NATURAL
GAS KIT
6000 series outdoor pizza ovens
IMPORTANT: This instruction manual contains important information necessary for the proper
assembly and safe use of the appliance.
Read and follow all warnings and instructions carefully before assembling and using the appliance.
Keep this manual for future reference.
OWNER'S MANUAL
Makes great tasting,
traditional Italian pizza –
with bubbly cheese, crispy
crust & toasty toppings.
Pizzeria Pronto
PizzaQue
Pizzacraft
PC6018
CS1214
©The Companion Group 2014
1250 9th Street, Berkeley, CA 94710
800-521-0505
info@companion-group.com
®
®
®
Advertisement
Related Manuals for Pizzacraft 6000 series
Summary of Contents for Pizzacraft 6000 series
- Page 1 GAS KIT Makes great tasting, traditional Italian pizza – with bubbly cheese, crispy 6000 series outdoor pizza ovens crust & toasty toppings. OWNER’S MANUAL IMPORTANT: This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information ........3 Assembly Instructions ....... 5 Operation Instructions ......13 Troubleshooting ......... 14 Warranty and Registration ......15... -
Page 3: Safety Information
SAFETY INFORMATION A. IMPORTANT: Before you begin... B. SPECIAL NOTES: Read and follow all instructions carefully. . WARNING: Connection to gas source must be This device requires outlet pressure of 7 inches of done by a certified plumber. water column. Installation must be made in accordance with any If pressure is greater than 1/2 psi, make sure that local codes or regulations, or in the absence of... - Page 4 DANGER If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Remove hood. 4. If odor continues, keep away from the appliance and immediately call your fire department. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury or death.
-
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS Before beginning assembly of product, make sure all parts are present. Compare parts with package contents and hardware contents list. Do not discard packing materials before assembly is complete. If any part is missing or damaged, do not attempt to assemble the product. Call customer service at 800- 521-0505. - Page 6 Shut off gas supply and remove cap from the outlet of the housing pipe. WARNING: Connection to gas source must be done by a certified plumber. Wall hole where housing pipe extends from * CONFIRM GAS LINE PRESSURE IS 7” W.C.
- Page 7 Coat the 3/8 NPT MALE outlet of the house piping with gas resistant pipe dope. Attach the threaded end of the quick disconnect socket (note: the direction arrow of flow is indicated on the socket) to the thread- ed outlet of the house piping and tighten with hose wrench. Shut-off valve Wall hole where housing pipe extends from Existing outlet of the house piping Quick Disconnect...
- Page 8 Remove hood and pizza stones from oven and carefully set them aside. Flip oven base upside down to access the inlet pipe. Inlet Pipe Remove the inlet pipe from the oven body by unscrewing the 2 screws on front of oven beneath the knob as well as the screw securing the inlet pipe mount underneath the oven.
- Page 9 Uncrew the Jet from the interior end of the inlet pipe facing in toward the oven. Propane Gas Jet old Jet has smaller internal hole Replace the old Jet with the new one provided in the NG Conversion Kit. Natural Gas Jet Jet has larger internal hole...
- Page 10 Replace inlet pipe. Insert gas inlet assembly into body as shown. Secure control valve with 2 supplied screws to body front then secure pipe support with the third M4x5 Phillips screw. Attach control knob by aligning the keyway and pushing onto valve spindle. Connect starter wire from valve assembly to starter plug by firmly pushing it into place.
- Page 11 Attach the 6’ Natural Gas Hose directly to the appliance by connecting the 3/8 SAE FEMALE end of the hose to the 3/8 SAE MALE appliance inlet and tighten with hose wrench. Natural Gas Hose Make sure all the appliance controls are turned OFF before connecting the hose to the quick disconnect socket.
- Page 12 LEAK TEST INSTRUCTIONS DANGER: DO NOT use open flame to test for gas leaks. DO NOT perform leak test near any potential source of ignition. DO NOT SMOKE while performing the test. A fire or explosion could occur resulting in property damage, severe burn or even death. Make sure the hose is NOT connected to the quick connect socket before proceeding.
-
Page 13: Operation Instructions
OPERATING INSTRUCTIONS BREAKING IN YOUR OVEN When firing your oven for the first time, it is advisable to run the burner on “HIGH” for 20 minutes and then turn the oven off and let cool to room temperature. This tempers the oven and once cool is ready for use. Note that each burner has been tested before it left the factory, discoloration of the metal is a natural result of the material being heated. -
Page 14: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Check black wire is connected to starter plug (pg. 8 - step 6) Follow auxilery starter instructions No spark to confirm spark (pg. 13) Sparking pin distance has been changed (adjust pin for stronger spark) Burner will not light Check for kink in hose No gas flow to burner Check for gas leaks in connections... -
Page 15: Warranty And Registration
WARRANTY AND REGISTRATION We guarantee our products for one year from date of purchase for defects in manufacture or materials. We will repair or replace at our option. Proof of purchase is required. For replacement parts call 800-521-0505...
