VISUAL PARKING ASSIST SENSOR
VPX-B104R
• OWNER'S MANUAL
• MODE D'EMPLOI
• MANUAL DE OPERACIÓN
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda,
Shinagawa-ku,
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
SYSTEM (VPASS)
Please read before using this equipment.
Veuillez lire avant d'utiliser cet appareil.
Léalo antes de utilizar este equipo.
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Wilhelm-Wagenfeld-Str. 1-3,
80807 München, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K. LTD.
Alpine House
Fletchamstead Highway,
Coventry CV4 9TW, U.K.
Phone 0870-33 33 763
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris Nord Il,
B.P. 50016, 95945 Roissy Charles de Gaulle
Cedex, France
Phone 01-48638989
R
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Phone 02-725-13 15
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPX-B104R and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine VPX-B104R

Summary of Contents for Alpine VPX-B104R

  • Page 1 Veuillez lire avant d’utiliser cet appareil. • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. ALPINE ELECTRONICS MARKETING, INC. ALPINE ITALIA S.p.A. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 161-165 Princes Highway, Hallam 1-1-8 Nishi Gotanda, Viale C. Colombo 8, 20090 Trezzano Victoria 3803, Australia...

  • Page 3: Table Of Contents

    ENGLISH Contents Operating Instructions WARNING DANGER ........... 2 WARNING ........2 CAUTION ......... 3 NOTICE ..........5 Sensor Operation Introduction ........6 Important Information .....6 How the Visual Parking Assist Sensor System Works ....6 Installation and Connections Installation Diagram ......7 1. Sedan ............7 2.

  • Page 4: Warning

    When in doubt, showing conditions in view of the camera. The camera uses consult your Alpine dealer. a wide-angle lens, therefore, there is a difference in distance BEFORE WIRING, DISCONNECT THE CABLE FROM THE perspective between what is normally seen and what appears NEGATIVE BATTERY TERMINAL.

  • Page 5: Caution

    Failure to do so may cause personal injury or damage to the Use for other than its designed application may result in fire, product. Return it to your authorized Alpine dealer or the electric shock or other injury. nearest Alpine Service Center for repairing.
  • Page 6 • When the detection sensors are clogged with foreign matter The Parking Corner Sensor might such as show, mud or icicles. (Normal function resumes not be able to detect the following after removal.) objects: • Rope, wire, small-diameter pipes or objects made of these materials, such as wire fences.

  • Page 7: Notice

    • When getting too close to an obstacle (< 0.7ft) as the • Non-reflecting objects that project at sharp or acute angles sensors might have a false detection; for example: no beep, in relation to the sensors. slow beep, fast beep or three fast beeps. • Objects around the lower part of the bumper.

  • Page 8: Sensor Operation

    Sensor Operation How the Visual Parking Assist Sensor System Works Introduction The system is ready for operation when the ignition switch is turned ON and the shift lever is Thank you for purchasing this Visual Parking moved to the reverse position. Assist Sensor System (VPASS system).

  • Page 9: Installation And Connections

    Installation and Installation Diagram Connections 1. Sedan For your protection, please pay extra attention to the following symbols. Sensor CAUTION Camera This symbol is intended to alert the user that an accident, injury or vehicle damage may occur if the instruction is not observed. Monitor Buzzer •...

  • Page 10: Accessory Parts

    • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. 0° Spring Plate 6° Spring Plate ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 1-1-8 Nishi Gotanda, 161-165 Princes Highway, Hallam Viale C. Colombo 8, 20090 Trezzano...

  • Page 11: Wire Connection

    * Connect only one monitor to the system using the Alpine Video cable or RCA video out. * Use the Alpine video cable (provided with system) to connect between the VPASS system and video monitor or between VPASS and Alpine camera...

  • Page 12: Painting Sensor Cover And Sensor Unit

    Painting Sensor Cover and Remove the spring plate from the Sensor Unit sensor cap box to avoid painting. Remove the rubber ring from the Please follow the instructions in this manual for sensor unit box to avoid painting. painting and assembling, in order to get the best performance.

  • Page 13: Sensor Assembly

    Sensor Assembly CAUTION Remove the cap from the sensor unit • Do not damage the coating surface when after the paint is dry. installing the rubber ring and sensor cap. • Confirm the installation is not loose when Install the sensor rubber into the installing the rubber ring and sensor cap.
  • Page 14 Install the sensor on the vehicle bumper. SUGGESTION Refer to the Installation of Sensor for installing sensors on the vehicle bumper. Before installing sensors on the vehicle bumper, make sure the painting process of sensors has been finished.

  • Page 15: Installation Of Sensor

    Installation of Sensor 1.6 ft (Min) 0.4 ft (Min) 1/3 Length 1/3 Length 1/3 Length 0.4 ft (Min) Equip the sensor with the 0° sensor cap and spring plate for a flat bumper. Equip the sensor with the 6° sensor cap and spring plate for bumper with a slope. Divide the distance between 2 marked Park the vehicle on a flat level surface.
  • Page 16 Check behind the bumper to ensure Insert the plug into the socket. there is enough depth for sensor installation. Install the sensor vertically, with the “UP” sign facing up. Install the sensor into the hole and mount firmly in the bumper. Route the sensor cable.

  • Page 17: Installation Of Ecu

    Installation of ECU On-Screen Display Set Up Align the calibration paper behind the car, and up to the rear wheel. Align the 0 ft mark with the rear bumper. Calibration sheet Line up bumper with 0 ft Mount the ECU on a dry, protected area inside the vehicle.

  • Page 18: Fish-Eye Correction Menu

    Fish-eye Correction Menu Use the [+] or [-] button to adjust the To go to Fish-eye correction menu, refer to top of Green line to match the back step 1 through 4 of On-Screen Display Set-up edge of the calibration paper, 6ft section.

  • Page 19: Diagnostic

    Diagnostic Press the [ENT] to enter the sub-menu. To go to Diagnostic menu, refer to step 1 through 4 of On-Screen Display Set-up Function Parameter section. Fish-eye Correction Select the “Diagnostic”. Press the [ENT] Line Length to enter. Line Shift Select the “System status”. Press the [ENT] to enter.

  • Page 20: Setup Mode Structure Tree

    Setup -Mode Structure Tree Setup Mode 1. Fish-eye correction FEC 1 FEC 2 FEC8 Return 2-1 Off 2. Parking Guide Line 2-2 Line Length Adjustment 2-3 Line Slope Adjustment 2-4 Line Shift Adjustment 2-5 Line Ratio Adjustment Firmware Version 2-6 Return P1002-08-03 Battery Voltage 12.8V...

  • Page 21: Function Test After Installation

    Check whether the sensor wires are plugged into the ECU properly. c) Check the sensor wires for damage. • Ask an Alpine authorized dealer for advice if the trouble persists. 3. Take your vehicle to an Alpine authorized dealer if you encounter either of these problems:...
  • Page 22 5KMG006334XA000X...

Table of Contents
