- Page 1 User Manual HDMI EXTENDER OVER FIBER HDMI Fiber Extender over IP with KVM (20km) Where every Moment comes Alive ER2870EXF...
-
Page 2: Specifications
Introduction： HDMI fiber extender is a device to use single mode and bidirectional fiber cable to transmit HD audio and video, the longest distance is 20km, and it supports point-to-point mode, point-to- multipoint, multipoint-to-multipoint mode. Features： It supports HDMI 1080p @ 60Hz Ø... -
Page 3: Hdmi Receiver
Physical interface diagram： HDMI Transmitter IR-TX HDMI OUT USB-PC Ports Function description Optical fiber SC / LC connector Fiber-LC IR-TX IR transmitter port HDMI IN HDMI input HDMI OUT Local HDMI loop out 5V Power Interface DC/5V Power adapter indicator Power System working indicator Link... -
Page 4: Connection And Operation
Ports Function description Fiber-LC Fiber LC / SC port IR-RX IR receiver port HDMI OUT HDMI output DC/5V 5V Power Interface Power Power adapter indicator Link System working indicator Keyboard Connect to keyboard Connect to mouse Mouse Connection and Operation： Connect the HDMI port of the source to the HDMI Transmitter with HDMI cable. - Page 5 2- Multipoint to Multipoint Application HDMI Cable Optical fiber cable D V D Optical fiber cable S TB Switch P S 3 IP settings: (multipoint-to-multipoint Settings required) 1. Connect the RX/TX of the extender to the computer using optical fibers and network cables through the switch.
- Page 6 3. Open the computer web browser, TX use 192.168.1.200:9999 login: (RX IP address is according to the actual input, RX board not connect cables will display in the display IP RX board.) Note: If the page cannot enter correctly, please check whether the colon input method is correct (Should be english input method).
-
Page 7: Package Include
E. g.: 1) 192.168.1.100. 2)192.168.1.101. 3)192.168.1.102. The IP for RX needs to be configured as TX IP +8; E. g.: TX: 192.168.1.100 RX: 192.168.1.108 Transmit Mode: Choose ‘MULTI_TO_MULTI’. Note: Click Submit (Commit) for each setting. Application diagrams： Audio-visual conference Command and control center Home theater Package include：...
