- Page 1 EVS-Series Emergency Voice System Document LS10062-001SK-E Installation and 07/10/2014 Rev: Operations Manual P/N LS100062-001SK-E:B ECN: 14-0113...
-
Page 2: Installation Procedure
Installation Procedure Adherence to the following will aid in problem-free installation with long-term reliability: Installation Precautions - Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be connected to the fire alarm control panel. Disconnect all sources of power before servicing. -
Page 3: Table Of Contents
Contents Section 1 Overview ..............................1-1 Optional Accessories ........................1-1 Features ...........................1-2 About This Manual ........................1-2 1.3.1 Terms Used in this Manual ....................1-3 How to Contact Silent Knight ....................1-4 Section 2 Agency Listings, Approvals, and Requirements ........2-1 Federal Communications Commission (FCC) ................2-1 Underwriters Laboratories (UL) ....................2-2 2.2.1 Requirements for All Installations ..................2-2 2.2.2 Requirements for Central Station Fire Alarm Systems ............2-2... - Page 4 4.5.1 EVS-50W Board Layout ....................4-12 4.5.2 Mounting the EVS-50W ....................4-13 4.5.3 Wiring Specifications ......................4-14 4.5.4 Speaker Wiring ........................4-15 4.5.4.1 Wiring Lengths .......................4-15 4.5.4.2 Class B (Style Y) ....................4-15 4.5.4.3 Class A (Style Z) ....................4-16 4.5.5 VBUS Wiring ........................4-16 4.5.6 SBUS Wiring ........................4-17 4.5.7 Connecting AC Power ......................4-18 4.5.8 Backup Battery for EVS-50W ...................4-19 4.5.9 Calculating Current Draw and Standby Battery ...............4-20...
- Page 5 Silent Knight Fire Product Warranty and Return Policy Manufacturer Warranties and Limitation of Liability...
-
Page 6: Section 1 Overview
LS10062-001-SK-E Section 1 Overview The Emergency Voice System Packages are a combination of the addressable fire alarm control panel and voice integration control all in one package. The general idea of the Emergency Voice System is to activate a message giving building occupants instructions about an emergency event. -
Page 7: Features
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Features EVS-Series • The EVS-VCM has a built-in Digital Message Repeater. • 15 recordable one minute messages that can be mapped to eight EVS. • Single enclosure for system control components. • SBUS addressable amplifier. -
Page 8: Terms Used In This Manual
Overview LS10062-001-SK-E 1.3.1 Terms Used in this Manual The following terminology is used with the this system: Term Description Emergency Voice System.The features of the control panel and accessories that provide Mass Notification functionality as described in UL standard 2572. FACP Fire Alarm Control Panel Local Operator's Console. - Page 9 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Limitations of Fire Alarm Systems Manufacturer recommends that smoke and/or heat detectors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer’s recommendations, State and local codes, and the recommendations contained in Guide for the Proper Use of System Smoke Detectors, which is made available at no charge to all installing dealers.
- Page 10 Overview LS10062-001-SK-E prehend the meaning of the signal. It is the property owner’s responsibility to conduct fire drills and other training exercises to make people aware of fire alarm signals and instruct on the proper reaction to alarm signals. iii) In rare instances, the sounding of a warning device can cause temporary or permanent hearing loss. •...
- Page 11 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E manufacturer’s representative. Maintenance should be performed annually by authorized personnel only. The most common cause of an alarm system not functioning when a fire occurs is inadequate maintenance. As such, the alarm system should be tested weekly to make sure all sensors and transmitters are working properly. SURVIVABILITY: Per the National Fire Alarm Code, NFPA 72, all circuits necessary for the operation of the notification appliances shall be protected until they enter the evacuation signaling zone that they serve.
-
Page 12: Section 2 Agency Listings, Approvals, And Requirements
Agency Listings, Approvals, and Requirements Federal Communications Commission (FCC) The following information must be provided to the telephone company before the FACP can be connected to the phone lines: Manufacturer: Silent Knight by Honeywell Model Number: 5820XL-EVS FCC registration number: AC6 USA-34758-AL-E Ringer equivalence: 0.8B... -
Page 13: Underwriters Laboratories (Ul)
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Underwriters Laboratories (UL) 2.2.1 Requirements for All Installations General requirements are described in this section. When installing an individual device, refer to the specific section of the manual for additional requirements. The following subsections list specific requirements for each type of installation (for example, Central Station Fire Alarm systems, Local Protected Fire Alarm systems, and so on). -
Page 14: Section 3 Before You Begin Installation
LS10062-001-SK-E Section 3 Before you Begin Installation This section of the manual is intended to help you plan your tasks to complete the installation. Pleas read this section thoroughly, especially if you are installing a EVS-Series control for the first time. Environmental Specifications It is important to protect the control panel from water. - Page 15 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E by running the wire through ferrite shield beads or by wrapping it around a ferrite toroid. Flexputs / NACs Devices SBUS Relays Devices VBUS 5820XL-EVS Figure 3-1 Wire Routing Example Note: All circuits are power limited except the battery and AC cabling. Maintain 1/4 inch spacing between high and low voltage circuits and between power-limited and non-power limited circuits.
-
Page 16: Sbus Specifications
Before you Begin Installation LS10062-001-SK-E SBUS Specifications Refer to Section 4 of the FACP’s installation manual for SBUS wiring details. EVS-Series Model Number FACP Installation Manual 5820XL-EVS LS10061-001SK-E Electrical Specifications Table 3-1: EVS-50W AC Current Draw Standby Alarm Module Voltage Current Current EVS-50W 25V... -
Page 17: Section 4 Evs Device Installation
LS10062-001-SK-E Section 4 EVS Device Installation Caution! To avoid the risk of electrical shock and damage to the unit, power should be OFF at the control panel while installing or servicing. Mounting the Cabinet This section provides instructions on how to install the EVS series cabinet for surface or recessed mounting. Refer to Section 3.1 when choosing a mounting location. -
Page 18: Recessed Mounting
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E If you need to remove the cabinet door and the dead front panel, see Section 4.1.3.1 for instructions. Key Shaped Holes 26-1/2” Bottom Mounting Holes 20" Figure 4-1 5820XL-EVS and EVS-RCU Cabinet Mounting Holes 4.1.3 Recessed Mounting This section describes how to recess mount the cabinet into a wall. - Page 19 EVS Device Installation LS10062-001-SK-E Mount the cabinet to wall studs by inserting a screw through the cabinets side mounting holes into the wall stud. Trim Ring Sheet Rock Cabinet Mounting Hole 1.5 to 1.75" Mounting Studs Trim Ring Mounting Hole Cabinet Trim Ring Mounting Hole...
-
Page 20: 4.1.3.1 Cabinet Door And Dead Front Removal
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.1.3.1 Cabinet Door and Dead Front Removal While installing the cabinet it may be necessary to remove the cabinet door and the dead front panel. This section provides instructions on how to remove the door and dead front panel. Disconnect the SBUS connection between the EVS-VCM and the FACP. -
Page 21: Installing The Evs-Vcm
LS10062-001-SK-E Installing the EVS-VCM The EVS-VCM Voice Control Module is contained within the Silent Knight EVS Series panel enclosure. It provides a supervised microphone for live communication and an interface for the Emergency Voice System. This section provides information on how to install or remove the EVS-VCM to the control cabinet and how to make the proper wiring connections. - Page 22 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E ALL CALL NON-ACTIVE EVS Control LED EVS Control Button Button CALL Button NON-ACTIVE ALL CALL CALL Dead Front Dead Front Panel Panel Mounting Mounting Holes Holes OPG Select EVS (1-8) Activate Buttons Buttons Figure 4-6 Front View EVS-VCM...
-
Page 23: Connecting The Evs-Vcm To The Sbus
EVS Device Installation LS10062-001-SK-E 4.3.2 Connecting the EVS-VCM to the SBUS Refer to Figure 4-7 to properly connect the EVS-VCM to the FACPs SBUS. EVS-VCM Supervised Power Limited FACP Figure 4-7 SBUS Connections See Section 4.11 to set SBUS addressing. 4.3.3 Installing the Microphone To install the microphone follow these steps:... - Page 24 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Insert Microphone cord through hole at the bottom of the dead front panel. See Figure 4-9. Figure 4-9 Microphone Cord Inserted Through Dead Front Panel Hole Attach strain relief clip to microphone cord. The strain relief clip should have about 2-3/4” of micro phone cord through it.
-
Page 25: To Remove The Evs-Vcm
EVS Device Installation LS10062-001-SK-E 4.3.4 To Remove the EVS-VCM To remove the EVS-VCM follow these steps: Remove AC power and disconnect batteries from the main control panel. Disconnect the SBUS connections from the SBUS terminals on the EVS-VCM. See Figure 4-7. Disconnect any devices connected to the VBUS. -
Page 26: Installing The Evs-Sw24 Switch Expander
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Installing the EVS-SW24 Switch Expander The EVS-SW24 adds 24 switches to the EVS-Series controls for a total of 40 (with the 16 Non-EVS switches on the EVS-VCM). This section provides instruction on how to properly install the EVS-SW24. Follow these steps to install the EVS-SW24: Open Cabinet door and dead front panel. - Page 27 EVS Device Installation LS10062-001-SK-E Connect one end of the wiring harness (P/N 130398 supplied) to the EVS-VCM and the other end to the EVS-SW24 as shown in Figure 4-13. Wiring Harness Figure 4-13 Wiring Harness Connection Restore AC power. Reconnect backup batteries. 4-11...
-
Page 28: Installing The Evs-50W
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Installing the EVS-50W This section provides information on how to install the EVS-50W for use with the EVS-Series products. 4.5.1 EVS-50W Board Layout Figure 4-14 shows the location of terminals, DIPs, and Expander connection, used in the installation of the EVS- 50W. -
Page 29: Mounting The Evs-50W
EVS Device Installation LS10062-001-SK-E 4.5.2 Mounting the EVS-50W The EVS-50W is equipped with a separate enclosure. Refer to Section 4.1 when selecting a mounting location for the EVS-50W. The panel should be accessible to main drop wiring runs. It should be mounted as close to the center of the building as possible and located within a secured area, but should be accessible for testing and service. -
Page 30: Wiring Specifications
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.5.3 Wiring Specifications All wiring and devices installed in the system must meet the standards described in National Electrical Code (NFPA 70), NFPA Standard 72, and Life Safety Code (NFPA 101). To avoid induced noise (transfer of electrical energy from one wire to another), keep input wiring isolated from high-current output and power wiring. -
Page 31: Speaker Wiring
EVS Device Installation LS10062-001-SK-E 4.5.4 Speaker Wiring Each EVS-50W supplies four NAC (Notification Appliance Circuit) for speaker connection. The speaker circuit can be supervised and wired Class B (Style Y) or Class A (Style Z). The speaker circuit is capable of 50 watts of power at 25 Vrms or 70.7 Vrms. -
Page 32: Class A (Style Z)
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.5.4.3 Class A (Style Z) Figure 4-18 illustrates how to wire speakers to the control panel using Class A (Style Z) wiring. Supervised Power Limited Figure 4-18 Class A (Style Z) Speaker Configuration 4.5.5 VBUS Wiring The VBUS is an analog voice bus that carries the recorded voice messages from the... -
Page 33: Sbus Wiring
EVS Device Installation LS10062-001-SK-E 4.5.6 SBUS Wiring This section contains information on how to connect EVS-50Ws (up to 4) onto the main control SBUS. Refer to Section 3.3 for SBUS specifications. Wire the SBUS as shown in Figure 4-20 or Figure 4-21. Control Panel Supervised... -
Page 34: Connecting Ac Power
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.5.7 Connecting AC Power The AC inputs are rated as 120 VAC, 60 Hz (transformer P/N 115061). To install the AC transformer into the EVS-50W cabinet follow these steps: Open the cabinet door. To access cabinet interior, open dead-front panel by removing the upper screw and the mid-door retaining screw. -
Page 35: Backup Battery For Evs-50W
EVS Device Installation LS10062-001-SK-E 4.5.8 Backup Battery for EVS-50W The following steps explain how to connect the batteries (refer to Figure 4-24): Connect the black wire of the battery harness to the (-) side of the battery #2. Connect the jumper wire provided form the positive (+) side of battery #2 to the negative side of battery #1. Connect the red wire from the battery harness to the positive (+) side of battery #1. -
Page 36: Calculating Current Draw And Standby Battery
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.5.9 Calculating Current Draw and Standby Battery This section helps you determine the current draw and standby battery needs for your installation (18 Ampere Hours max. will fit in cabinet). Complete the remaining instructions in Table 4-2. Batteries larger than 18 AH will not fit in the main control cabinet, and must be housed in the RBB Accessory Battery Cabinet. -
Page 37: Installing The Evs-125W
EVS Device Installation LS10062-001-SK-E Installing the EVS-125W This section provides information on how to install the EVS-125W for use with EVS-series products. 4.6.1 EVS-125W Board Layout Figure 4-25 shows the location of terminals, DIPs, and Expander connections used in the installation of the EVS- 125W. -
Page 38: Mounting The Evs-125W
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.6.2 Mounting the EVS-125W The EVS-125W is equipped with a separate enclosure. Refer to Section 4.1 when selecting a mounting location for the EVS-125W. The panel should be accessible to main drop wiring runs. It should be mounted as close to the center of the building as possible and located within a secured area, but should be accessible for testing and service. -
Page 39: Wiring Specifications
EVS Device Installation LS10062-001-SK-E 4.6.3 Wiring Specifications All wiring and devices installed in the system must meet the standards described in National Electrical Code (NFPA 70), NFPA Standard 72, and Life Safety Code (NFPA 101). To avoid induced noise (transfer of electrical energy from one wire to another), keep input wiring isolated from high-current output and power wiring. -
Page 40: Speaker Wiring
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.6.4 Speaker Wiring Each EVS-125W supplies four NAC (Notification Appliance Circuit) for speaker connection. The speaker circuit can be supervised and wired Class B (Style Y) or Class A (Style Z). Speaker circuit 1 is capable of 100 watts of power at 25 Vrms. -
Page 41: Class A (Style Z)
EVS Device Installation LS10062-001-SK-E 4.6.4.3 Class A (Style Z) Figure 4-29 illustrates how to wire speakers to the control panel using Class A (Style Z) wiring. Supervised Power Limited Figure 4-29 Class A (Style Z) Speaker Configuration 4.6.5 VBUS Wiring The VBUS is an analog voice bus that carries the recorded voice messages from the EVS-VCM to the EVS- 125Ws, or the voice messages generated from a system microphone to the EVS-125Ws. -
Page 42: Sbus Wiring
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.6.6 SBUS Wiring This section contains information on how to connect EVS-125Ws (up to 4) onto the main control SBUS. Refer to Section 3.3 for SBUS specifications. Wire the SBUS as shown in Figure 4-31 or Figure 4-32. Supervised Power Limited Figure 4-31 SBUS Connections of the EVS-125W... -
Page 43: Connecting Ac Power
EVS Device Installation LS10062-001-SK-E 4.6.7 Connecting AC Power At installation, connect the AC terminals to the power source as shown in Figure 4-33. It may be necessary for a professional electrician to make this connection. The AC terminals are rated as 120 VAC, 60 Hz. Figure 4-33 AC Connection 4.6.8 Backup Battery for EVS-125W... -
Page 44: Calculating Current Draw And Standby Battery
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Connect the red wire from the battery harness to the positive (+) side of battery #1. Figure 4-34 Battery Connection to EVS-125W 4.6.9 Calculating Current Draw and Standby Battery This section helps you determine the current draw and standby battery needs for your installation (18 Ampere Hours maximum will fit in cabinet). -
Page 45: Installing The Evs-100W
EVS Device Installation LS10062-001-SK-E Installing the EVS-100W This section provides information on how to install the EVS-100W for use with the 5820XL-EVS. 4.7.1 EVS-100W Board Layout Figure 4-35 shows the location of terminals, DIP switch’s and Expander connection used in the installation of the EVS-100W. -
Page 46: Mounting The Evs-100W
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.7.2 Mounting the EVS-100W The EVS-100W is equipped with a separate enclosure. Refer to Section 3.1 when selecting a mounting location for the EVS-100W. The panel should be accessible to main drop wiring runs. It should be mounted as close to the center of the building as possible and located within a secured area, but should be accessible for testing and service. - Page 47 EVS Device Installation LS10062-001-SK-E Instead, separate the wiring as follows: 1/4” spacing must be maintained Input/Output Type: Wiring between each of these circuit Non Power-Limited: AC power, Standby batteries types; as well as between power Power-Limited: SBUS, VBUS limited and non power-limited circuits.
-
Page 48: Speaker Wiring
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.7.4 Speaker Wiring Each EVS-100W supplies eight NAC (Notification Appliance Circuit) for speaker connection. The speaker circuit can be supervised and wired Class B (Style Y) or Class A (Style Z). The speaker circuits are capable of 50 watts (each) at 25 Vrms or 70.7 Vrms. -
Page 49: Class B (Style Y)
EVS Device Installation LS10062-001-SK-E 4.7.4.2 Class B (Style Y) Figure 4-38 illustrates how to wire speakers to the control panel using Class B (Style Y) supervision. Supervised Power Limited 15kW EOL UL Listed Figure 4-38 Class B (Style Y) Speaker Configuration 4.7.4.3 Class A (Style Z) Figure 4-39 illustrates how to wire speakers to the control panel using Class A (Style Z) wiring. -
Page 50: Vbus Wiring
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.7.5 VBUS Wiring The VBUS is an analog voice bus that carries the recorded voice messages from the EVS-VCM to the EVS- 100Ws, or the voice messages generated from a system microphone to the EVS-100Ws. The maximum resistance on the VBUS is 20. -
Page 51: Sbus Wiring
EVS Device Installation LS10062-001-SK-E 4.7.6 SBUS Wiring This section contains information on how to connect EVS-100Ws (up to 4) onto the main control SBUS. Refer to Section 4 of the FACP’s Installation manual for SBUS specifications. Wire the SBUS as shown in Figure 4-41 or Figure 4-42. -
Page 52: Setting The Evs-100W Mode
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.7.7 Setting the EVS-100W Mode Figure 4-43 DIP Switch Modes When the EVS-100W is connected to a 5820XL-EVS version 13 or prior, see Figure 4-43 to set the amplifier mode using the DIP switches. When the EVS-100W is connected to a 5820XL-EVS version 14 or later, the mode is set using SKSS and the DIP switch mode selector is ignored. -
Page 53: Backup Battery For Evs-100W
EVS Device Installation LS10062-001-SK-E 4.7.8 Backup Battery for EVS-100W The following steps explain how to connect the batteries (refer to Figure 4-49): Connect the black wire of the battery harness to the (-) side of the battery #2. Connect the jumper wire provided form the positive (+) side of battery #2 to the negative side of battery #1. Connect the red wire from the battery harness to the positive (+) side of battery #1. -
Page 54: Calculating Current Draw And Standby Battery
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.7.9 Calculating Current Draw and Standby Battery This section helps you determine the current draw and standby battery needs for your installation (18 Ampere Hours maximum will fit in cabinet). Complete the remaining instructions in Table 4-4. Batteries larger than 18 AH will not fit in the main control cabinet, and must be housed in the RBB Accessory Battery Cabinet. -
Page 55: Installing The Evs-100Wbu
EVS Device Installation LS10062-001-SK-E Installing the EVS-100WBU The EVS-100WBU provides backup capability when operating the EVS-100W in the 100 watt with backup mode. The EVS-100WBU mounts above the EVS-100W board on the standoffs provided. 4.8.1 EVS-100W Board Layout Figure 4-45 shows the location of the EVS-100WBU on the EVS-100W board. EVS-100WBU Figure 4-45 Layout of EVS-100WBU 4-39... - Page 56 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.8.2 Installing the EVS-100WBU Follow these steps to install the EVS-100WBU. Make sure that all power supplied to the EVS-100W is removed. Connect the backup amplifier cable harness (P/N 50116775-001) from the connector labeled “Backup Amplifier”...
-
Page 57: Installing The Evs-Ce4
EVS Device Installation LS10062-001-SK-E Installing the EVS-CE4 The EVS-CE4 adds four audio circuits to the EVS-50W or EVS-125W. The EVS-CE4 mounts inside the EVS- 50W or EVS-125W cabinet Follow these steps to install the EVS-CE4: Using the four supplied screws mount the EVS-CE4 in the EVS-50W or EVS-125W cabinet as shown in Figure 4-47. -
Page 58: 4.10 Installing The Evs-Rvm
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.10 Installing the EVS-RVM The EVS-RVM Remote Voice Module is contained within the EVS-RCU Remote Command Unit. It provides a supervised microphone for live communication and an interface for the Emergency Voice System. 4.10.1 EVS-RVM Board Layout The following is description of the EVS-RVM remote voice module components. - Page 59 EVS Device Installation LS10062-001-SK-E NON-ACTIVE EVS Control ALL CALL EVS Control CALL Button Button Button NON-ACTIVE ALL CALL CALL Dead Front Dead Front Panel Mounting Panel Mounting Holes Holes OPG Select Buttons EVS (1-8) Activate EVS Status Buttons & Alarm LEDs Figure 4-50 Front View EVS-RVM 4-43...
-
Page 60: Wiring The Evs-Rvm
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.10.2 Wiring the EVS-RVM Refer to Figure 4-51 to properly connect the EVS-RVM to the FACPs SBUS. EVS-RVM Supervised Power Limited FACP Figure 4-51 SBUS Connections See Section 4.11 to set SBUS addressing. Connect the SBUS to the annunciator and EVS-RVM. -
Page 61: Installing The Microphone
EVS Device Installation LS10062-001-SK-E Connect the EVS-RVM to the VBUS and EVS-125W. EVS-VCM VBUS Connections 15k Resistor 3 VMS, 5 mA max. on last device EVS-RVM EVS-125W Figure 4-53 VBUS and EVS-125W Wiring for EVS-RVM 4.10.3 Installing the Microphone To install the microphone follow these steps: Clip the microphone into the micro phone clip. - Page 62 EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E Insert Microphone cord through hole at the bottom of the dead front panel. See Figure 4-55. Figure 4-55 Microphone Cord Inserted Through Dead Front Panel Hole Attach strain relief clip to microphone cord. The strain relief clip should have about 2-3/4” of micro phone cord through it.
-
Page 63: To Remove The Evs-Rvm
EVS Device Installation LS10062-001-SK-E 4.10.4 To Remove the EVS-RVM To install the EVS-RVM follow these steps: Remove AC power and disconnect batteries from the main control panel. Disconnect the SBUS connections from the SBUS terminals on the EVS-RVM. See Figure 4-51. Disconnect any devices connected to the VBUS. -
Page 64: 4.11 Addressing Sbus Devices
EVS Series Emergency Voice System Installation Manual LS10062-001-SK-E 4.11 Addressing SBUS Devices When installing a hardware module (such as, 5815XL, 5824, 5860, 5496, 5895XL, 5865-3 or 5865-4, EVS-50W, EVS-125W, EVS-100W, EVS-VCM, and EVS-RVMs), you must use the DIP switches on the module to assign an ID# to the module. Figure 4-58 shows all possible DIP switch positions and their correlation to a numerical ID. -
Page 65: Silent Knight Fire Product Warranty And Return Policy
No credit will be issued if the returned board was damaged due to misuse or abuse. • Repairs and returns should be sent to: Silent Knight / Honeywell Attn: Repair Department / RA Number_______________________ 12 Clintonville Road Northford, CT 06472 USA... -
Page 66: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 68 Silent Knight 12 Clintonville Road Northford, CT 06472-1610 203-484-7161 Fax: 203-484-7118 www.silentknight.com...
