Connecting the System
When connecting to separately sold power amp
RCA connector
The navigation unit
13
Subwoofer output
or non-fading output
(SUBWOOFER OUTPUT or
NON-FADING OUTPUT)
28 cm (11 in.)
30 cm (12 in.)
10
30 cm (12 in.)
Blue/white
To system control terminal of the power amp
(max. 300 mA 12 V DC).
Do not connect this lead to Auto-antenna control
terminal.
Rear output
(REAR OUTPUT)
Front output
(FRONT OUTPUT)
30 cm (12 in.)
