Axion Maestro ZHT Hardware Manual

Hide thumbs

Advertisement

Table of Contents

MAESTRO ZHT™
Hardware Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maestro ZHT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axion Maestro ZHT

Summary of Contents for Axion Maestro ZHT

  • Page 1 MAESTRO ZHT™ Hardware Guide...

  • Page 2: Declaration Of Conformity

    Declaration of Conformity This instrument meets the requirements for ANSI/UL 61010-1 and CAN/CSA-C22.2 No. 61010-1. The following standards were applied: IEC/EN 61326 (EMC) and IEC/EN 61010-1 (Safety). The user is responsible for providing a compatible electromagnetic environment in order for the device to perform as intended. Do not use this device in close proximity to sources of strong electromagnetic radiation, (e.g.
  • Page 3 Thank you Thank you for purchasing the Maestro ZHT, Axion's powerful integrated system for impedance-based cell analysis. Please contact us with any questions regarding system operation. Intended Use: The Maestro is intended for benchtop research experiments only; it is not intended for use in diagnostic procedures.
  • Page 4 Included Equipment & Symbols Used 1 Maestro ZHT Warning Symbol in Manual 1 Starter CytoView-Z Pack Power On/Off 1 Smart Plate 1 AxIS Z User Guide Ethernet 1 Power Cable 1 Ethernet Cable 2 Air Filters 1 Door Cleaning Cloth...
  • Page 5 Plate Button Light Functions White then Blue Pulsing Maestro is starting up. Blue Maestro is open/closed without plate. Green Pulsing Maestro has plate docked and is acquiring data. Red Pulsing Error.
  • Page 6 Recommended Set-up Environment The Maestro contains very sensitive electronic equipment that may pick up external environmental interference (e.g. table bumps, cell phone signals, power outlet emissions, etc.). The Maestro has many features that assist in mitigating this interference, but proper instrument placement can help.
  • Page 7 System Set-up Instructions The Maestro is designed for quick and easy set-up. 1) Power - Plug the Power Cable into the back of the Maestro and the plug into a wall outlet. WARNING: To avoid the RISK of electric shock, this equipment must only be connected to a SUPPLY MAINS with protective earth.
  • Page 8 Working with the General Features Power Button - Turns the system on/off. The system will take a minute to boot up or shut down. Plate Button - Docks and undocks Z plates. The button color indicates AxIS mode (ready, recording, error). Door - Opens automatically when the plate is ejected.
  • Page 9 Door Power Button Touchscreen Plate Button...
  • Page 10 Working with the Plate Chamber CytoView-Z Plate A1 Notch - Proper orientation of plate with A1 notch in top left. Pogo Pin Connectors - Connect plate to Maestro electronics. Heater Plate - Maintains temperature throughout experiment. Refer to the Axis Z User Guide for details.
  • Page 11 Plate A1 Notch Pogo Pin Heater Plate Connectors...
  • Page 12 Working with the Back Panel Mains Power Switch - Use only when unplugging the system. Must be in the "I" position for the system to power up. CO2 Input - Connect 100% CO2 (15 PSI, 50 PSI max; 6 mm OD tubing). Air Filter - Attach supplied air filter to luer lock fitting.
  • Page 13 CO2 Input Air Filter Ethernet Filter Input Ventilation Lumos Power Plug In/Out Mains Power Switch...
  • Page 14 4) Close the chamber by pushing the Plate Button to activate gas control*. 5) In AxIS Z, push Measure Baseline to record the media-only baseline impedance. 6) For details on operating the Maestro ZHT, please review the AxIS Z user guide which can be found in the AxIS Z Help Menu.
  • Page 15 The Pogo Pins and external air filter are the only user serviceable parts. Please contact Axion Support at support@axionbio.com for any other maintenance. Storage When the Maestro is not in use, Axion recommends leaving the Smart Plate engaged with the door closed.

  • Page 16: Air Filter Replacement

    Air Filter Replacement The Maestro ZHT’s CO2 controller requires clean air to maintain a stable environment for your cells. To replace the air filter, twist luer fitting to remove the tube from the air filter, then twist filter counter-clockwise to remove it from the back of the Maestro. Twist the new filter in place on the Maestro until snug.
  • Page 17 Performance Maintenance Plans The Maestro systems are a critical piece of equipment in your lab. Keep your systems operating without interruption and at peak performance. Why purchase a Performance Assurance Plan? • Priority response • Ensures critical data accuracy • Trained and qualified factory engineers •...

  • Page 18: Technical Specifications

    Technical Specifications Power Supply Specifications: System Dimensions: 100-240V AC Voltage Size 280 x 452 x 225 mm (W x D x H) 8-4A AC Current Weight 30.6 lbs 60-50Hz Frequency Operating Environment: Environmental Controls: Recommended CO2 Temperature 5-32oC 15 psi (1 bar) Pressure Max Relative up to 80%...
  • Page 19 Technical Specifications +/- 5mV at 1, 10, 41.5 kHz Impedance Measurement Signal +/- (0.5% + 1 Ω) Impedance Measurement Repeatability +/- (1% + 1.5 Ω) Impedance Measurement Uniformity 1 Sample/Minute (Automatic, All Wells) Impedance Sampling Rate 50 Ω to 5 kΩ Imepdance Dynamic Range 1 TB Device Storage...

  • Page 20: Further Information

    Discover the functionality of your cells with impedance-based cell analysis and MEA electrical network analysis. www.axionbiosystems.com/applications Technology Learn how impedance assays work and the innovation behind Axion's products. www.axionbiosystems.com/technology Resources Access the tools and content to drive your research. www.axionbiosystems.com/resources...
  • Page 21 Contact Axion Biosystems Email: support@axionbio.com Phone: 404-477-2557 1819 Peachtree Road NE Suite 350 Atlanta, GA 30309 www.axionbio.com...
  • Page 22 Notes...
