EiRA ER2602EX Manual

Hdmi extender over cat6 120m
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
Introduction
This HDMI Extender is a solution for transmission and extension uncompressed full HD
1080p@60Hz HDMI signal over a signal CAT5/5e/6 network cable. It includes a
transmitter unit (TX) and a receiver unit (RX), working as a pair. Long transmission
distance is up to 120 meters with zero latency. This HDMI Extender support IR
passback for remote control source device from receiver site easily. This product is
perfect for AV transmission in applications of HD conference system, HD video
shooting, HD multimedia education system, HD digital advertising and signage etc.
Features
• Include a transmitter unit (TX) and a receiver unit (RX), working as a pair.
• Transmission distance up to 120m via CAT6 cable, 100m via CAT5E cable,
80m via CAT5 cable.
HDMI Extender Over CAT6
120m (ER2602EX)
www.eiratek.com
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ER2602EX and is the answer not in the manual?

Questions and answers

Related Manuals for EiRA ER2602EX

Summary of Contents for EiRA ER2602EX

  • Page 1 HDMI Extender Over CAT6 120m (ER2602EX) Introduction This HDMI Extender is a solution for transmission and extension uncompressed full HD 1080p@60Hz HDMI signal over a signal CAT5/5e/6 network cable. It includes a transmitter unit (TX) and a receiver unit (RX), working as a pair. Long transmission distance is up to 120 meters with zero latency.
  • Page 2 HDMI Extender Over CAT6 120m (ER2602EX) • Support IR passback for remote control source device to receiver site easily. Support IR pass-back function (20~60KHz). Innovative IR pass back function, perfect improved infrared remote control experience • Uncompressed and zero latency.
  • Page 3 HDMI Extender Over CAT6 120m (ER2602EX) Package Contents Interface Transmitter (TX) Reset button Restart the unit RJ45 signal output Connect with network cable LINK indicator LED turns on all the time with HDMI signal transmission, flashes with no signal transmission...
  • Page 4 HDMI Extender Over CAT6 120m (ER2602EX) Receiver (RX) Reset button Restart the unit RJ45 signal input Connect with network cable LINK indicator LED turns on all the time with HDMI signal transmission, flashes with no signal transmission Power input Connect with DC5V1A power adapter...
