Item #1000 750 726
Model #MS2033C
USE AND CARE GUIDE
DIGITAL CLAMP METER
Questions, problems, missing parts? Before returning to the store,
call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.CA
THANK YOU
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Commerical Electric!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Commercial Electric MS2033C
Summary of Contents for Commercial Electric MS2033C
- Page 1 Model #MS2033C USE AND CARE GUIDE DIGITAL CLAMP METER Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA THANK YOU continually create quality products designed to enhance your home.
-
Page 2: Table Of Contents
Table of Contents ......7 Table of Contents ........2 . -
Page 3: Fcc Compliance Statement
Safety Information (continued) PRECAUTIONS WARNING: This manual contains information and WARNING: Make sure to use the correct input jack, warnings necessary for safe operation and maintenance of function, and range when measuring. the meter. It is recommended that you read and understand this instruction manual thoroughly prior to using the meter. -
Page 4: Warranty
Warranty WARRANTY: 12 MONTHS For one year from the date of purchase, this product is warranted against any defects in material or workmanship. This warranty is void if this product is ever used while providing commercial services or if rented to another person. Contact the Customer Service Team at 1-877-527-0313 or visit www.HomeDepot.ca. -
Page 5: Automatic Power Off Function
Pre-Operation (continued) AUTOMATIC POWER OFF FUNCTION If the meter is idle for 30 minutes after turning it on, the meter automatically powers off to save the battery. To turn the meter back on, press the FUNC button. LCD DISPLAY DEFINITIONS Part Symbol Definition... -
Page 6: Temperature Specifications
Pre-Operation (continued) AC CURRENT SPECIFICATIONS Measuring Range Resolution Accuracy 0.01A 400A 0.1A ±(2.5% of rdg + 5 digits) 600A Additional Specifications: □ Frequency Range: 50Hz~60Hz □ Maximum Input Current: up to 120% of full scale for no more than 60 seconds □... -
Page 7: Frequency Specifications
Pre-Operation (continued) FREQUENCY SPECIFICATIONS Measuring Range Resolution Accuracy 50Hz 0.01Hz 500Hz 0.1Hz ±(1.0% of rdg +5 digits) 5kHz 10kHz 0.01kHz Additional Specifications: □ Measuring Scope: 10~100kHz □ Input Signal Range: ≥0.2V AC (rms) (input current will increase when the frequency to be measured increases) □... -
Page 8: Capacitance Specifications
Pre-Operation (continued) CAPACITANCE SPECIFICATIONS Measuring Range Resolution Accuracy 5.0nF 0.001nF ±(4.0% of rdg +5 digits) 50nF 0.01nF 500nF 0.1nF 5.0µF ±(3.0% of rdg +3 digits) 50µF 0.01 µF 100µF 0.1 µF Additional Specifications: □ Overload Protection: 250V DC or AC (rms) DIODE TEST Measuring Range Resolution... -
Page 9: Operation
Operation BEFORE YOU TAKE A MEASUREMENT CAUTION: If the current under measurement is higher CAUTION: than the selected value for a long period, overheating may common (COM) test line, then connect the charged test line. take place, compromising the safety and operation of the inner circuits. - Page 10 Operation (continued) Completing Frequency and Duty Cycle Measurements □ Insert the black test probe (M) into the COM jack (H) and the red test probe (L) into the INPUT jack (G). □ Move the rotary switch (C) to the V~ position (1). □...
- Page 11 Operation (continued) Completing a Diode Test WARNING: To avoid injury or damage to the meter, make sure to turn off all power and discharge all capacitors before measuring diode. □ Insert the black test probe (M) into the COM jack (H) and the red test probe (L) into the INPUT jack (G).
- Page 12 Operation (continued) Completing a Capacitance Measurement WARNING: Electric shock hazard. To avoid electric shock, before measuring capacitance, discharge the capacitance completely. □ Insert the black test probe (M) into the COM jack (H) and the red test probe (L) into the INPUT jack (G). □...
-
Page 13: Maintenance
Maintenance WARNING: Before you open the meter, always disconnect it from all sources of electric current and make sure you are not charged with static electricity, which may destroy the internal components. WARNING: Any adjustment, maintenance, or repair work carried out on the meter while it is live should be carried out by a qualified electrician. - Page 14 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA Retain this manual for future use.
