Royal Classics MONIQUE B992-110 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,which
may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS
LIST and/or HARDWARE LIST shown below.
CAUTION: Please read the instructions thoroughly before assembly.
1.We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2.Please do not over tighten screws or bolts until the assembly is completed.
3.Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble
your newly purchased product correctly and efficiently.
NO: COMPONENT
A
HEADBOARD
B FOOTBOARD
C SIDE RAIL
LEFT LEG
D
HEADBOARD
RIGHT LEG
E
HEADBOARD
CENTER
F
POST
HEADBOARD
G
SLAT
H
SLATS
SUPPORT
I
LEGS
Assembly Instructions
B992-110: MONIQUE 6/6-6/0 EK/WK HEADBOARD
B992-120: MONIQUE 6/6-6/0 EK/WK PANEL FB & SLATS
B992-330: MONIQUE 5/0-6/6 Q/EK PANEL SIDE RAILS

PARTS LIST

DRAWING
Q'TY
1PC
1PC
2PCS
1PC
1PC
1PC
1PC
4PCS
8PCS
MADE IN VIETNAM

HARDWARE LIST

NO: COMPONENT
1
Bolt Φ5/16"x50mmL
2 Flat washer Ø5/16"
3
Lock washer Ø5/16"
4
Allen Key 4mm
5
Threaded Bolt Ø5/16"x90mmL
6
Flat washer
7
Hex Nut Ø5/16"
8
Wood screw Ø8x30mmL
9
Ø5/16" Wrench 12mm
DRAWING
Q'TY
9PCS
9PCS
9PCS
1PC
8PCS
8PCS
8PCS
8PCS
1PC
PAGE: 1OF2
