EN7016SK EchoStream
Installation and Operation Manual
1 Quick Start
By following this procedure you can quickly configure the supplied
equipment to perform a site survey. Review the main body of this manual
for additional options, features and a more detailed startup process.
Note: If performing site surveys in Australia or New Zealand, the additional
setup steps in the main body of this manual must be performed.
1. Slide off the battery cover on the back of the EN4016SK survey
receiver.
2. Load four AA batteries into the survey kit receiver.
3. Press the Power button to turn on the survey kit receiver.
Figure 1 EN4016SK Survey Receiver
4. Press the enter button to advance to M
5. Select R
P
on the M
EGISTER
OINT
6. Select P
1 on the R
OINT
EGISTER
7. Press the EN1223SK Reset button.
Transmit
LED
On/Off
Button
Figure 2 EN1223SK Survey Transmitter
8. Select P
. The survey transmitter should now be registered.
ENDANT
9. Press the EN1223SK On/Off button. The transmit LED should begin to
flash.
10. Use the small flat-blade screwdriver to press the housing release tab on
either end of the EN1210SK and separate the housing.
11. Select P
2 on the R
OINT
EGISTER
3.6.14 04493E © Inovonics, 2014 - www.inovonics.com
Survey Kit
Power
Button
Enter
Button
Exit
Button
M
.
AIN
ENU
M
.
AIN
ENU
P
menu.
OINT
Reset
Button
P
menu.
OINT
12. Press the EN1210SK Reset button. The transmitter should now be
registered.
Frequency
Band
Selection
Pins
Figure 3 EN1210SK Survey Transmitter
13. Press the EN1210SK On/Off button. The transmit LED should begin to
flash.
14. Place the survey transmitters where you plan to mount your network
coordinator or receiver.
15. Walk the receiver to the first point you plan to use a transmitter or a two-
way end device.
Note: Reversing the position of the end device and the high-power
repeater will make the survey easier to perform. This equipment reversal
will not affect the accuracy of the results.
16. Press Exit to return to the M
17. Select P
S
on the M
OINT
TATUS
18. Select P
1 or P
2 to view signal information.
OINT
OINT
Figure 4 The Point Status Summary Screen
Transmit
Reset
LED
Button
On/Off
Button
M
.
AIN
ENU
M
.
AIN
ENU
Transmission
Signal
Symbols
Quality
