  • Page 1 Empowering Every IoT Device with Our Technology Thundercomm TurboX™ Open Kit Software User Manual C610 Rev LA1.0 Oct 27, 2020...
  • Page 2 This document itself and the proprietary technical information contained herein is the property of Thundercomm. Without prior written authority of Thundercomm, no one shall copy, modify or reprint the whole or part of this document. Offenders are liable for all related damages, loss and litigations.
  • Page 3 Bluetooth Generic Access Profile (GAP) ................15 Ethernet................................ 15 2.10 Camera ................................. 16 2.11 Audio ................................16 2.11.1 Speaker test .......................... 16 2.11.2 Capture with Dmics ......................17 2.12 POE ................................20 2.13 Sensors ................................. 21 Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 4 1 x Accelerate & Gyroscope Sensor 1 x Wifi/Bt Antenna Connector 6 x LEDs 4 x Keys (Vol Up/Down, Force USB Boot, Power) Power Supply DC IN 12V, POE 15W, Battery Connector Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 5 Operation Temperature: -20℃ ~ 70℃ Operation Humidity: 5%~95%, non- condensing Dimension 38 x 38 mm OS Support Linux, Android TurboX™ C610 Open Kit Block Diagram Camera Module and TFT-LCD are accessories to the Open Kit. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 6 10 Giga Bit Ethernet POE 11 TF Card 12 Display Port 13 Debug UART 14 Power ON 15 Vol_UP 16 Vol_Down 17 Force USB Boot 18 Power LED, PMIC RGB LEDs 19 JTAG Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 7 Press the power key to make system boot up, the log will output as following: Format: Log Type - Time(microsec) - Message - Optional Info Log Type: B - Since Boot(Power On Reset), D - Delta, S - Statistic Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 8 122880+0 records out 62914560 bytes (60 M) copied, 0.974147 s, 62 M/s Note: Each TF card corresponds to a directory. You need to replace the "98C7-A27D" folder with your TF card directory. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 9 VM Hyp calls not present Booting from slot (_a) Booting Into Mission Mode ..Update Device Tree total time: 77 ms Start EBS [13803] BDS: LogFs sync skipped, Unsupported App Log Flush : 6 ms Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 10 0.000000] Boot CPU: AArch64 Processor [51df805e] 0.000000] Machine: IOT 0.000000] earlycon: msm_geni_serial0 at MMIO 0x0000000000880000 (options '') (3) After about 3 minutes(first boot after flash), you will see the Android Home Screen via LCD. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 11 (3) After about 3 minutes(first boot after flash), press the power key again, you will see the Android Home Screen through the monitor. 2.4 Touchpanel After Home Screen is seen from LCD, you can operation on Touchpanel. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 12 33.928630] msm-dwc3 a800000.hsusb: DWC3 in low power mode 33.979067] msm-dwc3 a600000.ssusb: DWC3 in low power mode 58.262364] msm-dwc3 a600000.ssusb: DWC3 exited from low power mode 58.508337] usb 3-1.4: new high-speed USB device number 3 using xhci- Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 13 Note: Only if USB type C is connected with an OTG cable, USB type A can work normally. (1) Connect a USB type C OTG cable, the external hub on board is detected. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 14 # echo 0 > /sys/class/leds/led_gen/brightness // Turn off the gen led # echo 255 > /sys/class/leds/led_wifi/brightness // Turn on the wifi led # echo 0 > /sys/class/leds/led_wifi/brightness // Turn off the wifi led Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 15 NOTE: Force USB BOOT is forced download mode (emergency download) Device node VOLUME UP /dev/input/event2 VOLUME DOWN /dev/input/event0 POWER KEY /dev/input/event0 USBBOOT (1) Get interrupt event: $ adb shell # cat dev/input/event0 # cat dev/input/event2 Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 16 Swipe down from the top of the screen. Touch and hold Wi-Fi Turn on Use Wi-Fi. Tap a listed network, enter the password. Networks that require a password have a Lock . Confirm if an IP is get. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 17 Quick Settings. (3) You can change the AP name and password by tapping “Setting”-> “Network & internet”-> “Hotspot & tethering”-> “Wi-Fi hotspot” (4) use your phone to connect this wifi. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 18  If you don't find Pair new device, check under "Available devices" or tap More Refresh. Tap the name of the Bluetooth device you want to pair with your device. 2.9 Ethernet It is not supported yet. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 19 Connect camera module as the following picture After system bootup, open the app“Snapdragon Camera”, we can preview, take a picture or record a video. 2.11 Audio 2.11.1 Speaker test Make sure connected Speaker Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 20 # tinycap /data/dmic0.wav -D 0 -d 0 -T 10 -r 48000 -c 1 b. Capture with DMIC1 $ adb root $ adb shell # tinymix 'AIF1_CAP Mixer SLIM TX0' 1 # tinymix 'CDC_IF TX0 MUX' DEC0 # tinymix 'ADC MUX0' DMIC Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 21 # tinymix 'DMIC MUX4' DMIC4 # tinymix 'AIF1_CAP Mixer SLIM TX5' 1 # tinymix 'CDC_IF TX5 MUX' DEC5 # tinymix 'ADC MUX5' DMIC # tinymix 'DMIC MUX5' DMIC5 # tinymix 'MultiMedia1 Mixer SLIM_0_TX' 1 Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 22 (3) Play the wav file $ adb pull /data/dmic0.wav . $ adb pull /data/dmic1.wav . $ adb pull /data/6mics.wav . Play the *.wav , you can hear what your said before. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 23 TurboX™ C610 Open Kit Software User Manual 2.12 POE (1) Make sure connected POE adapter ⑬ (2) Connect debug UART, press the power key, make sure system bootup as normal mode. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
  • Page 24 TurboX™ C610 Open Kit Software User Manual 2.13 Sensors After system bootup, open the app“QSensorTest”, we can get Accel & Gyro sensor data. Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
