Pie Pass® Pickup Unit
Models
PPU41C-120
PPU61S-120
CAUTION:
WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Installation and
Operation Manual
REV D 09/01/2021
P/N 229783
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Duke Pie Pass PPU41C-120
Summary of Contents for Duke Pie Pass PPU41C-120
- Page 1 WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning This manual is Copyright © 2021 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered trademark of the Duke Manufacturing Co.
-
Page 2: Table Of Contents
Installation and Operation of: Pie Pass® Pickup Unit TABLE OF CONTENTS Important Safety Instructions ........................2-3 Receiving and Inspection ............................ 3 Specifications ............................... 4-5 Wire Diagram ................................6 Counter Top Installation and Operation ......................7 Cart Installation and Operation......................... 8 Door Reversal Instructions ..........................9-10 Cleaning ...................................11 IMPORTANT SAFETY INSTRUCTIONS... -
Page 3: Receiving And Inspection
Installation and Operation of: Pie Pass® Pickup Unit The following warnings and cautions appear throughout this manual and should be carefully observed. • Turn the unit off, disconnect the power source and allow unit to cool down before performing any service or maintenance on the unit. •... -
Page 4: Specifications
Installation and Operation of: Pie Pass® Pickup Unit SPECIFICATIONS Back Of Unit 22.18 W/ HANDLES Front Of Unit 23.89 21.23 30.86 6’ Cord Front View Side View Back View ELECTRICAL SPECIFICATIONS: DIMENSIONS: Freight Class: 100 120 - Volt - 60 Height Width Depth... - Page 5 Installation and Operation of: Pie Pass® Pickup Unit SPECIFICATIONS Back Of Unit 22.18 W/ HANDLES Front Of Unit 23.89 21.23 64.61 6’ Cord Front View Side View Back View ELECTRICAL SPECIFICATIONS: DIMENSIONS: Freight Class: 100 120- Volt - 60 Height Width Depth Crated Ship Weight...
-
Page 6: Wire Diagram
Installation and Operation of: Pie Pass® Pickup Unit WIRE DIAGRAM Dominoes PPU service wiring diagram 4 - shelf unit is represented with solid lines. 6 - shelf option is represented with dotted lines *Each shelf heater has a built-in thermostat control Line Cord DPST... -
Page 7: Counter Top Installation And Operation
Installation and Operation of: Pie Pass® Pickup Unit COUNTERTOP INSTALL Countertop Install Operation of Unit a. Turn on power switch. a. Set unit on counter. b. Seal unit to countertop by b. Allow 20-30 minutes for unit applying silicone to the to preheat. -
Page 8: Cart Mount
Installation and Operation of: Pie Pass® Pickup Unit CART MOUNT Standalone Install Operation of Unit Note: If unit is not bolted to cart a. Turn on power switch. install as instructed below. b. Allow 20-30 minutes for unit a. Position unit on cart. to preheat. -
Page 9: Door Reversal Instructions
Installation and Operation of: Pie Pass® Pickup Unit DOOR REVERSAL INSTRUCTIONS Remove top hinge bracket (2 screws). A. Tilt top of door toward center of unit. Tilt forward so top pivot pin is on the outside of the top down flange. B. - Page 10 Installation and Operation of: Pie Pass® Pickup Unit Install the new bottom hinge bracket (pro- Flip door around. Install Teflon washer vided in the parts bag) in the bottom left (provided in the parts bag) on bottom door corner of unit. hinge pin, and insert door bottom hinge pin into bottom hinge bracket on unit.
-
Page 11: Cleaning
Installation and Operation of: Pie Pass® Pickup Unit CLEANING • Before cleaning the unit, switch it off. • Leave the unit to cool to touch. • Finally, wipe the unit down with noncorrocive cleaner. • Do not use abrasives, steel wool or similar. •... - Page 12 Installation and Operation of: Pie Pass® Pickup Unit Phone: 314-231-1130 Duke Manufacturing Co. Toll Free: 1-800-735-3853 2305 N. Broadway www.dukemfg.com Fax: 314-231-5074 St. Louis, MO 63102...
