Logik L49UE17 Unpacking Manual

Unpacking
Guide
L49UE17
TV
Instruction Book
& Quick Start Guide
Accessories TV Feet, leg and screw x 2
Pack
Fitting the Feet
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Keep the protective bag on your TV, it will help to protect the TV.
Lay the TV down on a flat surface ideally on the edge of a table so the base of the
TV slightly overhangs the edge of the table, with the back side facing up. Please
make sure a soft cushioned material (such as a dry bath towel or thick piece of
foam) is placed beneath the screen.
If you don't have a table big enough, you can use the TV box. Lie the box flat,
make sure you place the polystyrene back in the box first to give the box some
rigidity and strength.
3. Screw the leg and foot together with the supplied screw.
4. Position each foot onto the back of the stand. They are marked Left and Right on
the back of each foot. Make sure you slide the lug under the recess.
5. Using 3 of the supplied screws, to screw each foot onto the TV.
• Keep the protective bag on your TV until you have attached the stand and
positioned the TV.
• The LCD display is very fragile, and must be protected at all times when
installing and removing the base stand. Be sure that no hard or sharp object,
or anything that could scratch or damage the LCD display, comes into
contact with it. DO NOT exert pressure on the front of the TV at any time
because the screen could crack.
L49UE17 Unpacking Guide.indd 1
✔
2 people are required
when unpacking your TV.
Right foot Left foot
(when looking from (when looking from
the back of the TV) the back of the TV)
✘
Remove the Protective Bag
Protective
Bag
Table
Cushioned
material
Don't lift the TV from the top
When you remove the TV from its box lie it flat.
Don't balance it on the sensor at the front of the TV.
