Desktop ROG Strix (G10DK)
Service Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROG Strix G10DK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus ROG Strix G10DK

Summary of Contents for Asus ROG Strix G10DK

  • Page 1 Desktop ROG Strix (G10DK) Service Manual...
  • Page 2 INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR INTHIS MANUAL OR PRODUCT.
  • Page 3 ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS' suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
  • Page 4 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Before handling components, use a grounded wrist strap or touch a safely grounded object to avoid damaging them due to static electricity.
  • Page 5 Table of Contents ⚫ ASUS Desktop ROG Strix (G10DK) Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Appropriate Tools ⚫ Disassembly steps : • SLIDE DOOR • VGA CARD • • DDR & SSD CARD • WIFI CARD & M.2 WIFI CARD •...
  • Page 6 ASUS Desktop ROG Strix (G10DK) Overview Rear Panel View Front & Top View ❶ Power button ❶ PS/2 keyboard/mouse combo port ❷ Headset port ❷ USB 3.2 Gen 1 ports ❸ USB 3.2 Gen 1 ports ❸ DVI-D port ❹ VGA port ❺...
  • Page 7 Components Top View ♦ STAND OFF ♦ WIFI ANTENNA ♦ CABLE USB WIFI TO MB ♦ VGA CARD ♦ SYS FAN ♦ LED BD CR ♦ HDD SATA CABLE ♦ X500MA IO: M2*4.6H*4.75D (L:300MM) 6USB/VGA/DVI/HDMI BLK AJ:LAN/3AUDIO/F1 ♦ AUDIO CABLE ♦...
  • Page 8 Components Bottom View ♦ VGA Card ♦ SYS FAN ♦ LED BD CR ♦ LED BD. UP ♦ DDR ♦ MAIN BOARD ♦ CPU SOCKET ♦ LED BD. DOWN ♦ ♦ WIFI CARD ♦ LED BD. SIDEUP ♦ FRONT IO BD USB CONN GASKET ♦...
  • Page 9 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ROG Strix (G15DK) desktop. ♦ Screwdriver ♦ Alcohol 95% ♦ Glove ♦ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. #1 #2 ♦...
  • Page 10 SLIDE DOOR Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Remove screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Pull the side doors*2pcs. #6-32*6.3L (7.3,2.45)(B)//KL,MACHINE NY B-ZN #2 8.0±0.5 Pull SLIDE DOOR (L) Pull SLIDE DOOR (R) Back...
  • Page 11 VGA CARD Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect connector. Screws Spec Torque(kgf-cm) Step 2 : Open the door. M3*6L (5.5,2.15) (P) #2 4.0± 0.5 Step 3 : Remove screws *4pcs. Step 4 : Press and unlock the VGA card.
  • Page 12 Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect (yellow mark) FAN connector *1pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove 4 screws on the outside of iron grid. M5*10L (F) W-NI (TP5) 8.0±0.5 Step 3 : Take out the Fan*1 pcs.
  • Page 13 DDR & SSD CARD Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Unlock then remove DDR *4pcs. Step 2 : Remove screw *1pcs then take out the SSD *1pcs. 2.0 ±0.2 M2*3L(4.6,0.8) (K)#1 Assembly Notice...
  • Page 14 WIFI CARD & M.2 WIFI CARD Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect the RF CABLE (connectors)*2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove the screw *1pcs. Step 3 : Remove WIFI CARD. M2*3L(4.6,0.8) (K)#1 2.0±0.2 Step 4 : Disconnect CABLE USB WIFI TO MB connector *1pcs.
  • Page 15 CPU COOLER Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect connector. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *2pcs. M3*4L (6.3,2.05) (P) #2 6.0±0.5 Step 3 : Remove the CPU Cooler. Disconnect Remove Take it out...
  • Page 16 MAIN BOARD & CPU Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect (yellow mark) connectors *8pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *12pcs (Red and green mark). M3*4L (6.3,2.05) (P) #2 6.0±0.5 Step 3 : Take out the Main Board.
  • Page 17 MAIN BOARD Assembly Notice Please follow the below image to Add sponge *4pcs (red mark)on motherboard DIMM Area. D700TD MB SPONGE L35 W8 T8//L35 W8 T8...
  • Page 18 MAIN BOARD with CPU COOLER & CPU Assembly Notice Please follow the instructions to assemble the CPU. CPU triangle must be aligned to MB triangle. Please follow the instructions to assemble VRM HS SUP BKT. 13PF02Q0M03011 SCREW M2*4L+MYLAR D6.5X1.7 G15DK VRM HS SUP BKT BLK 3.0kgf-cm +/- 0.3 Back...
  • Page 19 MAIN BOARD with CPU COOLER & CPU Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please make sure that re-smear thermal material on CPU Die, if thermal module have to be reassembled. Step-1 : Using dust-free cloth with 95% alcohol to clean up the residual thermal grease on CPU& GPU Die. Step-2 : Please use plastic tool (Plastic stick) to get Thermal Grease, and smear over CPU around 0.2~0.3mm thick.
  • Page 20 FRONT COVER AND LED BOARD Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Pull the latch slightly away. Screws Spec Torque (kgf-cm) Step 2 : Turn over the front case and Disconnect the connectors *2pcs of the cable inside. M3*8L (X) W-NI 4.0±0.5 Step 3 : Tear off the Mylar.
  • Page 21 LED CR BD for (Metal side door) SKU only Assembly Notice Before assemble cable on LED CR BD, Please add 2pcs ACETATE tape on the LED CR BD Pin as below picture.
  • Page 22 4D(Plastic side door) Cable for 2D(Metal side door) and only Assembly Notice Before assemble two cables, please follow below to paste ACETATE TAPE. Note: The two cables are GL10DH SATA CABLE 15P F/P 430MM and CABLE USB2.0 CRB TO Step1-1 : Winding the two cables with ACETATE TAPE to increase the insulation layer. MB L750.
  • Page 23 POWER SWITCH Please be sure to pull out AC POWER CORD. Disassembly Notice Assembly Notice When need to reuse old POWER SWITCH HOLDER, please Step 1 : Push hooks then take out POWER SW CABLE with POWER SWITCH HOLDER from CHASSIS. make sure the hooks no broken or deformation.
  • Page 24 TOP COVER AND FRONT IO BD AND LED BD Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Disconnect connectors *1pcs and remove screws *3pcs located on the LED BD. SIDEUP. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *2pcs.
  • Page 25 FIO USB CABLE Assembly Notice Please be sure to pull out adapter and disconnect the battery. Please follow the below criteria to assemble FIO USB CABLE. Step-1 : Make sure the acetate is attached to the Cable plug. Step-2 : Make sure the acetate is attached to the connector. Step-3 : Make sure the acetate is securely attached to the surface of the part on each side when wrapping.
  • Page 26 Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Remove screws *4pcs. Screws Spec Torque (kgf-cm) Step 2 : Disconnect the connectors *2pcs. SCREW #6-32*6L(7.1,2.3) (B) #2 6.5±0.5 Step 3 : Take out the HDD. Disconnect Unscrew Back...
  • Page 27 POWER SUPPLY Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Torque (kgf-cm) Step 1 : Disconnect the connector *1pcs. Screws Spec Step 2 : Remove screws *4pcs. SCREW #6-32 L6*H2.3 (B) W-NI 8.0±0.5 Step 3 : Take out the POWER SUPPLY. Disconnect Unscrew Take out...
  • Page 28 WIFI MAIN ANTENNA Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Tear off the Gasket and ANTENNA*2pcs. Step 2 : Take out ANTENNA. Assembly Notice Tear off Please follow the red and yellow mark to paste the Antenna and gasket.
  • Page 29 CABLE ASSEMBLY Assembly Notice Please be sure to pull out adapter and disconnect the battery. Tidy up the cable of the back mainframe as illustrated. Back...
