Essentials For Living MALAY Assembly Instructions

ASSEMBLY INSTRUCTIONS
MALAY BED
PARTS LIST
CODE PARTS
1
2
3
4
5
6
7
PAGE 1 OF 5
DESCRIPTION QTY
HEADBOARD
SIDE RAIL
FOOT BOARD
MIDDLE SUPPORT
MIDDLE LEG
CROSS BAR
SIDE BAR
CODE
A
B
1
C
D
2
E
F
1
G
H
1
1
- PLEASE DO NOT DISCARD ANY OF THE PACKAGING UNTIL YOU HAVE
CHECKED ALL THE PARTS AND HARDWARE HAVE BEEN SUPPLIED.
- BEFORE YOU BEGIN ASSEMBLY, DECIDE ON THE HEIGHT YOU WOULD LIKE TO
SET THE CROSS BARS AS THEY CAN BE ADJUSTED TO DESIRED DISTANCE
8 FROM FLOOR (10"-13").
- FOLLOW INSTRUCTIONS CLOSELY AS DEVIATION FROM THEM MAY VOID
YOUR WARRANTY AND PRESENT A POSSIBLE SAFETY RISK.
- IT IS RECOMMENDED THAT ASSEMBLY IS DONE ON A SOFT SURFACE LIKE
CARPET TO AVOID ANY DAMAGE.
-THOUGH NOT NECESSARY, IT IS ADVISED THAT ASSEMBLY BE COMPLETED BY
2
A TEAM OF AT LEAST TWO PEOPLE.
HARDWARE LIST
HARDWARE DESCRIPTION
BRACKETS
JCBC BOLT
M6 X 60MM SS
FLAT WASHER
M6 x Ø18MM SS
SPRING WASHER
M6 x Ø11MM SS
NUT M6
HEX KEY L4
WRENCH 10
FAB SCREW
Ø8 X 1.5'' SS
QTY
8
9
17
8
8
1
1
16
