAM1-SUM to monitor SDI audio transmitted in real time over Ethernet.
  • Page 16 Option card. The source of these signals is the monitored audio channels as shown on meters 1 - 8. Tascam cables may be used, and can be purchased by contacting Wohler Sales. Refer to Figure 2-6 for the pinout of this connector.
  • Page 17 Figure 2-6: Analog DB-25F Input and Output Connections Pair 1 Pair 2 Pair 3 Pair 4 17. AoIP SFP Module Cage (optional): This provides a location in which to insert the AoIP Module supplied with the OPT-DANTE (iVAM) and OPT RAVENNA 64 (iVAM) options.

  • Page 18: Sfp-2022-6 / Sfp-2110 Address Setup

    To integrate it into your digital network, you need to set its address to the source to be monitored. You must use the MN-Set configuration software to set up this option. It is available from Wohler Technologies Technical Service. The procedure to accomplish this is described in the SFP-2022-6 / SFP-2110 Setup Guide (part number 821822), which is available at https://wohler.com/downloads/...

  • Page 19: Channel Meter Screen

    Channel Meter Screen Audio meters, as well as other indicators are displayed on the wide touchscreen LCD display in Clusters which can be set up as single channels or stereo pairs, as shown in Figure 2-8. Figure 2-8: Audio Level Meter Screen 1.

  • Page 20: Operating The Monitor

    Preset, press and hold the Channel Trim knob for 3 seconds. 7. Loudness Cluster Indicator: The current selected Cluster which is undergoing Loudness analysis is indicated by an orange bracket. 8. Loudness Reading: This indicator displays the Loudness of the selected Cluster.

  • Page 21: Adjust The Trim Of A Cluster

    to monitoring the Clusters the way they were before the solo. Adjust the Trim of a Cluster Select the Cluster to be trimmed using one of the above methods. With the Trim Dial highlighted, rotate the Channel Trim knob. Trim can be adjusted in 1 dB steps from -60 dB to +12 dB.

  • Page 22: Video Screen

    Video Screen Information about the signal can be superimposed over the upper part of the video image. The Video Info selection in the Unit Config Menu determines whether this information is always displayed, never displayed, or is only displayed for the first 5 or 10 seconds after switching to the video screen.

  • Page 23: Menu / Option Touchscreen

    Menu / Option Touchscreen You may set most options or view a variety of system information using the self- contained menus. To access the Main Menu, touch the Menu button which appears on the upper left of the level meter screen or press the Source/Preset knob for 2 seconds.

  • Page 24: Main Menu

    Main Menu Touch the Menu button or press the Source/Preset knob to access the Main Menu. The Main Menu is shown in Figure 2-11. You may simply touch your selection or rotate the Source/Preset knob to navigate to your choice. As you rotate the Source/Preset knob, each selection button will highlight.
  • Page 25 shown in Figure 2-13. You may touch your selection or rotate the Source/Preset knob to navigate to your choice. As shown in Figure 2-13, the Source knob is located at the lower left of the Loudness Meter Screen. If the Source Knob Select setting in the Unit Config menu is set to Cluster Select, then rotating the Source knob will adjust the channel cluster source of the Loudness measurement.
  • Page 26 calculated loudest and softest passage over the program period (shown as LRA -0.1 above). 2. The Average Loudness is the average of all calculated loudness measurements made over the Program period (shown as PROG - 20.5 above). 3. The Maximum Loudness is the maximum calculated loudness over the program period (shown as MAX -20.1 above).

  • Page 27: Loudness Settings

    Loudness Settings Touch the Loudness Settings button on the Loudness Menu to display the Loudness Settings screen. This screen allows you to change between Manual and Continuous Monitoring Modes, and also to set the Alarm mode. It also provides a summary of various Loudness settings, as set in the Configuration | System Preference | Loudness Configuration tab of the Web GUI.

  • Page 28: Source Select

    This screen also shows sources which are unlicensed and therefore nonfunctional. These sources are shown in a gray color. To license these sources so that they may be used, contact Wohler Technologies. Figure 2-14 shows the Source Select Menu. Figure 2-14: Source Select Menu Touch Menu to exit this menu.
  • Page 29 Menu Back Analog Valid license is required DB25 This selection requires a license from Wohler to enable. Please call at +1-510-870-0810 or email at support@wohler.com. Thank you! Back Touch Back to return to the Source Select menu or touch Menu to return to the Main Menu.

  • Page 30: Presets

    Presets Presets are pre-arranged input and monitoring setups that can be used to monitor a variety of combinations of inputs. They may be set up to allow quick and easy selection of monitoring configurations for various productions and situations. If you have not set up any Presets, use the Configure Presets page in the Web GUI to do so.
  • Page 31 Figure 2-18: All Presets Screen - Preset Selection To select a Preset, touch your selection or rotate the Source/Preset knob to navigate to your choice and then press it. touch the associated button. After a quick 2-second delay, the metering screen will display the channels contained in that source.

  • Page 32: Preset Favorites

    Preset Favorites Touch the Preset Favorites button to display the Preset Favorites screen. This shows the Presets that you have designated as Favorites. Refer to the Dashboard section of Chapter 4. Generally, these are frequently used Presets that you want to separate out from the possibly many other Presets in the system.

  • Page 33: Unit Settings

    Unit Settings Touching the Unit Settings selection on the Main Menu screen proceeds to the Unit Settings Menu, which contains additional menu selections. You may touch your selection or rotate the Source/Preset knob to navigate to your choice and then press it. The Unit Settings Menu is shown in Figure 2-22.

  • Page 34: Unit Configuration

    attenuation level of the internal speakers. The value ranges from 0 to -255 dB. 0 results in full volume and -255 causes the speakers to be muted. 2. Treble: This tone control adjusts the high frequency speaker audio response from -12 dB to +12 dB. Lowering Treble compensates for high frequency pre-emphasis or removes sibilance effects.
  • Page 35 a. Always On: The video information is always displayed. b. Off: The video information is never displayed. c. 5 Secs: The video information is displayed for 5 seconds after the video screen is selected and then it disappears. d. 10 Secs: The video information is displayed for 10 seconds after the video screen is selected and then it disappears.

  • Page 36: Meter Scales

    Meter Scales Touching the Meter Scales button on the Unit Settings Menu displays the Meter Scales screen as shown in Figure 2-25. The controls on this screen select the scale standards as well as the ballistics that will be applied to the audio meters. Figure 2-25: Meter Scales Screen The controls function as follows: 1.
  • Page 37 Table 2–4: Meter Limits and References Default Color Default Ballistics Default Bounds Scale Bottom Limit Top Limit Reference Lower Upper Float -72 dBFS 0.0 dBFS 0 dBFS = 0 dBFS -30 dBFS -20 dBFS Type I VU -53 dBr +5.5 dBr -15 dBFS = 0 dBr -5 dBr 0 dBr...

  • Page 38: Phase Configuration

    Phase Configuration Touching the Phase Config selection on the Unit Settings Menu proceeds to the Phase Config Menu. This menu is shown in Figure 2-27 for each of the iVAM1- SUM models. Figure 2-27: Phase Configuration Menu Phase Phase Cancel & Exit Save &...

  • Page 39: Hdmi Settings

    HDMI Settings Touching the HDMI Settings selection on the Main Menu proceeds to the HDMI Settings menu, as shown in Figure 2-28. Figure 2-28: HDMI Settings Menu The controls in this menu function as follows: 1. HDMI Display: Set to On or Off to enable or disable the HDMI Output on the rear panel.

  • Page 40: Analog Configuration

    Analog Configuration Touching the Analog Config button in the System Options Menu displays the Analog Config screen. Contained in this menu is an Analog Reference as illustrated in Figure 2-29. The parameters set on this screen pertain to the Analog Input and Analog Output DB25 and XLR connectors on the rear panel of the iVAM1-SUM.

  • Page 41: System Options Menu

    System Options Menu Touching System Options in the Main Menu proceeds to the System Options menu, which is an intermediate menu leading to other screens. This menu is shown in Figure 2-30. Figure 2-30: System Options Menu System Options Menu Network System Settings...
  • Page 42 Figure 2-32: Network Configuration: Setting Change 2. Touch the digits to be entered and then touch the Enter button. The Clear button may be touched to erase any mistyped digits. 3. Now repeat steps 1 and 2 until you have replaced all of the necessary digits. 4.

  • Page 43: System Reboot

    Figure 2-34: System Reboot If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.

  • Page 44: System Update

    System Update Touching the System Update selection in the System Options Menu displays System Update screen as shown in Figure 2-35, showing the current software version of the product. To update the system software locally from the iVAM1-SUM front panel, follow the procedure in the Local Update from the Front Panel section of Appendix A.

  • Page 45: Factory Reset

    Mac address 28.) If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.

  • Page 46: System Information

    System Information Touching the System Details selection in the System Options menu displays the System Details screen as shown in Figure 2-37. This screen lets you view the product Serial Number, Software Version, and various other information. Figure 2-37: System Details Screen The information shown on this screen is read only and cannot be changed.

  • Page 47: Passcode Settings

    To prevent accidental or unauthorized changing of critical settings in some of the menus, it is possible to block or restrict access to various menus. The Wohler Web GUI can be used to limit access to the menus of your choice. Refer to Chapter 4, the Front Panel Configuration tab of System Preferences.
  • Page 48 When you have successfully entered the Passcode, the Passcode Settings screen will appear, as shown in Figure 2-40. Figure 2-40: Passcode Settings Screen The functions on this screen are as follows: Restricted Access: This switch will turn ON or OFF protection or blocking of any menus, except for the Passcode Settings menu, which is always Passcode protected.

  • Page 49: Forgotten Passcode

    Although the Passcode should be remembered or securely noted somewhere, it can happen that it is forgotten. This can be remedied by performing a Factory Reset from the Wohler Web GUI. Unfortunately, this will also erase all of the menu settings. You may also contact Wohler Technical Service for help.

  • Page 50: Chapter 3: Technical Info

    CHAPTER 3: Technical Info Table 3–1: iVAM1-SUM Specifications Specification Values/Domains Power Requirements 100 VAC to 240 VAC ± 10%, 50/60Hz Power Consumption 65 Watts Dimensions 1.75” x 19” x 5.5” (44mm x 483mm x (H x W x D) 140mm), standard 19” rack mounting Shipping/Net Weight 8 lbs.
  • Page 51 Specification Values/Domains Optional - SFP Receiver: • Multi-Mode Fiber: LC Connectors, SMPTE 2110 Receiver 850nm COAX (such as Belden 1694A): > 150 m Cable/Fiber Length (max) Single-mode fiber: 10 km AES Inputs 8 AES channels on HD-15 are optional AES Outputs 8 AES channels on HD-15 Upgrades Via USB or GUI web interface...
  • Page 52 Table 3–2: iVAM1-SUM Options Option Part # Description MADI optical fiber transceiver. Multi-Mode, LC SFP-MM-MADI- 829081 (fiber) connectors. SFP module with software Fiber activation key. MADI optical fiber transceiver. Single-Mode, SFP-SM-MADI- 829082 LC (fiber) connectors. SFP module with Fiber software activation key. 3G/HD/SD-SDI single video receiver with SFP-SDI 829089...
  • Page 53 **MN-Set is configuration software that is necessary so that you can set up this module. It is available at no cost either from its manufacturer, Embrionix, or by contacting Wohler Technologies Technical Service. Table 3–3: iVAM1-SUM Option Cards Option...
  • Page 54 Figure 3–1: iVAM1-SUM Block Diagram 3G-SDI Input 1 HDMI Output Video from SDI 1, 2, or SFP 3G-SDI Input 2 Touchscreens for Audio Meters (8 or 16 Meters) 3G-SDI Output Audio from SDI 1, 2, or SFP Menu HD/1080p 59.94Hz SDI-1 LKFS-M : -20.5 Monitoring...

  • Page 55: Chapter 4: The Ivam1-Sum Web Gui

    CHAPTER 4: The iVAM1-SUM Web GUI The self-contained iVAM1-SUM Web GUI allows you to customize the configuration of the iVAM1-SUM to suit your needs. If the default configuration suits your needs and you prefer to use it that way, then you do not need to use the iVAM1-SUM Web GUI.

  • Page 56: Network Connection

    Figure 4–1: Host IP Settings Close the control panel and reboot the host computer after making an IP address change to be sure the change takes effect. Either reconnect to the installed network or continue with this direct connection to access the iVAM1-SUM Web GUI.

  • Page 57: Network Setup

    Network Setup Make network IP Address changes for the local iVAM1-SUM Management (MGMT) Port here. Figure 4–2: Set IP Addresses iVAM-SUM The procedure for changing the IP Address information is as follows: 1. Use DHCP? Check this box if your network has a DHCP server and you want to use dynamic addressing.

  • Page 58: Dashboard

    Dashboard Throughout the Web GUI, pages are a click or two away using the list of selections on the left side. The Dashboard page shows all of the available Preset configurations at a glance. The iVAM1-SUM allows you to assign Presets to particular groups.
  • Page 59 In Figure 4-4, it can be seen that there are five Presets in the Operator-1 group and no Presets in the Operator-2 group. The currently selected active Preset for local operation is shown in red. In Figure 4-4, this is the Preset named SDI-1. Figure 4–4: Dashboard Preset Recall / Edit Favorite / All Group / Preset...
  • Page 60 Figure 4–5: Dashboard Preset Edit The Edit options for a Preset are: 1. Delete: Remove the Preset from the system. Do Not delete the currently active Preset. 2. Rename: Rename the Preset, but keep all of its other characteristics. 3. Make Favorite: Make this Preset a favorite. This can be done for frequently used Presets.
  • Page 61 Figure 4–6: Dashboard Group Edit The Edit options for a Group are as follows: 1. Delete: Delete the Group and all of the Presets it contains. 2. Rename: Rename the Group, but keep all of its other characteristics. Page 61 iVAM1-SUM...

  • Page 62: Audio Meters

    Audio Meters Click on Audio Meters to remotely display the audio meters of the iVAM1-SUM. This display is shown in Figure 4-7. Also displayed is the name of the source that the meters are displaying. In Figure 4-7, this is SDI/BNC-1. Figure 4–7: Audio Meters Display iVAM-SUM Page 62...

  • Page 63: System Preferences

    System Preferences Click on System Preferences to find the System Audio Clock Reference, Loudness Configuration and Phase Indicator Configuration, and Front Panel Configuration tabs. These are as shown in Figures 4-8, 4-9, 4-10, and 4-11. System Audio Clock Reference The System Audio Clock Reference setting provides a way to set the global clock source for the unit.

  • Page 64: Loudness Configuration Tab

    Loudness Configuration Tab The Loudness Configuration tab allows you to make settings which will determine how Loudness is to be calculated on the Loudness Meter. This tab is shown in Figure 4-9. Figure 4–9: Loudness Configuration Tab The following settings can be made on this tab: 1.

  • Page 65: Phase Indicator Configuration Tab

    a. Manual: Touch the Manual button to enable Manual Mode. This allows you to measure the loudness of a specific program or segment of a program, such as a commercial. In this mode, the Start and Stop button on the Loudness Meter screen can be manually used to begin and end a loudness measurement interval.

  • Page 66: Front Panel Configuration Tab

    Continue button to try again. If you have forgotten the Passcode, this can be remedied by performing a Factory Reset. Unfortunately, this will also erase all of the menu settings. You may also contact Wohler Technical Service for help. Figure 4-12: Unrecognized Passcode...
  • Page 67 When you have successfully entered the Passcode, the Passcode Settings screen will appear, as shown in Figure 4-13. Figure 4-13: Front Panel Configuration Tab Enable / Disable Menu Access iVAM-SUM The functions on this screen are as follows: Enable Restricted Access for Front Panel Configuration: This switch will turn ON or OFF protection or blocking of any local product menus, except for the Passcode Settings menu, which is always Passcode protected.
  • Page 68 Figure 4-14: Examples of Local Menu Protection Passcode Access: No Access: System Options System Options Menu Menu Network System Network System Settings Reboot Settings Reboot System System Factory Factory Update Update Reset Reset System Passcode System Passcode Details Settings Details Settings Page 68 iVAM1-SUM...

  • Page 69: Preset Management

    Preset Management Presets are monitoring configurations that can be composed of channels from multiple sources and displayed on the meters in any order. Presets should be set up to allow operators to quickly shift between setups for monitoring. The Preset Management screen contains selections of all of the details for a Preset, and is largely arranged in a matrix format connecting input channels to monitoring channels.
  • Page 70 2. System Clock Reference: There must be a system clock reference for monitoring to take place. Select a reference from the pull down list. The best choice is a stable, always present clock source locked to house sync. Second to that, use the selected input as the clock. Generally speaking, Internal is not the best choice.
  • Page 71 7. Speaker Assign: Speaker assignments are made automatically when a cluster is set. However, it can be that in an actual signal, the channel assignments may be different than what the automatic assignment assumes. A speaker assignment adjustment is provided for each channel, should you need to override the automatic settings.

  • Page 72: Output Routing

    Six or eight channels could be directed to the AES outputs, which could feed an external surround sound system. Contact Wohler Sales to purchase the license for the OPT-OUTPUT- ROUTING feature.

  • Page 73: Destination Outputs

    Figure 4-17: Global Output Routing Option Global Output Source Output Destination Routing Inputs Options Outputs Destination Outputs On the left of the Global Output Routing screen are listed the Destination Outputs. These are the outputs to which any input can be routed. They are as follows: 1.

  • Page 74: Source Inputs

    route these channels appropriately. 8. AoIP/Pair-10 (DANTE / RAVENNA): Selected inputs will be mixed to Channel 19 and Channel 20. Use a Dante Controller or Aneman/Zman web interface to route the remaining pairs appropriately. 9. HDMI/Pair-1: Selected inputs will be mixed to the left and right channels and played through first pair of the HDMI Output.

  • Page 75: Typical Questions Regarding Output Routing

    2. Solo/Mute: This setting determines whether or not the outputs are affected by solos and mutes. The Speaker/Headphone output is always affected by solos and mutes. Note also, that all outputs in Speaker Mix mode also are affected by solos and mutes. 3.

  • Page 76: What Is The Difference Between Global Output Routing And Output Routing In Presets

    What is the difference between Global Output Routing and Output Routing in Presets? Both are used to configure the unit outputs. Global Output Routing is applied by default when you select a source or when creating presets and when you don’t change the Output Routing unique to any Preset.

  • Page 77: How Do I Route Only Specific Monitored Channels To The Analog Xlr Outputs

    The setting shown above determines that outputs will follow the Audio Meter screen solos & mutes for the XLR outputs because the checkbox is checked. It is not checked for the AES outputs, so they will not be affected by the solo & mute choices.

  • Page 78: How Do I Keep The Internal Speakers Muted And Have Audio Only On The Analog Xlr Outputs

    How do I keep the internal speakers muted and have audio only on the analog XLR outputs? When the optional OPT-OUTPUT-ROUTING license is purchased, in the Global Output Routing configuration, do not select any Speaker Headphone checkboxes for any meter channels as shown below, and then select the desired meters for Analog XLR.

  • Page 79: What Are Aoip-Pair 9 And Aoip Pair 10

    What are AoIP-Pair 9 and AoIP Pair 10? AoIP-Pair 9: Selected inputs will be mixed to AoIP transmit channels 17 and 18. Note that configuration for channels 1 - 16 is not supported. Use a Dante Controller or Zman web interface to route these channels appropriately. AoIP-Pair 10: Selected inputs will be mixed to Channel 19 and Channel 20.

  • Page 80: Global Evertz Routing

    Global Evertz Routing Evertz Quartz routing is a protocol that allows for exchanging source labels in a facility. This improves the interoperability of equipment of various manufacturers in a facility. When Global Evertz Routing is selected, the menu shown in Figure 4-18 appears.
  • Page 81 Status will indicate Invalid Address. Enter the Host Address and Port of the Evertz Quartz server in the Quartz Server Setup section. For assistance, contact Wohler Technical Service. Click the Apply button to enable Evertz Quartz compatibility. When Evertz Quartz compatibility is enabled and connected, this screen changes as...
  • Page 82 Figure 4-22: Preset Setup Screen Apply Global Quartz Routing Tab The Global Quartz Routing Tab will display the Quartz Server Setup and allow you to decide whether Global Quartz Routing will apply to this Preset. Page 82 iVAM1-SUM...

  • Page 83: Preset Replication

    Preset Replication Preset Replication allows you to copy presets from a master unit to multiple iVAM1- SUM units. This can save a lot of setup time if multiple units all need basically the same setup. To start Preset Replication, click on the Preset Replication tab on the master unit. This will start the unit discovery process and will list all the iVAM1-SUM units that you currently have on your network.
  • Page 84 Figure 4-24: Preset Replication Target Selection Screen Click either From Master Unit or Select Preset File. This determines the source of the Presets to be copied. Preset Files would be files that you have previously stored in the computer running the Web GUI. You may add a descriptive name or version to the Presets being copied.

  • Page 85: Import/Export Presets

    Import/Export Presets Use the Import / Export Presets page to manage the Preset database in the iVAM1-SUM. You may export the Preset database onto the computer hard drive for security backup purposes or as a means to transfer it to another iVAM1-SUM. Likewise, it can be used to import a Preset database from the computer hard drive into the iVAM1-SUM.

  • Page 86: Import Configuration

    4. Click Yes to proceed with writing the Preset data to the hard drive. The copying will proceed. After the Preset data has been written, the screen in Figure 4-26 will appear, explaining what has been exported in an Export Presets Summary.
  • Page 87 Figure 4–27: Database Import iVAM-SUM Download all Presets from your iVAM-SUM unit onto your computer. Upload Presets from a file to your iVAM-SUM unit. Page 87 iVAM1-SUM...

  • Page 88: System

    These tabs are explained in the following three sections. System Information This tab displays a variety of information about the iVAM1-SUM. It is shown in Figure 4-28. This information could be useful to view if you are contacting Wohler Technical Service. Figure 4–28: System Information Tab...

  • Page 89: Sfp Information

    It is shown in Figure 4-29. This information could be useful to view if you need to ascertain what module, if any, is installed, or if you are contacting Wohler Technical Service. Figure 4-29: SFP Information Tab Note: SFP Information, as shown in lower half of Figure 4-29, can be used to retrieve the 2110 or 2022 SFP Module network configurations.

  • Page 90: Licenses

    It is shown in Figure 4-30. You will use this tab to enter any new license numbers that you purchase. Contact Wohler Sales to obtain new license numbers. If you need help, Wohler Technical Service will be happy to assist you in installing these numbers.

  • Page 91: Factory Reset

    If you have any doubt as to whether you should perform a Factory Reset, do not click the Initiate Factory Reset button. Contact Wohler Technical Service for advice. Factory Reset will also reset your IP address to the default one. After a Note: Factory Reset, the IP Settings will need to be updated.

  • Page 92: Reboot System

    Reboot System page is shown in Figure 4-32. This function is normally only used upon request from Wohler Technical Service to troubleshoot or correct an issue. The Reboot System function should be used with a bit of caution. It puts the iVAM1-SUM out of service for several minutes while it is rebooting, and this may unexpectedly interfere with the use of the product by the remote operator.

  • Page 93: Appendix A: Software Upgrades

    Product Downloads on the Products > iVAM1-SUM page, in Support > Downloads > Drivers & Software, or contact Wohler Customer Support for more information. Unzip the downloaded update files to reveal two files. One will have a suffix of .wx and the other will have a suffix of .md5sum.

  • Page 94: Local Update From The Front Panel

    Local Update from the Front Panel Use the following steps to update the iVAM1-SUM software: 1. Copy the unzipped Wohler Update Package file(s) from your computer to the root directory (not inside of a folder) of a USB flash drive. It must be FAT32 file type, and does not need to be empty.
  • Page 95 Do you want to Update your Software Version 3.4-39 System to 1.0.1? Wohler iAM-AUDIO 3.4-56 6. To proceed, touch Yes. To back out, touch No. After you touch Yes, the screens will change, as shown in Figure A-4. The left screen will display "Software Upgrade in Progress"...

  • Page 96: Updating Via The Web Gui Using A Flash Drive

    Updating via the Web GUI using a Flash Drive Use the following steps to update the iVAM1-SUM software: 1. Copy the unzipped Wohler Update Package file(s) from your computer to the root directory (not inside of a folder) of a USB flash drive. It must be FAT32 file type, and does not need to be empty.
  • Page 97 Figure A-6 – Available Software Updates 5. After clicking the System Update button, a verification screen displays as shown in Figure A-7. If you agree that the correct update version has been selected, click the Yes button. Figure A-7 – System Update Verification 6.

  • Page 98: Updating An Ivam1-Sum Remotely

    Web GUI. Connect to the iVAM1-SUM with the Wohler Web GUI. Navigate to the System | System Update menu. Click within the large blue dotted line rectangle at the right of the screen. A file selection window will open, as shown in Figure A-9.
  • Page 99 Figure A-10 – Invalid System File Version Figure A-11 – Invalid Checksum iVAM-SUM 3. At this point, wait for the update to complete. It may take several minutes, until the it is critical not to disturb the iVAM1-SUM or the Web GUI update process is complete.

  • Page 100: Updating Multiple Units Remotely

    The iVAM1-SUM units being updated will be temporarily out of service. 2. Use the Wohler Web GUI to connect to an iVAM1-SUM already containing the latest update. This will be referred to as the Master Unit. Navigate to the System | System Update | Remote System Update menu.
  • Page 101 Figure A-13 – List of Found iVAM1-SUM Units 4. Then click Update Selected Devices. The window shown in Figure A-14 will appear. Figure A-14 – Apply System Package 5. Click Apply System Update. The screen shown in Figure A-15 will appear. This screen contains a table showing the update progress of each of the iVAM1-SUM units being updated.
  • Page 102 Figure A-15 – System Update Progress 6. At this point, wait for each update to complete. It may take several minutes, it is critical not to disturb any of the iVAM1-SUM units or the Web until the update process is complete. When it is complete, each iVAM1- SUM will restart.

  • Page 103: Appendix B: Dante Network Setup

    On iVAM1-SUM, the AoIP source can be selected through the Source Select option. The iVAM1-SUM is set up at the Wohler factory to be used as a slave rather than a master within the Dante network. Other devices or software, such as a Dante Controller, are expected to be responsible for most device configurations and all audio routing.
  • Page 104 Card ID will be shown in red, e.g. Wohler-xxxxxx where xxxxxx is the last 6 hex digits of the card MAC address as shown in B-1. This usually indicates that the IP address of the card is not in the same subnet as the Dante Controller host.

  • Page 105: Dante Tm Device Setup

    Dante Device Setup The iAM1-SUM default Dante Device Name is “Wohler- …” followed by the last 6 digits of the Dante port MAC address, as shown in Figure B-2. This name can be changed by the Dante Controller to appear that way on the network, but that will not change the iVAM1-SUM unit name appearing on GUI pages and iVAM1-SUM Remote Metering or Discovery pages.

  • Page 106: Dante Clock Selection

    Other changes such as Latency settings can be made by the Dante Controller through the Device View menus. Some changes may require remote rebooting of the Brooklyn II card to take effect, temporarily interrupting audio and publishing the new information to the network. Important: Only 44.1 kHz and 48 kHz audio sample rates are currently supported by the iVAM-SUM.

  • Page 107: Aes67

    AES67 The iVAM1-SUM Brooklyn II can be configured for AES67 operation. Refer to Figure B-5. AES67 operation with Dante is limited to eight or less receive and transmit channels at 48 kHz sample rates. 24 bit linear (L24) encoding and 1 msec packet time are fixed default transmit parameters.
  • Page 108 Figure B–6: Device View - Network Config Page 108 iVAM1-SUM...

  • Page 109: Device Lock

    Device Lock command at this time. Dante Firmware Upgrades Wohler iVAM1-SUM monitors ship with current Brooklyn II firmware as of the option installation date. The version information is found in the Dante Controller Device View-Status page. iAM software/firmware is tested with the latest Dante code release.

  • Page 110: Additional Information

    Additional Information The following links are provided for those who need more information about the Dante controller or the Dante Firmware update manager. https://my.audinate.com/products/firmware-update-manager https://www.audinate.com/products/software/dante-controller https://dev.audinate.com/GA/dante-controller/userguide/pdf/latest Dante Legal Disclosures TRADEMARK ATTRIBUTION: Products covered in the manual include licence from Audinate Pty Ltd under US Patents 7747725, 8005939, 7978696, 8171152, European Patent 2255541, Chinese Patent ZL200780026677.0 and other patents pending or issued, see or such other...

  • Page 111: Appendix D: Ravenna (Zman) Setup

    APPENDIX D: Ravenna (ZMAN) Setup Introduction Installing the iVAM1-SUM into an existing and functioning Ravenna network using the Merging ZMAN Card is virtually plug and play. The iAM rear panel AoIP jack supports 1Gb/s and 100Mb/s Ethernet devices in Ravenna Audio over IP network configurations.

  • Page 112: Configuring The Aoip Merging Option Card

    The Merging Ravenna card runs specific firmware from Merging and augmented by Wohler for use within the iVAM1-SUM. The card will not function correctly if the user downloads and installs firmware from any source besides Wohler. The Wohler augmentation includes the ability to support 64 channels.

  • Page 113: Getting Started | General Settings

    item View is enabled. Do not proceed until the card shows on Aneman. Right click on that line and select Web Services: Advanced (or Ravenna) to bring up the Merging Ravenna configuration page. Also, the ICON of the card will appear in the main part of the Aneman screen.

  • Page 114: Getting Started | Ptp

    Getting Started | PTP This tab is shown in the following figure. This configuration page refers to how your Ravenna network is synchronized to clocks. Figure D-2: Getting Started | PTP The elements of this tab are as follows: 1. Global Settings: The default value for PTP a.

  • Page 115: Getting Started | Session Sources

    3. Status: a. Lock: This shows if the device is locked to PTP (Locked -Locking - Unlocked) b. Master: This is true or false for the current device. c. GMID: This is the current GrandMasterID (PTP Master) d. Delta (ns): This is the time delta between the device and the PTP master.

  • Page 116: Getting Started | Session Sinks

    8. Payload type: RTP Payload type - This value should not be modified. 9. Codec: The possible bit rate values are L24, L16, DSD64, DSD64_32, DSD128, DSD128_32, and DSD256. Note that these values are sampling rate dependent. 10.Frame size (samples): This the frame size of the current source. 11.DSCP: The audio DSCP should be set to 34 for RTP AES67 or 46 for RTP Ravenna.

  • Page 117: Getting Started | Session Info

    5. Manual: This allows manual entry of an SDP. 6. Delay (samples): This sets the playback delay. 0 is automatic delay. 7. Ignore RefClk GMID - accept source locked to any PTP master: This feature is useful when you want to connect a stream through Internet (for example with two PTP Masters (GPS) at each location.

  • Page 118: Getting Started | Ins/Outs

    Getting Started | Ins/Outs This tab allows you to change the name of the specific Inputs and/or Outputs. Figure D-5: Getting Started | Ins/Outs Getting Started | I/O Router This page allows remapping of incoming channels to different internal channel assignments.

  • Page 119: Operation

    Operation: Connecting Remote Source to Local Sink This instruction assumes another Ravenna device is active on the network and sourcing a multicast stream. The Merging Configuration section for Session Sink controls how to configure the card to receive the stream and provide it to the IAM interface for display on meters and speakers, etc.
  • Page 120 Figure D-7: Session Sinks Tab To avoid confusion if monitoring more than one Flow, especially if the various source Flows have overlapping channel numbers, use the matrix to direct Flows to higher channel ranges. For example, for monitoring 2 SDI sources (four 8 channel Flows), assign two flows to 1-8 and 9-16 and the next SDI signal to 17-24 and 25- 32.

  • Page 121: Zman Session Sources

    Figure D-8: Session Sources Tab ZMAN Updating The Zman card is pre-initialized with the correct Wohler firmware load. In case of future upgrades, use the following steps: 1. In Aneman, right click the ZMAN entry on the bottom Devices section, and select Maintenance Mode.

  • Page 122: Appendix E: Api Documentation

    APPENDIX E: API Documentation Introduction This appendix discusses ways to use the Application Program Interface (API) to allow third party equipment to remotely access options and settings of the iVAM1- SUM. It includes specific code examples for commonly used requests. The API uses JavaScript Object Notation (JSON) as its communication language.
  • Page 123 2. GET Preset Configuration Method: GET /api/cf/presets/<int:preset ID> Example Response: "error": null, "params": { "PresetId": "result": { "GroupId": 1, "Favorite": 0, "Data": { "Name": { "Preset": "SDI_Autofill", "Program": "", "Group": "newGrpNameSdi" "MeterSet": { "6": { "Speaker": "Right", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 2, "Type": "SDI",...
  • Page 124 "VolumeDb": "13": { "Speaker": "Left", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "14": { "Speaker": "Right", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb":...
  • Page 125 "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "10": { "Speaker": "Right", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "5": { "Speaker": "Left", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 2, "Type": "SDI",...
  • Page 126 "Speaker": "Right", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "11": { "Speaker": "Left", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "7": {...
  • Page 127 "InputIndex": "VolumeDb": "15": { "Speaker": "Left", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "Channel": 0, "InputNo": 0, "InputIndex": "VolumeDb": "1": { "Speaker": "Left", "DelayMs": 0, "Source": { "Slot": 0, "Cage": 2, "Type": "SDI", "ConnectorType": "BNC", "Channel": 1, "InputNo": 1, "InputIndex":...
  • Page 128 "NumberOfMeters": 2, "FirstMeter": 1, "Type": "Stereo", "MuteOnPresetRecall": true "Name": "Stereo 2.0 #2", "NumberOfMeters": 2, "FirstMeter": 3, "Type": "Stereo", "MuteOnPresetRecall": true "Name": "Stereo 2.0 #3", "NumberOfMeters": 2, "FirstMeter": 5, "Type": "Stereo", "MuteOnPresetRecall": true "Name": "Stereo 2.0 #4", "NumberOfMeters": 2, "FirstMeter": 7, "Type": "Stereo", "MuteOnPresetRecall": true...
  • Page 129 "Type": "Stereo", "MuteOnPresetRecall": true "DolbyInputSource": { "Slot": 0, "Cage": 0, "Type": "None", "ConnectorType": "None", "InputNo": 0, "Pair": "VideoSource": { "Slot": 0, "Type": "None", "InputNo": "ConnectorTypeOptions": { "0": { "MADI": { "1": { "MADI": { "ConnectorTypeOption": "BNC" "ApplyCdlb": true, "ApplyCor": true, "SpeakerDelayMs": 0, "AudioOutputRouting": null, "SystemClockSource": {...
  • Page 130 3. GET list of groups/presets Method: GET /api/cf/groups Example Response: "params": null, "error": null, "result": [ "Presets": [ "Favorite": 0, "Id": 3, "Name": "SDI_Autofill" "Favorite": 0, "Id": 2, "Name": "SDI_Manual" "Id": 1, "Name": "G1" 4. GET to recall the preset Method: GET api/op/presets/<int:presetID>/activate Example Response:...
  • Page 131 "PresetId": 5. POST to delete the group Method: POST api/op/group/<int:groupID>/delete Example Response: "params": { "GroupId": "error": null, "result": { "GroupId": 6. POST to delete the preset Method: POST api/op/preset/<int:presetID>/delete Example Response: "params": "PresetId": "error": null, "result": "PresetId": 7. POST to rename group Method: POST /api/op/group/<int:groupID>/newGrpNameSdi/rename Example Response:...
  • Page 132 "error": null, "result": { "GroupId": 1, "GroupName": "newGrpNameSdi" 8. POST to rename preset Method: POST /api/op/preset/<int:presetID>/newPresetNameTest/rename Example Response: "error": null, "params": { "PresetId": 1, "PresetName": "newPresetNameTest" "result": { "PresetId": 1, "PresetName": "newPresetNameTest" 9. POST to set preset as Favorite Method: POST /api/op/preset/<int:presetID>/<favoriteVal>/favorite Example Response: "error": null,...
  • Page 133 Source Select Method: POST /api/op/sourceselect 1. Body content for SDI/SMPTE-2022-6/ SMPTE-2110 "SourceType": “<String: SDI Input Source>”, "ChannelGroup": <Int: 1-2> Note: Allowed SDI input sources are: "Bnc-1.Sdi", "Bnc-2.Sdi", "Sfp-1.Sdi", "Sfp-1.Smpte2022", "Sfp-1.Smpte2110", e.g. "SourceType": "Sfp-1.Smpte2022", "ChannelGroup": 2. Body content for MADI "SourceType": <String: MADI Input Source>, "ChannelGroup": <Int: 1-8>...
  • Page 134 "SourceType": "Analog.DB25" 4. Body content for Aes "SourceType": "Aes" 5. Body content for Aoip "SourceType": "Aoip", "ChannelGroup": <Int: 1-8> Note: ChannelGroup 1 => Channels 1-8 and ChannelGroup 2 => Channels 9-16 and so on 6. Body content for TOSLINK "SourceType": "Toslink" Example Response: "unit_name": "", "model": "iVAM1-SUM",...

  • Page 135: Appendix F: Out Of Band Control

    SFP IP Address Configuration You may change the IP address of a 2110 or 2022-6 SFP. This can be done using the System Setup | Sfp Information | Network tab of the Wohler Web Server, as shown in Figure F-1.

  • Page 136: Sfp System Configuration

    You may change the Personality of an SFP using the System Setup | SFP Information | Personality tab of the Wohler Web Server. If the Embrionix SFP is a combo SFP module, you may also switch from 2110 to 2022 using this feature. All the personalities loaded on a SFP are displayed on the tab, as shown in Figure F-2.

  • Page 137: Sfp 2110 Configuration

    SFP 2110 Configuration If a 2110 firmware is loaded, the Wohler Web-GUI can be used to configure Audio/Video Flows of the SFP. The Out of Band On/Off Switch at the top of the SFP 2110 Global Setup page controls whether the out of band settings will be applied to the SFP or not.
  • Page 138 Figure F-4: Out of Band Switch: On Position You may define a global configuration using the “SFP 2110 Global Setup” or define it on per Preset basis. Refer to the SFP 2110 Preset Setup section later in this Appendix. The global configuration will be used for Source Select. Refer Figures F-3 and F-4 for Video parameters.
  • Page 139 Figure F-6: Audio Parameters Figure F-7: PTP Parameters Page 139 iVAM1-SUM...

  • Page 140: Sfp 2110 Preset Config

    SFP 2110 Preset Config SFP 2110 Configuration may be performed by Preset. Click the SFP Config button on the Preset Management screen, as shown in Figure F-8. Figure F-8: SFP 2110 Preset SFP Configuration Enable SFP Config After clicking the SFP Config button, the SFP 2110 Setup Screen will appear, as shown in Figure F-9.

  • Page 141: Diagnostic Information

    Figure F-9: SFP 2110 Setup Screen Diagnostic Information In addition to the configuration parameters, a Diagnostic Info pages exist to show the current flow information for a 2110 or 2022 SFP. This page is auto refreshed every 10 seconds to fetch the latest information from the SFP. The diagnostic information is always available even when the “Out of band”...
  • Page 142 Figure F-11: Diagnostic Information Figure F-12: Diagnostic Information Page 142 iVAM1-SUM...

This manual is also suitable for:

Ivam1-sum16

Table of Contents
