USE AND INSTALLATION MANUAL
GB
SEALED PELLET STOVE
CUTE AIR 8 M1
PART 1 - REGULATIONS AND ASSEMBLY
Instructions in English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CUTE AIR 8 M1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MCZ CUTE AIR 8 M1

Summary of Contents for MCZ CUTE AIR 8 M1

  • Page 1 USE AND INSTALLATION MANUAL SEALED PELLET STOVE CUTE AIR 8 M1 PART 1 - REGULATIONS AND ASSEMBLY Instructions in English...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................II INTRODUCTION ......................1 1-WARNINGS AND WARRANTY CONDITIONS ..............2 2-INSTALLATION ......................8 3-DRAWINGS AND TECHNICAL FEATURES ..............17 4-UNPACKING ......................20 5- SMOKE OUTLET .....................23 6-INSTALLATION AND ASSEMBLY ................27 7-DOOR OPENING .....................30 8-USB SOCKET ......................31 9-ELECTRICAL CONNECTION..................32 10-LOADING THE PELLETS ..................33...

  • Page 3: Introduction

    No part of this manual may be translated into other languages, adapted and/or reproduced, even in part, in other mechanical and/or electronic form or media, for photocopies, recordings or other, without the prior written authorisation of MCZ Group Spa. The company reserves the right to make changes to the product at any time without prior notice. The owner company reserves its rights according to law.

  • Page 4: 1-Warnings And Warranty Conditions

    1-WARNINGS AND WARRANTY CONDITIONS SAFETY WARNINGS • The installation, electrical connection, operating test and maintenance must only be carried out by a qualified operator. • Install the product in compliance with the laws and regulations in force. • Only use the fuel recommended by the manufacturer. The product must not be used as an incinerator.
  • Page 5 1-WARNINGS AND WARRANTY CONDITIONS • Do not dry laundry on the product. Any drying racks or the like must be kept at a safe distance from the product. Fire hazard. • The product maintenance operations must be exclusively carried out by a qualified operator on a yearly basis.
  • Page 6 1-WARNINGS AND WARRANTY CONDITIONS • Do not allow the product to come into contact with water, it contains live electrical parts. • Do not wash the product with water (or other liquids) as they could penetrate inside the unit, damaging the electrical insulation with the risk of electrocution. • Do not use detergents to wash the stove, they could damage the aesthetic parts of the product.
  • Page 7 1-WARNINGS AND WARRANTY CONDITIONS • The sound pressure level of this appliance does not exceed 70 dB(A). • Live electrical parts: only power the product once it has been fully assembled. • Disconnect the product from the 230V power supply before performing any maintenance operations.

  • Page 8: Intended Use

    1-WARNINGS AND WARRANTY CONDITIONS INFORMATION: • Please contact the retailer or qualified personnel for any information, problem or malfunction. • Only use the fuel specified by the manufacturer. • When the product is switched on for the first time, it is normal for it to emit smoke due to the paint heating up for the first time. Therefore make sure the room it is installed in is well-ventilated.
  • Page 9 1-WARNINGS AND WARRANTY CONDITIONS WARRANTY CONDITIONS For the duration, terms, conditions, limitations of the MCZ conventional warranty, please refer to the specific warranty card that is included with the product. Information for management of waste electrical and electronic equipment containing batteries and accumulators This symbol appears on the product, on the batteries, on the accumulators or on their packaging or on their documentation;...

  • Page 10: Warnings For The Correct Disposal Of The Product

    1-WARNINGS AND WARRANTY CONDITIONS WARNINGS FOR THE CORRECT DISPOSAL OF THE PRODUCT The owner is the sole party responsible for demolishing and disposing of the product. This must be performed in compliance with laws related to safety and environmental protection in force in his/her country. At the end of its working life, the product must not be disposed of as urban waste.
  • Page 11 1-WARNINGS AND WARRANTY CONDITIONS LEGENDA WHERE TO DISPOSE MATERIALS Metal Glass If there is any, to be disposed of separately based on the material used: Tiles or ceramics OUTER CLADDING Stone Glass ceramic (fire door): to be disposed of with inert or mixed waste If there is any, to be disposed of separately based on the material used: Tempered glass (oven door): to be disposed...
  • Page 12 1-WARNINGS AND WARRANTY CONDITIONS Our solid bio-combustible products, (hereinafter called “Products”) are designed and manufactured in compliance with one of the following European standard harmonised to Regulation (UE) no. 305/2011 for construction products: EN 14785: “Residential space heating appliances fired by wood pellets” EN 13240: “Room heaters fired by solid fuel.”...

  • Page 13: 2-Installation

    2-INSTALLATION The instructions in this chapter refer explicitly to the Italian installation regulation UNI 10683. In any case, always observe the regulations in force in the country of installation. PELLETS The pellet is obtained from natural dried wood sawdust (without paint). The compactness of the material is guaranteed by the lignin contained in the wood itself, without glue or binders.
  • Page 14 2-INSTALLATION FOREWORD The heating system (generator + combustion air supply + combustion product expulsion system + any hydraulic/aeraulic system) must be installed in compliance with the laws and regulations in force , and carried out by a qualified technician, who must issue a declaration of conformity of the system to the system manager and shall undertake full responsibility for final installation and consequent good operation of the product.

  • Page 15: Minimum Distances

    2-INSTALLATION MINIMUM DISTANCES Observe the distances from flammable objects (sofas, furniture, wood panelling, etc..) as specified in the following diagram. If objects considered to be particularly sensitive to heat are present, such as furniture, curtains or sofas, as a precaution, increase the stove clearances substantially to avoid possible deterioration due to the effect of heat.
  • Page 16 2-INSTALLATION In any case, ensure adequate distance to facilitate access during cleaning and extraordinary maintenance. If this is not possible, it must still be possible to distance the product from adjacent walls/elements. This operation must be performed by a technician qualified to disconnect the combustion product expulsion ducts and their subsequent restoration.
  • Page 17 2-INSTALLATION Below 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Above 15kW: Air duct diameter Maximum length Maximum length (smooth duct) (corrugated duct) 50mm 60mm 80mm 100mm Technical Dept. - All rights reserved - Reproduction prohibited...
  • Page 18 2-INSTALLATION Preparing the smoke expulsion system The combustion product expulsion system is a particularly important element for the proper operation of the appliance and must be correctly sized according to EN 13384-1. Its creation/adaptation/verification must always be carried out by a legally qualified operator and must comply with the regulations in force in the country where the appliance is installed.
  • Page 19 2-INSTALLATION Chimneypot The chimneypot, meaning the end part of the flue, must meet the following characteristics: • the smoke outlet section must be at least double the internal section of the chimney; • prevent the penetration of rain or snow; •...

  • Page 20: Examples Of Installation

    2-INSTALLATION EXAMPLES OF INSTALLATION (DIAMETERS AND LENGTHS TO BE SIZED) 1. Flue installation with hole for the passage of the pipe increased by: • minimum 100mm around the pipe if next to non-flammable parts such as cement, brick, etc.; or •...

  • Page 21: 3-Drawings And Technical Features

    3-DRAWINGS AND TECHNICAL FEATURES DRAWINGS AND CHARACTERISTICS CUTE AIR 8 M1 STOVE DIMENSIONS Ø50 Ø100 Technical Dept. - All rights reserved - Reproduction prohibited...

  • Page 22: Technical Specifications

    3-DRAWINGS AND TECHNICAL FEATURES TECHNICAL SPECIFICATIONS CUTE AIR 8 M1 Energy Efficiency Class Nominal output power 8.0 kW (6880 kcal/h) Minimum output power 2.4 kW (2064 kcal/h) Efficiency at Max 92.7% Efficiency at Min 94.3% Temperature of exhaust smoke at Max 135 °C...
  • Page 23 ACCORDING TO COMMISSION REGULATIONS (EU) 2015/1185 - (EU) 2015/1186 (PRODUCT FICHE) Manufacturer: MCZ GROUP SpA Trademak: Model Identifier: CUTE AIR 8 M1 / THEMA AIR 8 M1 Indirect heating functionality: Direct heat output (space heat output): Indirect heat output (water heat output): CPR harmonised standard:...

  • Page 24: 4-Unpacking

    4-UNPACKING INSTRUCTIONS FOR PACKAGING DISPOSAL The material that the appliance’s packaging is made of must be managed correctly, in order to make collection, reuse, recovery and recycling easier, where possible. The table below illustrates the possible components that the packaging is made of, and the relative instructions for correct disposal. DESCRIPTION CODE MATERIAL SYMBOL...
  • Page 25 4-UNPACKING Handle the product with suitable means paying attention to the applicable safety regulations in force. Do not turn the packaging over and handle the majolica parts with care. The stoves are delivered in a single package with ceramic panels or steel side panels packaged together with the structure and placed on top or at the side.
  • Page 26 4-UNPACKING Position the stove and connect it to the flue. Use the 4 adjustable feet (J) to get the stove correctly levelled so that the smoke outlet is lined up with the connecting pipe. If the stove needs to be connected to an outlet pipe which goes through the rear wall (to connect to the flue), take utmost care to make sure that the joint is not forced.

  • Page 27: 5- Smoke Outlet

    5- SMOKE OUTLET SMOKE OUTLET As per standard the stove is designed for upper smoke outlet (UP!). With a few easy manoeuvres the smoke outlet can be brought to the back. The installer must carry out the following steps: • eliminate the adapter 80/100 (part “1”) •...
  • Page 28 5- SMOKE OUTLET • disassemble female pipe-diameter 80 (part “4”) • remove lid “5”...
  • Page 29 5- SMOKE OUTLET • mount the female pipe diameter 80 (part “4”) at the back where the lid “5” was mounted • mount lid “5” at the top where the female pipe diameter 80 was mounted “4” At this point install the pipes for the rear outlet Technical Dept.
  • Page 30 5- SMOKE OUTLET In the case of rear installation, the 4019010 kit must be purchased. It is a part of top “A” without the hole for the top smoke outlet (see dedicated manual).

  • Page 31: 6-Installation And Assembly

    6-INSTALLATION AND ASSEMBLY DISASSEMBLING THE SIDE CLADDING In the event the side has to be removed, proceed as follows: • Open the door ”P” • Lift the pellet cover “R” • Remove the screw “v” at the front bottom part of the stove •...
  • Page 32 6-INSTALLATION AND ASSEMBLY • Remove the two screws “u” on the back of the stove • Pull out the panel “S” Proceed in the same way also for the other panel.

  • Page 33: 7-Door Opening

    7-DOOR OPENING OPENING THE DOOR OF THE FIREBOX To open the firebox door “P”, insert the cold handle (supplied) into the hole in the handle “M” and pull it towards you. Attention! Only open the door when the stove is off and cold. Technical Dept.

  • Page 34: 8-Usb Socket

    8-USB SOCKET USB SOCKET There is a USB socket on the bottom of the stove, near the control panel, if a software update is required; the cladding parts do not have to be removed to reach the socket directly in the circuit board (pos. 13 in the PCB). Attention! The USB socket must be used by skilled technicians.

  • Page 35: 9-Electrical Connection

    9-ELECTRICAL CONNECTION ELECTRICAL CONNECTION First connect the power cable to the back of the stove and then to a wall socket. It is recommended to disconnect the power cable when the stove is not used. The cable must never come into contact with the smoke exhaust pipe or any other part of the stove. ELECTRICAL STOVE CONNECTION STOVE POWER SUPPLY Connect the power cable to the back of the stove and then to a wall socket.

  • Page 36: 10-Loading The Pellets

    10-LOADING THE PELLETS LOADING THE PELLETS Fuel is loaded from the upper part of the stove by lifting the door “R”. Pour the pellets in slowly so that they are deposited at the bottom of the hopper. If loading pellets when the stove is running, open the door of the hopper using the stove mitten that comes with the stove itself.
