  • Page 1 Thundersoft TurboX® S625 EVB User Guide Thundercomm...
  • Page 2 REVISION PAGES 1 of 29 STATE TITLE Released Thundersoft TurboX® S625 EVB User Guide Version Date Description V1.0 2017-10-24 Initial Version V2.0 2017-12-28 1, EVB board upgrade to V2.0. 2, Change extension interface pin 2 and 4 to EXT_IF_VIN_5V. 3, Add I2S D2 and D3 to extension interface pin 11 and 13. 4, Closed some known issues...

  • Page 3: Table Of Contents

    Contents INTRODUCTION ..............................5 ................................5 URPOSE .............................. 5 AFETY UIDANCE REFERENCES ................................. 6 ........................... 6 EFERENCE OCUMENTS ............................ 6 & A EFINITION CRONYMS HARDWARE OVERVIEW ............................7 ................................7 VERVIEW ..........................8 LECTROSTATIC ROTECTION ..............................8 ACKAGE THUNDERSOFT TURBOX® S625 EVB ........................9 ..............................
  • Page 4 HDMI OUT TypeA Connector ........................ 16 4.5.8 Ethernet Connector ..........................17 4.5.9 4.5.10 Volume Key .............................. 17 TF Card connector ..........................18 4.5.11 Speaker Connector ..........................18 4.5.12 4.5.13 3.5mm Audio Jack ........................... 19 4.5.14 Touch Panel Connector .......................... 19 LCD Connector ............................
  • Page 5 ..............................28 EATURES ..............................28 SSUES ..............................28 LOSED SSUES...

  • Page 6: Introduction

     The EVB can be supplied by power adaptor. Required output of the power adaptor should be 12V, currency is greater than or equal to 2A. Thundercomm supplied power adaptor is recommended.  The EVB can be supplied by battery. Required output of the battery is 3.8V.

  • Page 7: References

    2 References 2.1 Reference Documents Document Thundersoft TurboX® S625 SOM Datasheet Thundersoft TurboX® S625 Package List Thundersoft TurboX® S625 CarrierBoard Part Reference Table 2.1-1 Reference Documents 2.2 Definition & Acronyms System on Module Evaluation Verification Board Bluetooth BLSP Based low-speed peripheral Display Serial Interface Camera Serial Interface Digital Signal Processor...

  • Page 8: Hardware Overview

    UART Universal Asynchronous Receiver/Transmitter Universal Serial Bus WLAN Wireless LAN Light-emitting diode Direct current eMMC Embedded Multi Media Card Table 2.2-1 Definition & Acronyms 3 Hardware Overview 3.1 Overview Thundersoft TurboX® S625 EVB is a powerful board, built with Qualcomm processors, high performance and rich interfaces.

  • Page 9: Electrostatic Protection

    3.2 Electrostatic Protection There are many interfaces on the device, and frequent plug-in connections, so it is required to take proper electrostatic protection during daily usage:  Utilize ESD table mat  Wear anti-static wrist strap or heel grounder Note: All of interfaces and buttons are all ESD, following standard Electromagnetic compatibility IEC61000-4-2.

  • Page 10: Thundersoft Turbox® S625 Evb

    4 Thundersoft TurboX® S625 EVB 4.1 Block Diagram VBAT eMCP WIFI&BT (2GB+16GB) (wcn3680B) backlight lpddr3 emmc (TPS61165) CSI0 (IMX214) DSI0 TP I2C3 CSI1 BLSP3 (IMX214) I2C4 LT8912B DSI1 (mipi2hdmi) BLSP4 I2C6 KSZ8851SNL BLSP1 (SPI2LAN) WSA8810 (audio PA) WCD9335 Slimbus VBAT (audio PA) Uart2 FT230XQ-R...
  • Page 11 16Gb, non PoP memory LPDDR3;32-bit wide; up to 933Mhz; System memory 16GB,eMMC5.1; Multimedia FHD (1920 × 1200) 60 fps; 16/18/24 bpp RGB; MIPI_DSI MIPI DSI four-lane DSI D-PHY 1.1; HDMI1.4 standard HDMI out 1080p 60 fps Dual 14-bit ISP; 13MP and 13MP;24MP at 30fps ZSL with dual-ISP;13MP 30fps ZSL with single ISP;...

  • Page 12: Interface Map

    1x 3.5mm HP jack (CTIA) 1x DMIC Extended Interface (support up to 4 DMICs) Audio 4x DMIC (on board) 2x Class-D Smart Speaker (up to 8Ω@2W) 1x power on 2x volume 1x force USB boot Others SW support Android 7 Operating -10℃...

  • Page 13: Bottom View

    5. 12V DC Jack 6.Battery connector 7. USB 3.0 Type A connector 1 8. USB 3.0 TypeA connector 2 9.USB 3.0 Type A connector 3 10. HDMI OUT TypeA connector 11. WLAN ext. ant. connector 12. 10Base/100Base Ethernet connector 13. Touch Panel connector 14.Debug UART connector 15.

  • Page 14: Basic Application

    4.4 Basic Application Power Adapter HDMI Camera Connector in back side Camera Connector in back side UART Figure 4.4-1 Thundersoft TurboX® S625 EVB Quick Start:  Remove Thundersoft TurboX® S625 EVB board carefully from the anti-static bag.  Assemble IMX214 Camera to the corresponding connector as show below. ...

  • Page 15: Detailed Description

    4.5 Detailed Description 4.5.1 12V DC Jack For convenient usage, 12V DC power adapter is provided in default package list. Battery & 12V power adaptor can be used independently; when both are connected, the EVB will choose 12V adaptor and cut-off battery power supplying.

  • Page 16: Power On Key

    4.5.3 POWER ON Key Press this Key for 4 seconds, the system will boot-up automatically. 4.5.4 Micro USB3.0 The S625 EVB utilizes Micro USB3.0 interface by default, the major functions list below：  Software debugging /downloading and transmitting data by connecting with PC ...

  • Page 17: Force Usb Boot Key

    4.5.6 Force USB Boot Key When press this button and NO/OFF key, before insert the battery or 12v power adapter, the system enters the force download mode (QFILE), which can be downloaded using the QFILE tool, but this is not recommended.

  • Page 18: Ethernet Connector

    standard. There are HDMI type A interface, and up to 60Hz 1080p 8-bit HDMI output. 4.5.9 Ethernet Connector There are LAN interface, the S625 EVB integrates SPI to LAN Bridge. 4.5.10 Volume Key Volume down & Reset Volume up There are volume keys. The user can generate a mandatory reset by long key pressing volume down key over 15s.

  • Page 19: Tf Card Connector

    4.5.11 TF Card connector Volume down & Reset Volume up There are Push–Push micro SD card connector. Its supports SD 3.0. 4.5.12 Speaker Connector There are speaker connector. The connector part number is WF12-042S3R/WAFER . The S625 EVB integrates audio code WCD9335 and stereo speaker PA WSA8810. It is up to 8Ω@2W output. Speaker connector PINs Signal...

  • Page 20: Mm Audio Jack

    4.5.13 3.5mm Audio Jack There are 3.5mm audio headset connector. CTIA standard interface. 4.5.14 Touch Panel Connector The S625 EVB has touch panel interface, the B to B connector part number is ASE5S1010. I2C signal pull up on EVB board. ouch panel connector Voltag Description...

  • Page 21: Lcd Connector

    4.5.15 LCD Connector The S625 EVB supports DSI0 channel for display, 1080p 60fps. The B to B connector part number is ASE5S2410. LCD connector Volta Description PINs Signal Type VREG_L6_1P8 1.8 V LCD IO power output, max current 100 mA GPIO61_LCD_RST_N chan 1.8V...

  • Page 22: Fan Connector

    4.5.16 Fan Connector There are Fan connector. The connector part number is SWF-12504LT. Battery Interface PINs Signal Level Description VBAT +4.1V Power supply max current 150mA 2, 3 4.5.17 Extension Interface There are General Purpose Header interfaces, including SPI bus、UART、I2C、GPIO、I2S etc. Audio Interface PINs Name Voltage...

  • Page 23: Camera Connector

    SMB1358_INT_GPIO59_EXT_CON 3.3v DI/DO GPIO GPIO_139_EXT_CON 3.3v DI/DO GPIO BLSP5_UART5_TX_EXT_CON 3.3v DI/DO UART BLSP5_UART5_RX_EXT_CON 3.3v DI/DO BLSP5_I2C5_SCL_EXT_CON 3.3v BLSP5_I2C5_SDA_EXT_CON 3.3v DI/DO BLSP7_SPI7_MOSI_EXT_CON 3.3v DI/DO BLSP7_SPI7_MISO_EXT_CON 3.3v DI/DO BLSP7_SPI7_CLK_I2C7_SCL_EXT_CO 3.3v BLSP7_SPI7_CS_I2C7_SDA_EXT_CON 3.3v 6,9,14,20,25,30, 34,39 7,15,22,26,27,2 8,32,33 Table 4.5-2 Extension Interface Definition 4.5.18 Camera Connector The S625 EVB supports two 4-lane camera interfaces.

  • Page 24: Dmic

    VREG_L6_1P8 1.8V Camera IO power output, max current 100 CAM_I2C_SCL1 1.8 V Camera control interface I2C serial clock Camera analog power output, CAM_AVDD_2V8 2.8 V max current 150 mA Camera digital power output, VREG_L2_1P1 1.1 V MIPI DSI0 signals for MIPI LCD; max current 300 mA SCAM_RST_N 1.8 V...

  • Page 25: Switch

    Acoustic dB SPL 10% THD @ 1 kHz Overload Point 4.5.20 Switch When switch is on Auto, insert the battery or 12V Power Adaptor, EVB will power on automatically. When switch is on manual, needs to pressing power on button. 4.5.21 LED Status RGB Power 12V...

  • Page 26: Operation Guide

    5 Operation Guide This chapter shows how to start Thundersoft TurboX® S625 EVB and do the testing and evaluation. 5.1 Hardware Preparation 5.1.1 Config fastboot & adb tools On Linux Ubuntu system, you can install adb or fastboot with below commands. sudo apt-get install android-tools-adb sudo apt-get install android-tools-fastboot After install success, you can find fastboot and adb tool under SDK...

  • Page 27: Power Off

    5.3 Power Off Long press power key after power off. 5.4 Reset 5.4.1 Reset by Hard key Long press Power key [POWER] for 10s or Volume down key [VOL -] for 15s, can reset Thundersoft TurboX® S625 EVB. 5.4.2 Reset by Command In Linux’s Terminal window, press command ‘adb reboot’...
  • Page 28 Please do not program persist partition. BT/WIFI mac address will be lost.

  • Page 29: Features List And Know Issues

    6 Features list and know issues 6.1 Features List Storage eMMC (Embedded Multi Media Card) WIFI 2.4G and 5G Band BT4.2, BLE Sensors Compass, Acceleration, Gyroscope HDMI Out HDMI 1.4, 1080@60 USB support USB 3.0 and USB 2.0 Micro TF card Extensible to 128GB maximum Camera Camera supported IMX214...
