Alpine X009-WRA Installation Manual

Alpine X009-WRA Installation Manual

Jeep wrangler 2011-up, 9"
Hide thumbs

Advertisement

Quick Links

Download this manual

Jeep Wrangler

X009-WRA 9"
Installation Manual
˜ Model: Wrangler
˜ Model Year: 2011-UP
* The specified vehicles have been tested and have met compatibility specs at the time of testing. Compatibility is
not guaranteed if the manufacturer has made production changes to the listed vehicles above.
Introduction
˜ Design and specifications are subject to change without notice for improvement.
To Ensure Safe Use, Always Follow These Precautions
˜ The installation of this product requires specialized skills and experience. We recommend that you have the
product installed by the store that you purchased it from.
˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual
so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as
a result of failure to follow the instructions in the manuals.
˜ This manual includes a number of symbols that are intended to help you use the product safely, to prevent
harm to you and others, and to protect against damage to property. These symbols and their meanings are
listed below. Make sure you fully understand these symbols before you begin reading the main text.
Explanations of Injury and Damage That May Result from Incorrect Use
Ignoring the content marked by this indication and using the product incorrectly is
Warning
expected to lead to death or serious injury.
Ignoring the content marked by this indication and using the product incorrectly is only
Caution
expected to lead to injury or property damage.
Model
Jeep
Wrangler
WRANGLER
Year
2011 - UP
Jeep Wrangler
˜ 1/13

Advertisement

loading
Need help?

Need help?

Do you have a question about the X009-WRA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alpine X009-WRA

Summary of Contents for Alpine X009-WRA

  • Page 1: Jeep Wrangler

    ˜ Before you use this product, be sure to carefully read this installation manual and the separate user's manual so that you can use the product correctly. Alpine Electronics bears no responsibility for problems that arise as a result of failure to follow the instructions in the manuals.
  • Page 2 Jeep Wrangler WRANGLER ˜ 2/13 Types of Precautions Indicates actions that are forbidden Indicates actions that are (must not be performed) mandatory (must be performed) Forbidden Mandatory Indicates that disassembly is Marks content that should receive forbidden. your full attention. Forbidden Warning Do not disassemble or modify the product.
  • Page 3 Jeep Wrangler WRANGLER ˜ 3/13 When installing and grounding the product, do not use any of the bolts or nuts of the steering wheel, brakes, fuel tank, or the like. Doing so could make the brakes stop working or lead to fire. Forbidden Do not install the product near the passenger-side airbag.

  • Page 4: Accessory List

    X009 Head Unit X009 Camera Harness AUX/Pre Out Harness GPS Antenna USB Extension Cable 8mm x 8 Screws Quick Reference Guides Registration Cards Alpine NAVTEQ Audio Navigation Registration Card Registration Card iDatalink Maestro Box Parts (ALP-MRR V2.0/ALP-HRN-WRA V2.0) Main Harness...
  • Page 5 Jeep Wrangler WRANGLER ˜ 5/13 Installation Kit Parts (G-KTX-009-WRA) X009-WRA Radio Dash Bezel Key Harness Side Mounting Brackets Microphone...

  • Page 6: Component Locations

    Jeep Wrangler WRANGLER ˜ 6/13 Component Locations GPS Antenna Location BT Microphone Jeep SINCE 1941 Jeep BT Microphone Location GPS Antenna Location...
  • Page 7 Jeep Wrangler WRANGLER ˜ 7/13 Factory Unit Disassembly Process Remove the rubber cover from the top center Remove the dash panel. storage area and extract 1 x 7mm screw. Remove the knee cover panel and extract 2 x 7mm screws located to the right and left sides of the steering wheel column.
  • Page 8 Jeep Wrangler WRANGLER ˜ 8/13 Programming the iDatalink Maestro Module INSTALL THE WEBLINK PLUG-IN CONNECT YOUR MAESTRO MODULE Go to: Use the included USB cable to connect your Maestro module to your idatalinkmaestro.com/plugin and follow the installation steps. Review the System Requirements before installing. LOG INTO WEBLINK Go to: idatalinkmaestro.com/login.

  • Page 9: Installation Instructions

    Jeep Wrangler WRANGLER ˜ 9/13 Installation Instructions Attach the Maestro to the main harness. Place GPS antenna next to the instrument panel as illustrated and run the cable to the radio cavity. Plug the OBDII connector on to the OBDII port below the driver side dash and run the extension to Mount the microphone as illustrated and run the the radio cavity.
  • Page 10 Jeep Wrangler WRANGLER ˜ 10/13 Trimming procedure for dash panel The factory dash panel needs to be trimmed to allow the new X009- WRA bezel to fit into place. Remove the highlighted area by cutting along the dashed line. Mount the modified panel back on the vehicle.
  • Page 11 Run the key harness through the top-left side of OEM dash panel by pressing down on the lock tab X009 headunit. Mount the X009 headunit using 4 x and turning right. Mount vents on to the X009-WRA 7mm factory screws. bezel.
  • Page 12 Jeep Wrangler WRANGLER ˜ 12/13 Exploded-View Diagram Dash Board X009 Head Unit X009-WRA Radio Dash Bezel Side Mounting Brackets Factory Vents and Window Switch Pod (not included) Bezel Wiring Diagram 20 Pin Harness (Connect to X009) 8 Pin Harness 8 Pin Harness...
  • Page 13 Jeep Wrangler WRANGLER ˜ 13/13 X009-WRA System Wiring To ODB II To Vehicle Connectors Connector (2-pin Black Connector) Blue Power Antenna (Not used) Blue/White Amp Turn-on (Use only with aftermarket ampli ers) iDatalink MAESTRO Module USB Extension Cable GPS Antenna...
