Pizzacraft PIZZA OVEN LEG KIT Owner's Manual

For 6000 series portable ovens
Hide thumbs

Advertisement

Quick Links

Download this manual
Pizza Oven
LEG KIT
IMPORTANT: This instruction manual contains important information necessary for the proper
assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance. Keep this
manual for future reference.
Pizza oven and propane tank not included
OWNER'S MANUAL
For 6000 Series
Portable Ovens
Pizzeria Pronto
Pizzacraft
PC6000/ PC6002/ PC6004/ PC6005/ PC6500
CS042414
©The Companion Group 2014
1250 9th Street, Berkeley, CA 94710
1.800.521.0505
info@companion-group.com
®
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the PIZZA OVEN LEG KIT and is the answer not in the manual?

Questions and answers

Related Manuals for Pizzacraft PIZZA OVEN LEG KIT

Summary of Contents for Pizzacraft PIZZA OVEN LEG KIT

  • Page 1 Read and follow all warnings and instructions before assembling and using the appliance. Keep this manual for future reference. Pizzeria Pronto ® Pizzacraft ® PC6000/ PC6002/ PC6004/ PC6005/ PC6500 CS042414 ©The Companion Group 2014 1250 9th Street, Berkeley, CA 94710 1.800.521.0505...

  • Page 2: Hardware Package Contents

    ASSEMBLY INSTRUCTIONS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents and hardware contents list. Do not discard package materials before assembly is complete. If any part is miss- ing or damaged, do not attempt to assemble the product. Call customer service at 800.521.0505. To watch assembly video go to companion-group.com/pizzeria-pronto/assembly/ Estimated assembly time: 30 minutes Tools required- #2 Phillips screwdriver, 10mm wrench and rubber mallet/wood block, NOT...
  • Page 3 *IF RECENTLY USED, ALLOW OVEN TO COOL COMPLETELY. MAKE SURE PROPANE TANK IS OFF AND DISCONNECTED FROM PIZZA OVEN Remove hood and baking stones (2 parts) and set aside. Unscrew interior leg screws(4). Flip oven over and remove short legs.
  • Page 4 Assemble front legs(2) and utility bar(1). Insert either end of utility bar into slots on upper leg. Secure with M5x25 screws(2). Insert upper front leg assembly and upper rear legs(2) into corrsponding leg holes at the base of the pizza oven.
  • Page 5 Insert lower legs(4) into upper legs(4), align holes and attach with M6x12 screws(4). DO NOT FULLY TIGHTEN THESE SCREWS UNTIL THE FINAL STEP OF ASSEMBLY. Insert bottom frames(2) into corresponding slots located near the base of the lower legs. Do NOT secure yet.
  • Page 6 Insert the straight ends of the tank ring frames(4) one at a time into the slots near the base of the lower leg so that they rest inside the lower frames within the slots. Each slot should contain one end of the bottom frame as well as one tank ring frame .
  • Page 7 Insert a lower leg cap(4) into each of the lower legs(4). Carefully tap leg caps into place securely using a rub- ber mallet or wooden block. CAREFULLY flip oven upright onto legs.
  • Page 8 Make sure oven is on a level surface and secure entire leg kit to oven using M6x10 Hex screws(4) and corresponding M6 washers. IMPORTANT: NOW TIGHTEN ALL LOOSE SCREWS IN ENTIRE ASSEMBLY! Gently place both pizza stones back into the oven and replace the hood.
  • Page 9 Place propane tank into support ring through either the left or right side. Insert tank at an angle so the base seats first and then rotate the tank into its upright position. Insert thumb screw into nut attached to rear of propane support ring and screw tight to secure propane tank into place.
  • Page 10 Reattach the gas line (rubber hose) to oven and enjoy. (WARNING: Make sure no part of the rubber hose is in contact with the oven body while the oven is hot). *Optional Long Cover Tank (available at pizzacraft.com) PM6019...

  • Page 11: Warranty And Registration

    We guarantee our products for one year from date of purchase for defects in manufacture or materials. We will repair or replace at our option. Proof of purchase is required. For replacement parts call 1.800.521.0505 Please register your oven at pizzacraft.com/register-pizza-oven.html or with enclosed postcard...
  • Page 12 ACCESSORIES For these and more visit pizzacraft.com/accessories.html DESCRIPTION ITEM NUMBER ACCESSORY 1 Pound Disposable Tank Adapter: Allows small portable propane bottle to be PC6013 used with the pizza oven. Great for tailgating and camping. Tee Valve: Allows you to use only one or two PC6014 cooking units for a 20 lb.
  • Page 13 DESCRIPTION ITEM NUMBER ACCESSORY Stone Brush: Long handle brush with natural PC0218 fiber bristles. Keeps stone clean between pizzas. Flexible Dough Rolling Mat: Easy to PC0408 measure and roll perfectly sized pizza crust. Pizza Warming Stand and Tray: 12 inch PC6020 pan is held above the hot oven, keeping the cooked pizza warm.
