Essentials For Living MALAY BED Assembly Instructions Manual

ASSEMBLY INSTRUCTIONS | MALAY BED
PARTS CHECKLIST
1 Headboard (1pc)
2 Side Rail (2pcs)
3 Footboard (1pc)
4 Middle Support (1pc)
5 Cross Bar (8pcs)
6 Side Bar (2pcs)
Step 1
Step 2
A Brackets (8pcs)
B JCBC Bolt M6x60mm (8pcs)
C Flat Washer M6xø18mm (16pcs)
D Spring Washer M6xø11mm (8pcs)
Please do not discard any of the packaging until you have checked all the parts and hardware
have been supplied. Before you begin assembly, decide on the height you would like to set the
cross bars as they can be adjusted to desired distance from the floor (10"-13"). Follow instructions
closely as deviation from them may void your warranty and present a possible safety risk. It is
recommended that assembly is done on a soft surface like carpet to avoid any damage. Though
not necessary, it is advised that assembly be completed by a team of at least two people.
2
19511 Pauling, Foothill Ranch, CA 92610 USA | www.EssentialsForLiving.com
HARDWARE CHECKLIST
E
F
G
H
1
2
1
2
Nut M6 (8pcs)
Allen Key L4 (1pc)
Wrench 10 (1pc)
Fab Screw ø8x1.5" (16pcs)
