QUICK INSTALLATION GUIDE

Copy Declaration

The copy of this munual belongs to Hangzhou Livoltek Power Co.,Ltd. All rights

reserved. Without the written permission of the company. Any unit or individual

shall not extract or reproduce part or all of the contents of this documents, and

shall not transmit it in any form.

GT3-75~125KW

GT3-36~75KW-L

GT3-100~150KW-M

Ver.00

Need help?

Do you have a question about the GT3-75KW and is the answer not in the manual?

Questions and answers

Summary of Contents for LIVOLTEK GT3-75KW

Page 1 GT3-100~150KW-M Copy Declaration The copy of this munual belongs to Hangzhou Livoltek Power Co.,Ltd. All rights reserved. Without the written permission of the company. Any unit or individual shall not extract or reproduce part or all of the contents of this documents, and shall not transmit it in any form.
Page 2 Please check www.livoltek.com for more information. Sa y LIVOLTEK GT3 Series grid-tied inverter, ideal for business and remote locations. The inverter generates renewable electricity from solar energy, and provides Pure Sine Wave AC output for connected equipment.
Page 3 Symbol on the Type Label Symbol Explanation CE mark. The inverter complies with the requirements of the applicable CE guild lines. UKCA mark. The inverter complies with the requirements of the applicable UKCA guild lines. UKNI mark. The inverter complies with the requirements of the applicable UKNI guild lines. Direct Current (DC) Alternating Current (AC) Point of connection for grounding protection...
Page 4 Seguridad Inversor de red LIVOLTEK Serie GT3, ideal para hogares, empresas y lugares remotos. El inversor genera electricidad renovable a partir de energía solar y proporciona una salida de CA de onda sinusoidal pura para los equipos conectados.
Page 5 Símbolo en la etiqueta de tipo símbolo Explicación Marca CE. El inversor cumple los requisitos de las líneas aplicables del gremio CE. Marca UKCA. El inversor cumple los requisitos de las líneas gremiales UKCA aplicables. Marca UKNI. El inversor cumple los requisitos de las líneas gremiales UKNI aplicables. Corriente continua (CC) Corriente alterna (CA) Punto de conexión para la protección de puesta a tierra.
Page 6 Segurança O inversor on-grid da série LIVOLTEK GT3, ideal para residências, negócios e locais remotos. O inversor gera eletricidade renovável a partir de energia solar e fornece saída CA de onda senoidal pura para os equipamentos conectados.
Page 7 Símbolo na Etiqueta de Tipo símbolo Explicación Marca CE. O inversor está em conformidade com os requisitos das diretrizes CE aplicáveis. Marca UKCA. O inversor está em conformidade com os requisitos das diretrizes UKCA aplicáveis. Marca UKNI. O inversor está em conformidade com os requisitos das diretrizes UKNI aplicáveis.
Page 8 Veuillez consulter www.livoltek.com pour plus d'informations. Sécurité LIVOLTEK série GT3 onduleur sur réseau est idéaux pour les maisons, les entreprises et les régions éloignées. L'onduleur génère de l'électricité renouvelable à partir de l'énergie solaire et fournit une sortie CA à onde sinusoïdale pure pour les équipements connectés.
Page 9 Symbole sur l'étiquette de type símbolo Explicación Marquage CE. Les onduleurs sont conformes aux exigences des directives CE applicables. Marquage UKCA. L'onduleur est conforme aux exigences des lignes de guilde UKCA applicables. Marquage UKNI. L'onduleur est conforme aux exigences des lignes de guilde UKNI applicables. Courant Continu Courant alternatif Point de connexion pour la protection de mise à...
Page 10 Prosimy o sprawdzenie strony www.livoltek.com w celu uzyskania dodatkowych informacji. Sécurité Falownik sieciowy LIVOLTEK serii GT3, idealne rozwiązanie dla domu, ﬁrmy i odległych lokalizacji. Falownik generuje odnawialną energię elektryczną z energii słonecznej i zapewnia wyjście prądu AC w postaci czystej fali sinusoidalnej dla podłączonych urządzeń.
Page 11 Symbol na tabliczce znamionowej símbolo Explicación Oznakowanie CE. Falownik spełnia wymagania obowiązujących wytycznych CE. Oznakowanie UKCA. Falownik spełnia wymagania norm UKCA Oznakowanie UKNI. Falownik spełnia wymagania norm UKNI. Prąd stały (DC) Prąd zmienny (AC) Punkt połączenia dla zabezpieczenia uziemienia. Uwaga RCM Certyﬁkat SAA.
Page 12 Packing List /Lista de embalagem/ Liste de colisage/Lista de embalaje /Lista di imballaggio/Paklijst Inverter Bracket Expans on Screws M5 Screws *2 OT Terminal *7 PV Termınal *20 pairs PV Pin Angle *20 pairs Quick Installation Guide *1 Cold-pressed Terminal *24 Wi-Fi Logger Certiﬁcation *1 Note:The images shown here are for reference.
Page 13 Mounting Location/Local de montagem/Emplacement de montage /Ubicación de montaje/Posizione di montaggio/Montagelocatie +60 C ≤100% < 4000m -30 C max 5 degrees ≥500mm ≥800mm ≥800mm ≥500mm ≥450mm Taking out and Moving the Inverter/Retirando e Movendo o Inversor/ Retrait et déplacement de l'onduleur/Cómo sacar y mover el inversor/ Estrazione e spostamento dell'inverter/De omvormer verwijderen en verplaatsen Carefully lift the inverter from the packaging box (it is recommended to arrange personnel...
Page 14 Mounting/Montagem/Montage/Montaje/Montaggio/Montage 1.Wall-Mounted Installation Spare parts Quantity Item Source Bracket Delivery Scope Self-tapping screw Delivery Scope Bolt assembly Delivery Scope Use a spirit level to ensure the bracket is level Drill holes at the marked locations φ 1 0 Use a hammer to hammer the expansion screws into the holes Pass the screws through the bracket and...
Page 15 2.Installed on the PV bracket (under the PV modules) Spare parts Quantity Notice: Item Source Materials marked "Self-prepared" in the material table,you should Bracket Delivery Scope prepare them yourself and select appropriate speciﬁcations according to Self-tapping screw Delivery Scope the actual installation situation. Bolt assembly Delivery Scope In addition to the standard inverter bracket, other brackets need to be...
Page 16 The U-shaped clamp passes through the mounting column and Install the inverter bracket the brackets to ﬁx the brackets on the mounting column. Before installation, make sure the column can support the weight of the inverter. Fix the inverter bracket on the column bracket 45N.m 1.
Page 17 PE/PE/mise à la terre/Puesta a tierra/Aarding Suggested spec: 10AWG wire Strip cables Crimping terminal Fasten on the inverter 12N.m Suggested spec: Insert the PV+/PV- pin PV+ crimping method 12-10AWG,4~6mm² wire diameter PV- crimping method Mc4 crimping tool < 1100 V 2.5~3.0 N.m Measure the PV+/PV- voltage(<1100v)
Page 18 Suggested circuit breaker current To ensure safety, cut oﬀ power ﬁrst Product AC Power 75kW 100kW 110kW 125kW Circuit Breaker Current 160A 200A 200A 250A 36kW-L 40kW-L 50kW-L 60kW-L 75kW-L Product AC Power 160A 160A 200A Circuit Breaker Current 250A 250A 100kW-M 124kW-M 125kW-M 150kW-M...
Page 19 Wi-Fi Insert the Wi-Fi into the inverter. Screw down the Wi-Fi Making COM Wirings strip the cable insulation for 6~8mm COM Connection COM port details display diagram DRM1/5 DRM2/6 DRM3/7 DRM4/8 DRM1/5 RS4851A RS4851B RS4852A RS4852B RS4853A RS4853B DI_1 DI_2 RS485A_R RS485B_R Meter_485A...
Page 20 System Connection Diagram/Diagrama de conexão do sistema/Schéma de connexion du système/Diagrama de conexión del sistema/Schema di connessione del sistema With CT Connection Diagram(80A ≤ ac ≤ 120A,120A ≤ ac ≤ 250A) Meter 3 6 9 12 3 6 9 12 Meter_485A Meter_485A Meter_485B...
Page 21 Meter Connection Meter_485A Meter_485B Meter Meter_485A Meter_485B Methods to determine the correct direction of smart meter: ① Disconnected the inverter, activate household loads, and observe the current and power values readings on the meter. Positive readings indicate the meter is correctly installed. ②...
Page 22 Scan the QR code to Go to login page Select the appropriate server based on the installation site. download the "My LIVOLTEK" APP My Livoltek App Download Conﬁrm WiFi Dongle Server Click ”Go Local Mode” Click ”Wi-Fi Mode” Connecting the WiFi dongle...
Page 23 System Operation Powering on the System Powering oﬀ the System Step 1:Turn on the AC breaker on the GRID side. Step 1:Turn oﬀ the loads (if needed). Step 2:Turn on the PV breaker. Step 2: Turn oﬀ the PV. Step 3: Switch on the loads (if needed to set 0-feed-in function). Step 3:Turn oﬀ...
Page 24 Select the appropriate server Enter default account and Click "Set". Setting is based on the installation site password complete Note:If the correct server has been set up before, this interface will display the corresponding data and there is no need to 8096 8096 enter it manually.
Page 25 Initial Parameter Setting 1. Power on inverter 5. Create a site(Plant) 2. Install My Livoltek App 6. Add the device(inverter)to the site Steps: 3. Wi-Fi dongle connection by App 7. Set initial parameters via the App's local mode. 4. App Account Restration 8.
Page 26 QR code to go to login page select the appropriate server based on the installation site. download the "My LIVOLTEK" APP My Livoltek App Download Conﬁrm WiFi Dongle Server click ”Go Local Mode” click ”Wi-Fi Mode” click ”Setting”...
Page 27 Create Site login to your account create a site enter site details site name address and time zone must match the installation location set the site according to site created successfully actual installation set the tariﬀ The old users can also add new sites here.
Page 28 Distribution Network go local mode select "PSD300-WiFi" connect to home WiFi connect to the WiFi Dongle connected to Network when prompted to switch networks, connect to your home Wi-Fi. click "Start Conﬁguration" User Register select the region and click "Register" enter account details account type...
Page 29 Initial Parameter Setting Start 1. Power on inverter 5. Create a site(Plant) 2. Install My Livoltek App 6. Add the device(inverter)to the site Steps: 3. Wi-Fi dongle connection by App 7. Set initial parameters via the App's local mode. 4. App Account Restration 8.
Page 30 LIVOLTEK oﬃcial platform: WEB LINK1: https://www.livoltek-portal.com/ For Asia, Latin, American, Australia and others WEB LINK2: https://evs.livoltek-portal.com/ For Europe,Middle East Regions, Africa My Livoltek App Cloud Monitoring User Register Create Site click on the “site” on navigation click the “Add site”...
Page 31 users could click on the site name to view related data Add Device click “Add Device” input the information of device open the site, users could view the information of devices...
Page 32 More information in the QR code or at www.livoltek.com 1418-35 Moganshan Road, Hangzhou, 310011, China info@livoltek.com www.livoltek.com...

This manual is also suitable for:

Gt3-36kw-l Gt3-100kw-m Gt3-125kw Gt3-75kw-l Gt3-150kw-m
