Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the Parts List and or Hardware List shown below
CAUTION: Please read the instructions thoroughly before assembly.
1.We recommend that you assemble this product with the assistance of another person; this will make the assemble
easier, and will help eliminate damage to the product or injury to persons during assembly.
2.Please do not tighten screws or bolts until the assembly is completed.
3.Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble
your newly purchased product correctly and efficiently.
PARTS LIST
NO:
COMPONENT
TABLE TOP
A
TOP MOUNTING
B
PLATE
C
TABLE LEAF
D
LEG
E
LEG POST
F
BOTTOM PLATE
BOTTOM MOUNTING
G
PLATE
Assembly Instructions
D1808-10: PLAZZO MARINA DINING TABLE
SKETCH
Q'TY
1PC
2PCS
1PC
6PCS
2PCS
2PCS
2PCS
MADE IN VIETNAM
HARDWARE LIST
NO:
COMPONENT
LONG BOLT Φ5/16"x2''L
1
2
LOCK WASHER Ø5/16"
FLAT WASHER Ø5/16"
3
4
ALLEN KEY 1/6''
SHORT BOLT Φ5/16"x1-1/2''L
5
6
WOOD CAP
7
GLUE FOR WOOD CAP
SKETCH
Q'TY
32PCS
56PCS
56PCS
1PC
24PCS
12PCS
1PC
PAGE: 1OF4
Advertisement
Related Manuals for Royal Classics PLAZZO MARINA D1808-10
Summary of Contents for Royal Classics PLAZZO MARINA D1808-10
- Page 1 Assembly Instructions D1808-10: PLAZZO MARINA DINING TABLE Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts which may have come loose inside the carton during shipment. Identify and count all items and compare with the Parts List and or Hardware List shown below CAUTION: Please read the instructions thoroughly before assembly.
- Page 2 Assembly Instructions D1808-10: PLAZZO MARINA DINING TABLE STEP 1 STEP 2 Assemble leg posts (E) together with bottom plates (F) Assemble legs (D) with leg posts (E) using Allen using Allen Key (4) with hardware 1,2, and 3. Key (4) with hardware 1,2, and 3. *Attention: DO NOT TIGHTEN THE BOLTS STEP 4 STEP 3...
- Page 3 Assembly Instructions D1808-10: PLAZZO MARINA DINING TABLE STEP 5 Repeat STEP 1 THOUGH STEP 4 to assemble the second pedestal. STEP 6 Assemble top mounting plate (B) on to the table slides using Allen Key (4) with hardware 5,2, and 3. STEP 7 in...
- Page 4 Assembly Instructions D1808-10: PLAZZO MARINA DINING TABLE STEP 8 STEP 9 Install the table leaf (C) by unlocking the locks Pulling on the ends of the tabletop to open the top under the tabletop. to place table leaf (C). UNLOCKED STEP 10 COMPLETED TABLE Push on the ends of the table top and...
