Assembly Instructions
CM4052E
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 4
Rev.14-06-03
Advertisement
Related Manuals for Furniture of America CM4052E
Summary of Contents for Furniture of America CM4052E
- Page 1 Assembly Instructions CM4052E ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List (Continued) Parts List #1 x 1 pc #D x 8 pcs Table Top Lock Washer 5/16” #E x 1 pc #2 x 4 pcs Allen Wrench M4...
- Page 4 Turn right (clockwise) to tighten #B x 8 pcs #C x 8 pcs #D x 8 pcs Carefully place the table top (#1) facing down on a protected surface. Align the legs (#2) with the pre-drilled holes on the bottom of the table top (#1). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then...
